APC by Schneider Electric IBAR12-20T Rackmount Surge Protector - 12 NEMA 5-20R Outlets - 3840J - 15ft Cord
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This surge protector operates at 120 V AC input and output, matching standard North American power configurations. The 3840-joule surge energy rating indicates a high capacity for absorbing transient energy, helping to safeguard sensitive electronics from potential damage due to power surges.
The unit features a 15-foot power cord, providing flexibility in placement relative to power sources. Its compact form factor, measuring 17.50 inches wide, 4 inches deep, and 1.75 inches high, is optimized for rackmount deployment without excessive depth consumption.
This section brings together practical product details such as Plug/Connector Type, Receptacles, Input Voltage, Output Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The IBAR12-20T combines high-density power distribution with substantial surge protection in a rack-optimized design. Its 12 outlets, split between front and rear mounting, allow for organized cable management and easy access to frequently used connections.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Durable Construction, Installation Flexibility.
Durable Construction
The all-metal housing provides physical durability and helps dissipate heat, while integrated LEDs offer at-a-glance status monitoring for power and protection circuits.
- All-metal housing
- LED status indicators
Installation Flexibility
Adjustable rackmount hardware accommodates various rack depths and mounting positions, ensuring a secure fit in 19-inch rack enclosures commonly used in IT infrastructure.
- Adjustable rack hardware
- 19-inch rack compatible
Deployment / Use Cases
This surge protector is ideal for environments where multiple devices require both power distribution and surge protection in a rack-mounted configuration. Its 12-outlet capacity suits small to medium server setups, network equipment racks, or AV installations where organized power management is essential.
Common applications include data center racks housing servers, switches, and storage devices; network closets with routers and patch panels; and broadcast or studio racks containing audio/video equipment. The 15-foot cord length allows placement flexibility when power sources are not immediately adjacent to the rack.
This section brings together practical product details such as Plug/Connector Type, Receptacles, Input Voltage, Output Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The IBAR12-20T features a low-profile design at 1.75 inches high, minimizing vertical space usage in rack enclosures. Its 17.50-inch width matches standard rack widths, while the 4-inch depth allows installation in racks with limited depth clearance. The all-metal construction provides durability in rack environments where equipment may be frequently accessed or reconfigured.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.75" (44.45 mm), 17.50" (444.50 mm), 4" (101.60 mm), 5.40 lb (2449.40 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.50" (444.50 mm)
- Depth
- 4" (101.60 mm)
- Height
- 1.75" (44.45 mm)
- Weight
- 5.40 lb (2449.40 g)
- Length
- 15 ft (4.57 m)
What's in the Box
The package includes the IBAR12-20T surge suppressor unit along with warranty information and an instruction manual for proper installation and usage guidance.
Package contents include IBAR12-20T IBAR12-20T Surge Suppressor Warranty information Instruction manual, IBAR12-20T. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 12 NEMA 5-20R outlets (2 front, 10 rear mounted)
- 3840-joule surge energy rating for equipment protection
- 15-foot power cord for placement flexibility
- All-metal housing with LED status indicators
- Adjustable rackmount hardware for 19-inch racks
- Lifetime limited warranty
- 120 V AC input and output voltage
- Compact dimensions: 17.50" W x 4" D x 1.75" H
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | IBAR12-20T |
| Brand Name | Tripp Lite series |
| Product Name | IBAR12-20T |
| Product Type | Surge Suppressor/Protector |
| Technical Information | |
| Plug/Connector Type | Yes |
| Receptacles | 12 x NEMA 5-20R |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Surge Energy Rating | 3840 J |
| Physical Characteristics | |
| Power Cord/Cable Length | 15 ft (4.57 m) |
| Height | 1.75" (44.45 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 4" (101.60 mm) |
| Weight (Approximate) | 5.40 lb (2449.40 g) |
| Miscellaneous | |
| Package Contents | IBAR12-20T IBAR12-20T Surge Suppressor Warranty information Instruction manual |
| Country of Origin | Philippines |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
How many outlets does the IBAR12-20T have and what type are they?
The IBAR12-20T provides 12 NEMA 5-20R outlets. These are standard 120V, 20-amp receptacles commonly used in North America for office and IT equipment. The outlets are arranged with 2 on the front and 10 on the rear for flexible cable management in rack environments.
What is the surge protection rating of this unit?
This surge protector has a 3840-joule surge energy rating. This rating indicates its capacity to absorb transient voltage spikes, helping to protect connected electronics from potential damage caused by power surges or lightning-induced transients.
Is this surge protector designed for rack mounting?
Yes, the IBAR12-20T is specifically designed for rackmount installation. It includes adjustable rackmount hardware that fits standard 19-inch rack enclosures, making it suitable for data centers, server rooms, and network closets where organized power distribution is required.
What is the length of the power cord?
The unit comes with a 15-foot (4.57-meter) power cord. This length provides flexibility in positioning the surge protector relative to power sources, which is particularly useful in rack environments where power outlets may not be immediately adjacent to the equipment.
What warranty coverage does this product include?
The IBAR12-20T comes with a lifetime limited warranty. This warranty covers defects in materials and workmanship for the life of the product, providing long-term assurance of quality and reliability for your power protection investment.
What are the physical dimensions of this surge protector?
The unit measures 17.50 inches wide, 4 inches deep, and 1.75 inches high. These compact dimensions are optimized for rackmount deployment, with the width matching standard 19-inch rack widths and the low profile minimizing vertical space consumption in rack enclosures.
What power capacity is listed for this UPS?
Power specifications help show where the unit fits best, including the type of load level, electrical environment, and backup role it is intended to support. These are usually the most decision-critical facts in a UPS or power-protection comparison.
What voltage details are listed?
The listed power specification is 120 V AC, which helps position the unit for the right load level and installation role.
