TRENDnet TI-PGM541 5-Port Industrial Gigabit PoE+ DIN-Rail Switch - 4 PoE+ Ports - 120W Budget - SFP Slot - Layer 2 - Metal Housing
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This industrial switch delivers full Gigabit Ethernet performance across all five ports, with four ports supporting IEEE 802.3at PoE+ to deliver up to 30W per port. The integrated 120W total PoE budget allows simultaneous powering of multiple high-demand devices such as IP cameras, wireless access points, VoIP phones, and sensors without external power injectors.
Network expansion and fiber connectivity are supported through a single SFP (mini-GBIC) slot, enabling uplinks to fiber optic backbones or long-distance copper runs. The switch adheres to key networking standards including IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3af, and 802.3at for broad compatibility.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TI-PGM541 stands out with its industrial-grade durability, high PoE budget, and flexible mounting options, providing a reliable networking foundation for critical applications.
Rugged Industrial Design
Metal construction and a wide operating temperature range ensure reliable performance in environments with vibration, dust, moisture, or extreme temperatures.
- Operates from -20°C to 65°C
- Metal housing for durability
- Terminal block power input
Substantial PoE+ Power
With a 120W PoE budget, this switch can power multiple high-wattage devices simultaneously, reducing the need for separate power supplies and simplifying infrastructure.
- 4 PoE+ ports (802.3at)
- Up to 30W per port
- Total budget: 120W
Deployment Flexibility
DIN-rail and wall-mount compatibility allow installation in control panels, enclosures, or directly on walls, adapting to space constraints in industrial or commercial settings.
- Includes mounting hardware
- Compact 5.12" x 7.09" footprint
- SFP slot for fiber uplinks
Deployment / Use Cases
This switch is purpose-built for environments where reliability, power delivery, and physical robustness are non-negotiable. Its industrial pedigree makes it suitable for applications beyond typical office networking.
In manufacturing and factory automation, the TI-PGM541 can power and connect IP cameras for surveillance, PLCs for control systems, and sensors for monitoring, all within harsh conditions. For outdoor or remote installations like traffic management systems, renewable energy sites, or agricultural monitoring, its wide temperature tolerance and durable build ensure continuous operation.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The switch features a compact metal chassis measuring 5.12" wide, 7.09" deep, and 1.10" high, with a weight of 1.47 pounds. Its design prioritizes durability and easy integration into industrial setups, with included DIN-rail clips and wall-mount hardware for secure installation in panels or on surfaces.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.10" (28 mm), 5.12" (130 mm), 7.09" (180 mm), 1.47 lb (668 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 5.12" (130 mm)
- Depth
- 7.09" (180 mm)
- Height
- 1.10" (28 mm)
- Weight
- 1.47 lb (668 g)
What's in the Box
The package includes all necessary components for immediate deployment.
Highlights
- 5-port industrial Gigabit switch with 4 PoE+ ports and 1 SFP uplink slot
- 120W total PoE budget supports high-power devices like PTZ cameras and Wi-Fi 6 access points
- Metal housing and wide operating temperature range (-20°C to 65°C) for harsh environments
- DIN-rail and wall-mount compatible with included hardware for flexible installation
- Layer 2 switching with support for key IEEE Ethernet and PoE standards
- Terminal block power input for secure industrial power connections
- Low 5W power consumption for energy-efficient operation
- TAA compliant for use in U.S. and Canadian government contracts
- Lifetime limited warranty for long-term reliability assurance
- Compact footprint (5.12" x 7.09" x 1.10") fits space-constrained enclosures
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TI-PGM541 |
| Brand Name | TRENDnet |
| Product Model | TI-PGM541 |
| Product Name | 5-port Industrial Gigabit PoE+ DIN-Rail Switch -20° - 65°C (-4° - 149°F) |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 5 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet PoE+,1 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-FX,1000Base-T |
| I/O Expansions | |
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 1 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3x,IEEE 802.3af,IEEE 802.3at |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 120 W |
| Power Source | AC/DC |
| Power Consumption | 5 W |
| Plug/Connector Type | Terminal Block |
| Physical Characteristics | |
| Product Material | Metal |
| Form Factor | DIN Rail Mountable,Wall Mountable |
| Height | 1.10" (28 mm) |
| Width | 5.12" (130 mm) |
| Depth | 7.09" (180 mm) |
| Weight (Approximate) | 1.47 lb (668 g) |
| Miscellaneous | |
| Package Contents | 5-port Industrial Gigabit PoE+ DIN-Rail Switch -20° - 65°C (-4° - 149°F) Quick Installation Guide Removable Terminal Block DIN-Rail and Wall-mount Hardware |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
How many PoE+ ports does this switch have, and what is the total PoE budget?
The TRENDnet TI-PGM541 has four Gigabit Ethernet ports that support IEEE 802.3at PoE+, delivering up to 30W per port. The total PoE budget is 120W, allowing the switch to power multiple high-demand devices such as IP cameras, wireless access points, or VoIP phones simultaneously without needing separate power supplies.
What type of uplink or expansion options are available on this switch?
This switch includes one SFP (mini-GBIC) slot for network expansion. This slot allows you to add a fiber optic or copper SFP module for uplinking to a network backbone, extending distance capabilities, or connecting to fiber infrastructure, providing flexibility beyond the built-in RJ-45 ports.
Is this switch suitable for industrial environments with extreme temperatures?
Yes, the TI-PGM541 is designed for industrial use with an operating temperature range of -20°C to 65°C (-4°F to 149°F). Its metal housing and robust construction ensure reliable performance in harsh conditions like factories, outdoor enclosures, or locations with significant temperature variations.
How is this switch mounted, and what mounting hardware is included?
The switch supports both DIN-rail and wall mounting. The package includes DIN-rail clips and wall-mount hardware, allowing easy installation in control panels, on walls, or in enclosures. This flexibility makes it ideal for space-constrained industrial or commercial settings where traditional rack mounting isn't feasible.
What networking standards does this switch support?
This switch complies with key IEEE standards including 802.3 (Ethernet), 802.3u (Fast Ethernet), 802.3ab/z (Gigabit Ethernet), 802.3x (flow control), 802.3af (PoE), and 802.3at (PoE+). It supports Layer 2 switching and media types such as twisted pair and optical fiber via the SFP slot, ensuring broad compatibility with existing network infrastructure.
What is the warranty for this industrial switch, and is it TAA compliant?
The TRENDnet TI-PGM541 comes with a lifetime limited warranty, providing long-term assurance of its durability and performance. It is also TAA compliant, meaning it meets the Trade Agreements Act requirements for use in U.S. and Canadian government contracts, ensuring it adheres to sourcing and manufacturing regulations.
