TRENDnet TFC-1000S40D3 Intelligent Fiber Media Converter - 1000Base-T to 1000Base-LX Single Mode SC Fiber (40 km / 24. 85 miles)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter implements precise signal conversion between 1000Base-T Gigabit Ethernet over twisted pair and 1000Base-LX over single-mode fiber. The SC-type fiber port utilizes dual-wavelength technology (TX-1310) optimized for long-haul transmission, while the RJ-45 copper port operates in Full-Duplex mode for maximum throughput. The converter maintains signal integrity across the entire 40 km distance without requiring intermediate repeaters or amplifiers.
Network management is facilitated through SNMP support at the port level, allowing administrators to monitor link status, activity, and performance metrics. Status LED indicators provide immediate visual feedback for power, link establishment, and data activity on both interfaces. The device operates with an external power adapter and generates minimal heat, ensuring stable operation in various environmental conditions.
Key Product Advantages
The TFC-1000S40D3 delivers several distinct advantages for network infrastructure projects requiring copper-to-fiber conversion. Its extended 40 km reach eliminates the need for multiple intermediate devices, reducing complexity and potential failure points in long-distance deployments. The intelligent management features provide enterprise-grade monitoring capabilities typically found in more expensive networking equipment.
Extended Distance Coverage
Transmits data over 40 km (24.85 miles) on single-mode fiber, far exceeding copper Ethernet limitations for campus, industrial, and metropolitan area network connections.
- Eliminates distance restrictions of Cat5e/Cat6 cabling
- Maintains signal quality over extended fiber runs
- Reduces need for intermediate network equipment
Flexible Deployment Options
Operates as a standalone converter or integrates with the TFC-1600 fiber chassis for centralized management in multi-port installations.
- Independent operation requires no chassis
- Scalable solution for growing network needs
- Simplifies migration from copper to fiber infrastructure
Deployment / Use Cases
This media converter is ideal for extending network segments between buildings in campus environments, connecting remote offices across metropolitan areas, or linking industrial equipment in manufacturing facilities. It effectively bridges the gap between copper-based local networks and fiber backbone infrastructure, enabling seamless integration without replacing existing endpoint devices.
Common applications include connecting security cameras over long distances, extending network access to remote warehouse locations, linking separate data centers for disaster recovery purposes, and integrating fiber runs into existing copper-based network architectures. The converter's compatibility with standard single-mode fiber makes it suitable for both new installations and legacy network upgrades.
Building-to-Building Connectivity
Connect network equipment between separate structures while maintaining Gigabit speeds and avoiding ground potential issues common with copper runs between buildings.
Industrial Network Extension
Extend Ethernet connectivity to remote manufacturing equipment, PLCs, or sensors in harsh environments where fiber provides superior noise immunity and distance capabilities.
Physical Profile
The compact wall-mountable design measures 6 inches wide by 6 inches deep by 3 inches high (152.40 mm x 152.40 mm x 76.20 mm), with a weight of approximately 12.76 ounces (361.74 grams). This space-efficient form factor allows installation in standard electrical boxes, on wall surfaces, or in equipment racks with appropriate mounting hardware. The durable construction withstands typical office and light industrial environments, while the external power adapter simplifies maintenance and replacement if needed.
- Width
- 6" (152.40 mm)
- Depth
- 6" (152.40 mm)
- Height
- 3" (76.20 mm)
- Weight
- 12.76 oz (361.74 g)
What's in the Box
The package includes all necessary components for immediate deployment of the media converter in your network environment.
Highlights
- Converts 1000Base-T Gigabit copper to 1000Base-LX single-mode fiber
- SC-type dual-wavelength fiber port supports distances up to 40 km (24.85 miles)
- Intelligent SNMP management at port level for network monitoring
- Operates as standalone converter or with TFC-1600 fiber chassis
- Wall-mountable compact design for space-constrained installations
- Full-Duplex operation on copper port for maximum throughput
- Status LED indicators for power, link, and activity monitoring
- Lifetime TRENDnet manufacturer's warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TFC-1000S40D3 |
| Brand Name | TRENDnet |
| Product Model | TFC-1000S40D3 |
| Product Name | Intelligent 1000Base-T to WDM TX-1310 Single Mode Fiber Converter(40KM) |
| Product Condition | New |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of SC Ports | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Maximum Distance Supported | 40 km (24.85 Mile) |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T,1000Base-LX |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Height | 3" (76.20 mm) |
| Width | 6" (152.40 mm) |
| Depth | 6" (152.40 mm) |
| Weight (Approximate) | 12.76 oz (361.74 g) |
| Miscellaneous | |
| Package Contents | TFC-1000S40D3 UTP/STP to Fiber Media Converter Power Adapter Quick Installation Guide |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 3 Year Lifetime |
User Manual
FAQ
What types of media does this converter support?
The TFC-1000S40D3 supports conversion between twisted pair copper Ethernet (1000Base-T) and single-mode optical fiber (1000Base-LX). The copper side connects via standard RJ-45 ports using Cat5e or higher cabling, while the fiber side uses SC connectors with dual-wavelength single-mode fiber for long-distance transmission.
What is the maximum distance this media converter can achieve?
This converter supports fiber runs up to 40 kilometers (24.85 miles) when using appropriate single-mode fiber optic cable. This extended reach makes it suitable for connecting network segments across campus environments, between buildings, or in metropolitan area network applications where copper Ethernet distance limitations would otherwise require additional networking equipment.
Does this converter support network management features?
Yes, the TFC-1000S40D3 includes intelligent SNMP (Simple Network Management Protocol) support at the port level. This allows network administrators to monitor link status, activity, and performance metrics, providing visibility into the converter's operation within managed network environments without requiring separate management modules or licenses.
Can this converter be used in chassis-based systems?
The converter functions effectively as a standalone device for individual conversion needs, but it is also compatible with the TRENDnet TFC-1600 fiber chassis. This allows multiple converters to be consolidated into a single managed unit for centralized power, monitoring, and administration in larger deployment scenarios requiring multiple copper-to-fiber conversion points.
What type of fiber connector does this converter use?
This media converter utilizes SC-type connectors for the fiber interface. The SC connector is a push-pull snap-in design that provides reliable connections with good repeatability, making it suitable for both permanent installations and applications where occasional reconfiguration might be necessary. The converter specifically supports dual-wavelength single-mode fiber with these connectors.
What warranty coverage does TRENDnet provide for this product?
TRENDnet backs the TFC-1000S40D3 with a 3 Year Lifetime warranty. This manufacturer's warranty covers defects in materials and workmanship under normal use, providing long-term assurance for network infrastructure investments. The warranty terms are detailed in the product documentation included with the converter.
