TRENDnet TPE-219GI PoE++ Injector - 90W High Power - Wall Mountable - Single Port Gigabit
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The TPE-219GI operates as a midspan injector, accepting data input from a standard Gigabit Ethernet switch and outputting both data and power on a single RJ-45 connection. It supports the full IEEE 802.3bt Type 4 power classification, enabling it to deliver up to 90W to compatible powered devices (PDs). This makes it one of the highest-output single-port injectors available for commercial and industrial deployments.
Certifications include IEEE 802.3, 802.3u, 802.3ab, 802.3bz for Ethernet performance, along with CE, FCC, and ETL safety and emissions compliance. The unit automatically negotiates power requirements with connected PDs, preventing over-delivery and ensuring safe operation across mixed device environments.
Relevant factors for this section include Maximum Output Power, Input Ports, Output Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TPE-219GI addresses the growing need for high-power PoE in modern networks without requiring expensive switch upgrades. Its 90W capacity supports the latest high-performance devices that exceed traditional PoE+ limits, while its compact wall-mount design simplifies installation in space-constrained environments like telecom closets, ceiling plenums, or equipment racks.
High-Power Compatibility
Delivers up to 90W for IEEE 802.3bt Type 4 devices, plus backward compatibility with 802.3af (15.4W) and 802.3at (30W) equipment.
- Supports latest high-power endpoints
- Auto-negotiates power class
- Prevents over-delivery to older devices
Installation Flexibility
Wall-mountable form factor with included mounting hardware allows placement near power outlets and network drops, reducing cable runs and improving cable management.
- Compact footprint: 6.06" H x 2.87" W
- Includes power cord
- Quick installation guide provided
Deployment / Use Cases
The TPE-219GI is ideal for extending high-power PoE to locations where existing network infrastructure lacks sufficient PoE capacity. Its single-port design makes it perfect for point deployments where only one device requires enhanced power, avoiding the cost and complexity of multi-port solutions.
Common applications include powering 802.11ax Wi-Fi 6/6E access points with multiple radios and high-gain antennas, PTZ security cameras with heaters and blowers, digital signage displays with bright LEDs, and industrial IoT sensors with extended operational requirements. It also serves as a reliable backup power source for critical network devices during switch failures or maintenance windows.
High-Density Wireless
Power next-generation Wi-Fi 6/6E access points that require up to 90W for maximum throughput and client density in enterprise and education environments.
Advanced Surveillance
Support PTZ cameras with thermal imaging, infrared illuminators, and environmental controls that exceed standard PoE+ power budgets.
Physical Profile
The injector measures 6.06 inches in height, 2.87 inches in width, and 1.42 inches in depth (154 x 73 x 36 mm), with a weight of approximately 13.62 ounces (386 g). Its vertical orientation and wall-mount capability optimize space utilization in racks or on walls, while the matte finish resists fingerprints and blends into professional installations. The compact design minimizes airflow obstruction when mounted in enclosed spaces.
- Width
- 2.87" (73 mm)
- Depth
- 1.42" (36 mm)
- Height
- 6.06" (154 mm)
- Weight
- 13.62 oz (386 g)
What's in the Box
Each unit includes the TPE-219GI PoE++ Injector, a power cord, and a quick installation guide for immediate deployment.
Package contents include TPE-219GI PoE++ Injector Quick Installation Guide Power Cord, TPE-219GI PoE++ Injector. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 90W maximum output power for high-demand devices
- IEEE 802.3bt Type 4 PoE++ compatibility
- Backward compatible with 802.3af/at PoE/PoE+
- Single-port Gigabit Ethernet design
- Wall-mountable form factor with included hardware
- 3-year limited warranty from TRENDnet
- CE, FCC, and ETL certified for safety
- Compact dimensions: 6.06" H x 2.87" W x 1.42" D
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TPE-219GI |
| Brand Name | TRENDnet |
| Product Model | TPE-219GI |
| Product Name | TPE-219GI PoE++ Injector |
| Packaged Quantity | 20 / Case |
| Product Type | PoE++ Injector |
| Power Description | |
| Maximum Output Power | 90 W |
| Interfaces/Ports | |
| Input Ports | 1 x RJ-45 |
| Output Ports | 1 x RJ-45 |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Height | 6.06" (154 mm) |
| Width | 2.87" (73 mm) |
| Depth | 1.42" (36 mm) |
| Weight (Approximate) | 13.62 oz (386 g) |
| Miscellaneous | |
| Package Contents | TPE-219GI PoE++ Injector Quick Installation Guide Power Cord |
| Certifications & Standards | IEEE 802.3af IEEE 802.3at IEEE 802.3bt IEEE 802.3 IEEE 802.3u IEEE 802.3ab I IEEE 802.3bz CE FCC ETL |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum power output of the TPE-219GI PoE++ Injector?
The TPE-219GI delivers up to 90 watts of power, making it compliant with the IEEE 802.3bt Type 4 standard. This high output supports power-hungry devices like advanced Wi-Fi 6 access points, PTZ cameras with environmental controls, and digital signage that require more than traditional PoE+ limits.
Is this injector compatible with older PoE devices?
Yes, the TPE-219GI is fully backward compatible with IEEE 802.3af (15.4W) and 802.3at (30W) devices. It automatically negotiates the correct power class with connected equipment, ensuring safe operation without manual configuration or risk of over-delivery to lower-power endpoints.
How many devices can the TPE-219GI power simultaneously?
This is a single-port injector, meaning it powers one device at a time through its output RJ-45 port. It accepts data input from a standard Gigabit Ethernet switch on its input port and outputs combined data and power on the output port to a single compatible powered device.
What mounting options are available for this PoE injector?
The TPE-219GI is designed for wall mounting, with a form factor that includes mounting hardware in the package. Its compact vertical design allows installation in tight spaces like telecom closets, on walls near network drops, or in equipment racks using optional rack shelves or brackets.
What certifications does the TPE-219GI carry for safety and compliance?
The injector is certified to CE, FCC, and ETL standards for electrical safety and emissions. It also complies with IEEE 802.3, 802.3u, 802.3ab, and 802.3bz for Ethernet performance, ensuring reliable operation in commercial and industrial environments without interference.
What is included in the warranty for this PoE++ injector?
TRENDnet provides a 3-year limited warranty for the TPE-219GI, covering defects in materials and workmanship under normal use. This warranty supports business and institutional deployments where long-term reliability is critical, backed by TRENDnet's technical support and replacement services.
