TRENDnet TPE-TG82ES EdgeSmart 8-Port Gigabit PoE+ Managed Switch - 64W PoE Budget - Layer 2 - Wall Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This managed switch supports Gigabit Ethernet over twisted pair cabling (1000Base-T) across all eight ports, with each port capable of delivering PoE+ power up to the 64W total budget. The Layer 2 switching architecture enables essential network segmentation and traffic prioritization features, including support for static link aggregation, Rapid Spanning Tree Protocol (RSTP), VLANs, Quality of Service (QoS), and IGMP snooping.
Power consumption is rated at 68.60W under typical operation, and the switch includes bandwidth control per port for traffic management. The IEEE 802.1p Class of Service (CoS) with queue scheduling allows prioritization of latency-sensitive applications like voice and video, while the Voice VLAN feature optimizes performance for VoIP deployments.
Relevant factors for this section include Total Number of Network Ports, Modular, Port/Expansion Slot Details, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TPE-TG82ES offers a balance of power, management, and deployment flexibility. Its 64W PoE budget supports multiple powered devices, while the managed features allow network administrators to optimize performance and security. The durable construction and lifetime warranty provide long-term reliability for business networks.
Managed PoE+ Switching
Combines eight PoE+ ports with web-based management for VLANs, QoS, and link aggregation, providing control and power in one compact unit.
- 64W total PoE budget
- Voice VLAN for VoIP optimization
- Bandwidth control per port
Compact and Silent Design
Fanless metal housing operates silently and mounts on walls, ideal for offices, retail spaces, or environments where noise and space are concerns.
- Fanless for zero noise
- Wall-mountable metal housing
- Compact footprint: 6" W x 4" H x 8" D
Deployment / Use Cases
This switch is well-suited for environments requiring both data connectivity and device power over Ethernet. In small offices, it can connect workstations while powering wireless access points for extended coverage. For security installations, it provides PoE to IP cameras without separate power adapters, simplifying cabling.
The wall-mountable design allows installation in network closets, behind desks, or in retail kiosks where rack space is limited. Its fanless operation makes it appropriate for quiet areas like conference rooms or reception desks.
Small Office / Retail Networks
Ideal for connecting computers, printers, and PoE devices like IP phones or cameras in offices or retail stores, with managed features for network segmentation and traffic control.
VoIP and IP Telephony
Supports Voice VLAN and QoS to prioritize voice traffic, making it suitable for VoIP phone systems where clear call quality and network reliability are critical.
Physical Profile
The TPE-TG82ES features a compact metal housing measuring 6 inches wide, 4 inches high, and 8 inches deep (152.4 x 101.6 x 203.2 mm), with a weight of 2.53 pounds (1147.59 g). Its wall-mountable form factor includes mounting brackets for secure installation on vertical surfaces, and the fanless design ensures silent operation without moving parts. The switch is manufactured in Taiwan and is TAA compliant for U.S. and Canadian government procurement requirements.
- Width
- 6" (152.40 mm)
- Depth
- 8" (203.20 mm)
- Height
- 4" (101.60 mm)
- Weight
- 2.53 lb (1147.59 g)
- Length
- 6.73" (170.94 mm)
Highlights
- 8 Gigabit PoE+ ports with 64W total PoE budget
- Managed Layer 2 switch with web-based interface
- Supports VLAN, QoS, link aggregation, and RSTP
- Voice VLAN feature optimized for VoIP applications
- 16Gbps switching capacity for full wire-speed performance
- Fanless compact design with metal housing
- Wall-mountable for flexible deployment
- Lifetime warranty for long-term reliability
- TAA compliant for government procurement
- Bandwidth control per port for traffic management
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TPE-TG82ES |
| Brand Name | TRENDnet |
| Product Line | EdgeSmart |
| Product Model | TPE-TG82ES |
| Product Name | 8-Port Gigabit EdgeSmart PoE+ Switch (61W) |
| Product Condition | New |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Modular | No |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Power Description | |
| Power Consumption | 68.60 W |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Height | 4" (101.60 mm) |
| Width | 6" (152.40 mm) |
| Depth | 8" (203.20 mm) |
| Length | 6.73" (170.94 mm) |
| Weight (Approximate) | 2.53 lb (1147.59 g) |
| Miscellaneous | |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
How many PoE+ ports does this switch have, and what is the total PoE budget?
The TRENDnet TPE-TG82ES includes eight Gigabit Ethernet ports, all of which support PoE+ (Power over Ethernet Plus). The total PoE budget is 64W, which can be distributed across the ports to power devices like IP phones, wireless access points, or security cameras. This allows for flexible power allocation based on connected device requirements.
Is this a managed or unmanaged switch, and what management features are included?
This is a managed Layer 2 switch with a web-based management interface. It supports static link aggregation, Rapid Spanning Tree Protocol (RSTP), VLANs for network segmentation, Quality of Service (QoS) for traffic prioritization, IGMP snooping for multicast traffic, and bandwidth control per port. These features provide control over network performance and security in small business environments.
What is the switching capacity of the TPE-TG82ES?
The switch offers a switching capacity of 16 Gbps, which enables full wire-speed performance across all eight Gigabit ports simultaneously. This capacity ensures smooth data transfer for applications like file sharing, video streaming, and VoIP without bottlenecks, supporting high network throughput in busy environments.
Can this switch be wall-mounted, and what are its dimensions?
Yes, the TPE-TG82ES is designed for wall mounting with included brackets. Its dimensions are 6 inches wide, 4 inches high, and 8 inches deep (152.4 x 101.6 x 203.2 mm), and it weighs 2.53 pounds (1147.59 g). The compact, fanless metal housing makes it suitable for installation in tight spaces like network closets or behind desks.
Does this switch support Voice VLAN for VoIP applications?
Yes, the TPE-TG82ES includes a Voice VLAN feature that prioritizes voice traffic for VoIP phones and systems. This, combined with QoS and IEEE 802.1p Class of Service support, helps ensure clear call quality and reduced latency by giving voice packets higher priority over other network traffic, optimizing performance for telephony deployments.
What warranty does TRENDnet offer for this switch?
TRENDnet provides a lifetime warranty for the TPE-TG82ES, covering defects in materials and workmanship for the product's lifespan. This warranty underscores the switch's durability and reliability for long-term use in business networks, offering peace of mind for investments in network infrastructure.
