TRENDnet TI-RG262i 26-Port Industrial Gigabit L2 Managed Switch - 24 RJ-45 Ports - 2 SFP Slots - 1U Rackmount - Fanless
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch delivers full Gigabit performance across all 24 RJ-45 ports, supporting auto-negotiation for 10/100/1000Base-T connections. The two SFP slots accept 100/1000Base-FX fiber modules, enabling long-distance uplinks to network cores or connections between buildings. With a non-blocking switching capacity of 52Gbps, it ensures wire-speed forwarding for data-intensive applications.
Layer 2 management features include IEEE 802.1Q VLAN tagging for network segmentation, LACP for link aggregation, and STP/RSTP for loop prevention. Quality of Service is handled through IEEE 802.1p prioritization with queue scheduling, allowing critical traffic like VoIP or industrial control data to receive priority bandwidth. IGMP snooping and MVR support optimize multicast streaming for video surveillance or digital signage deployments.
Relevant factors for this section include Features, Total Number of Network Ports, Network (RJ-45), Port/Expansion Slot Details. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TI-RG262i stands out with its combination of industrial durability, flexible connectivity, and advanced management in a compact 1U footprint. Its fanless operation eliminates moving parts that can fail in dusty or harsh conditions, while the wide temperature tolerance ensures reliability in unregulated environments like warehouses or transportation hubs.
Robust Connectivity
24 copper Gigabit ports handle high-density device connections, while two SFP slots provide fiber uplink options for extending network reach or connecting to backbone switches.
- 24 x 10/100/1000Base-T RJ-45
- 2 x SFP slots for fiber modules
- Supports twisted pair and optical fiber
Advanced Management Suite
Full Layer 2 manageability through multiple access methods gives administrators precise control over network behavior, security policies, and traffic optimization.
- CLI via console, Telnet, or SSH
- Web-based HTTP management
- SNMP v1/v2c/v3 monitoring
Industrial-Grade Construction
The metal housing meets IP30 protection standards against solid objects, and the terminal block power connector ensures secure DC power input in vibration-prone installations.
- IP30-rated metal enclosure
- Terminal block power connector
- -40°C to 70°C operating range
Deployment / Use Cases
This switch is purpose-built for industrial and harsh environment networking where commercial-grade equipment may fail. Its rugged design and wide temperature range make it ideal for manufacturing automation, outdoor Wi-Fi backhaul, transportation systems, or energy sector applications where equipment must operate reliably in uncontrolled conditions.
In factory settings, it can connect PLCs, HMIs, and sensors while withstanding electrical noise and particulate contamination. For smart city deployments, it provides PoE connectivity for outdoor cameras and access points, with fiber uplinks to central offices. The 1U rack-mount form factor integrates seamlessly into control room cabinets or network racks, and redundant power supply support enables high-availability configurations for critical infrastructure.
Physical Profile
The switch occupies a single rack unit (1U) with dimensions of 17.32" wide by 11.18" deep and a low-profile height of 1.73". Its all-metal construction provides durability and effective heat dissipation without active cooling. Weighing 7.63 lb, it installs securely in standard 19" racks using the included mounting kit. The terminal block power connector accepts 48-57V DC input, compatible with industrial power supplies or UPS systems.
- Width
- 17.32" (440 mm)
- Depth
- 11.18" (284 mm)
- Height
- 1.73" (44 mm)
- Weight
- 7.63 lb (3460 g)
Highlights
- 24 Gigabit Ethernet RJ-45 ports for high-density device connections
- 2 SFP slots for fiber uplinks using 100/1000Base-FX modules
- 52Gbps non-blocking switching capacity ensures wire-speed performance
- Fanless design with IP30-rated metal housing for harsh environments
- Operates in extreme temperatures from -40°C to 70°C (-40°F to 158°F)
- Full Layer 2 management via CLI, web, and SNMP v1/v2c/v3
- Supports VLAN, LACP, STP/RSTP, IGMP snooping, and QoS prioritization
- 1U rack-mountable form factor with terminal block DC power input
- Redundant power supply support for high-availability deployments
- NDAA/TAA compliant with lifetime warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TI-RG262I |
| Brand Name | TRENDnet |
| Product Model | TI-RG262i |
| Product Name | 26-Port Industrial Gigabit L2 Managed Rackmount Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Fanless |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network,2 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X |
| Maximum Data Transfer Rate | 250 MB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3x,IEEE 802.3af,IEEE 802.3at |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Input Voltage | 48 V DC,57 V DC |
| Power Source | DC |
| Redundant Power Supply Supported | Yes |
| Power Consumption | 20 W |
| Plug/Connector Type | Terminal Block |
| Physical Characteristics | |
| Product Material | Metal |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.73" (44 mm) |
| Width | 17.32" (440 mm) |
| Depth | 11.18" (284 mm) |
| Weight (Approximate) | 7.63 lb (3460 g) |
User Manual
FAQ
How many ports does this switch have and what types are they?
The TRENDnet TI-RG262i has 26 total ports: 24 Gigabit Ethernet RJ-45 ports for copper connections and 2 SFP slots for fiber optic modules. The RJ-45 ports support 10/100/1000Base-T auto-negotiation, while the SFP slots accept 100/1000Base-FX fiber transceivers for uplink connections.
What does 'industrial' mean for this switch compared to standard switches?
Industrial designation indicates this switch is built for harsh environments. It features a fanless design to eliminate dust ingress points, operates across an extreme temperature range of -40°C to 70°C, and has an IP30-rated metal housing that protects against solid objects. These features ensure reliability in manufacturing, outdoor, or uncontrolled environments where commercial switches might fail.
What management options are available for this Layer 2 managed switch?
The switch offers comprehensive management through multiple interfaces: command-line interface (CLI) accessible via console port, Telnet, or SSH; web-based management through HTTP; and SNMP v1, v2c, and v3 for monitoring. This allows network administrators to configure VLANs, QoS, link aggregation, spanning tree, and security policies according to their network requirements.
Can this switch support Power over Ethernet (PoE) for connected devices?
No, the TI-RG262i does not provide Power over Ethernet. It is a non-PoE industrial switch designed for data connectivity in harsh environments. For PoE requirements in similar conditions, TRENDnet offers separate industrial PoE switch models with power budgeting capabilities.
What are the rack mounting specifications and physical dimensions?
The switch is 1U rack-mountable with dimensions of 17.32" wide, 11.18" deep, and 1.73" high (440 x 284 x 44 mm). It weighs 7.63 lb (3460 g) and includes mounting hardware for standard 19" racks. The compact 1U form factor maximizes rack space efficiency while the all-metal construction provides durability in industrial installations.
What power input does this switch require and does it support redundancy?
The switch uses 48-57V DC input through a terminal block connector, compatible with industrial power supplies. It supports redundant power supply configurations for high-availability deployments, allowing connection of a backup power source to maintain operation during primary power failures. The switch consumes approximately 20W under normal operation.
