Tripp Lite by Eaton B119-4X2-4K 4 x 2 HDMI Matrix Switch/Splitter - 4K 3840 x 2160 - 4 Inputs - 2 Outputs - Video Switchbox
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This HDMI matrix switch delivers robust technical performance with four HDMI inputs and two HDMI outputs, supporting cable-based connectivity for seamless integration into existing AV setups. It handles 4K resolution at 3840x2160 and is backward compatible with 1080p content, ensuring broad compatibility with modern and legacy video sources. The device maintains signal integrity across all connections, eliminating manual cable swapping and reducing setup complexity.
Control options include IR remote with a 5-foot extension cable and RS-232 serial interface for integration into automated systems. The external power supply accepts 100-240V input, making it suitable for global deployment with included plug adapters for North America, U.K., Europe, and Australia.
Relevant factors for this section include Connectivity Technology, Number of Input Devices Supported, Device Supported, Graphics Modes. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The B119-4X2-4K offers distinct advantages for multi-display environments by combining high-resolution support with flexible source management. Its matrix switching capability allows independent routing of any input to any output, enabling tailored content delivery across two displays without compromising video quality.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include High-Resolution Performance, Flexible Control Options.
High-Resolution Performance
Supports 4K UHD at 3840x2160, delivering sharp, detailed video for digital signage, presentations, and entertainment applications.
- 4K graphics modes
- 1080p scan format compatibility
- No signal degradation
Flexible Control Options
Includes IR remote with extension cable and RS-232 adapter for versatile control in both manual and automated systems.
- IR remote included
- 5-foot extension cable
- RS-232 integration support
Deployment / Use Cases
The B119-4X2-4K is ideal for scenarios requiring dynamic video distribution across multiple displays. In digital signage networks, it enables content rotation from multiple media players to two screens, supporting retail advertising, corporate communications, and public information displays. For conference rooms or control centers, it allows presenters to switch between laptop, document camera, and Blu-ray sources across dual monitors or projectors.
Entertainment venues can use it to route gaming console or satellite receiver feeds to separate viewing areas, while educational institutions benefit from flexible source sharing in classrooms or labs. Its surface-mountable design and included mounting hardware facilitate clean installations in rack, wall, or desktop configurations.
Digital Signage Networks
Route content from multiple media players to dual displays for dynamic advertising or information boards.
Conference & Control Rooms
Switch between presentation sources like laptops and document cameras across two monitors or projectors.
Physical Profile
The switch features a compact, surface-mountable enclosure measuring 9.25" wide, 3.94" deep, and 1.17" high (234.95 x 100.08 x 29.72 mm), designed for discreet integration into AV racks, wall mounts, or desktop setups. Its low-profile design minimizes footprint while providing robust connectivity, and the included mounting hardware supports secure installation in various orientations.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.17" (29.72 mm), 9.25" (234.95 mm), 3.94" (100.08 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 9.25" (234.95 mm)
- Depth
- 3.94" (100.08 mm)
- Height
- 1.17" (29.72 mm)
What's in the Box
The package includes all necessary components for immediate deployment:
Highlights
- 4K UHD support at 3840x2160 resolution for high-quality video delivery
- 4 HDMI inputs and 2 HDMI outputs for flexible multi-source routing
- Matrix switching allows independent source selection for each display
- Includes IR remote with extension cable and RS-232 adapter for versatile control
- Surface-mountable form factor with included mounting hardware
- RoHS compliant and environmentally friendly design
- Three-year limited warranty for reliable long-term use
- Global power supply with international plug adapters (North America, U.K., Europe, Australia)
- Supports devices like displays, digital signage, computers, Blu-ray players, gaming consoles, and satellite receivers
- Compact dimensions: 9.25" x 3.94" x 1.17" (234.95 x 100.08 x 29.72 mm)
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | B119-4X2-4K |
| Brand Name | Tripp Lite series |
| Product Model | B119-4X2-4K |
| Product Name | B119-4X2-4K 4x2 HDMI Matrix Switch/Splitter |
| Product Type | Video Switchbox |
| Technical Information | |
| Connectivity Technology | Cable |
| Number of Input Devices Supported | 2 |
| Device Supported | Display,Digital Signage,Computer,Blu-ray Disc Player,Gaming Console,Satellite Receiver |
| Number of Displays Supported | 2 |
| Video | |
| Graphics Modes | 4K |
| Maximum Video Resolution | 3840 x 2160 |
| Scan Format | 1080p |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| Connectivity (RJ-45) | No |
| Number of HDMI Inputs | 4 |
| Number of HDMI Outputs | 2 |
| Physical Characteristics | |
| Form Factor | Surface-mountable |
| Height | 1.17" (29.72 mm) |
| Width | 9.25" (234.95 mm) |
| Depth | 3.94" (100.08 mm) |
| Miscellaneous | |
| Package Contents | B119-4X2-4K 4x2 HDMI Matrix Switch/Splitter IR Remote Control IR Extension Cable, 5 ft. (1.5 m) RS-232 Phoenix Adapter External Power Supply (Input:100-240V, 50/60 Hz, 0.35A;Output: 5V 2A) 4 x International Plug Adapters (North America, U.K., Europe, Australia) Mounting Hardware Owner's Manual |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum video resolution supported by the B119-4X2-4K?
The B119-4X2-4K supports 4K Ultra HD resolution at 3840 x 2160 pixels, ensuring high-definition video quality for digital signage, presentations, and entertainment content. It is also compatible with 1080p scan formats for backward compatibility with older devices.
How many HDMI inputs and outputs does this matrix switch have?
This switch features four HDMI inputs and two HDMI outputs. The four inputs allow connection of multiple source devices like computers, Blu-ray players, or gaming consoles, while the two outputs enable simultaneous feeding to two displays with independent source selection for each.
What control options are included with the B119-4X2-4K?
The switch includes an IR remote control with a 5-foot extension cable for convenient manual operation, plus an RS-232 Phoenix adapter for integration into automated control systems. This dual-control capability supports flexible deployment in both simple and complex AV setups.
Is the B119-4X2-4K suitable for international use?
Yes, it includes a universal power supply that accepts 100-240V input at 50/60 Hz, along with four international plug adapters for North America, U.K., Europe, and Australia. This makes it ready for global deployment without additional power accessories.
What types of devices can be connected to this HDMI matrix switch?
It supports a wide range of HDMI source devices including displays, digital signage players, computers, Blu-ray disc players, gaming consoles, and satellite receivers. This versatility makes it ideal for commercial, educational, and entertainment applications requiring multi-source video distribution.
What warranty and compliance certifications does this product have?
The B119-4X2-4K comes with a three-year limited warranty and is RoHS (Restriction of Hazardous Substances) compliant, ensuring it meets environmental standards. It is also TAA compliant and manufactured in Taiwan, supporting use in government and institutional procurement where such certifications are required.
