Tripp Lite by Eaton PS7224-20 Tripp Lite Power Strip - 24 Outlets - 22x NEMA 5-15R - 2x NEMA 5-20R - 120V AC - 20A - 15 ft Cord - Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This power strip operates on standard 120V AC input with a maximum current rating of 20A, supporting a power rating of 2.40 kW. It accepts a NEMA 5-20P plug and distributes power through 22 NEMA 5-15R and 2 NEMA 5-20R outlets, accommodating a mix of common equipment plugs.
The design includes a 15-foot power cord for flexible placement, and outlets are spaced 2.80 inches apart to prevent bulky adapters from blocking adjacent ports. Electrical protection is handled by a built-in circuit breaker, and the unit functions at a maximum frequency of 60 Hz.
This section brings together practical product details such as Plug/Connector Type, Receptacles, Receptacles Spacing, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The PS7224-20 excels in environments where space efficiency and outlet density are priorities. Its vertical 0U rack-mount design saves valuable rack space while placing 24 outlets within easy reach, eliminating the need for multiple power strips.
High-Density Outlet Layout
With 24 outlets in a 72-inch length, this strip maximizes power access per rack unit, ideal for densely packed server and network installations.
- 22 standard NEMA 5-15R outlets
- 2 higher-capacity NEMA 5-20R outlets
- 2.80-inch outlet spacing
Integrated Safety & Control
The built-in 20-amp circuit breaker and master power switch provide essential overload protection and convenient centralized power control.
- 20A circuit breaker
- On/off switch
- Metal construction
Deployment / Use Cases
This power strip is tailored for structured IT deployments where organized power distribution is necessary. Its rack-mountable form factor and high outlet count make it suitable for server racks, network cabinets, and audio-visual equipment racks.
Common applications include data center server racks, network operation centers, telecom infrastructure cabinets, and broadcast equipment setups. The 15-foot cord allows for placement flexibility, and the vertical mounting saves horizontal rack space.
This section brings together practical product details such as Plug/Connector Type, Receptacles, Receptacles Spacing, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Data Center Server Racks
Provide centralized power to multiple servers, switches, and storage units within a single rack, reducing cable clutter and improving accessibility.
Network Equipment Cabinets
Power routers, switches, and patch panels efficiently with the high-density outlet layout and rack-optimized design.
Physical Profile
The PS7224-20 features a slim profile with dimensions of 1.50 inches in height and width, and a depth of 72 inches. Its vertical 0U rack-mount design allows installation along the side of a rack without consuming standard rack units. The metal construction ensures durability, and the silver and black finish offers a professional appearance. Weighing approximately 6.50 pounds, it is manageable for installation while remaining sturdy in place.
- Width
- 1.50" (38.10 mm)
- Depth
- 72" (1828.80 mm)
- Height
- 0U
- Weight
- 6.50 lb (2948.35 g)
- Length
- 15 ft (4.57 m)
What's in the Box
The package includes the power strip along with necessary mounting hardware and an instruction manual for straightforward installation.
Package contents include Power Strip 120V AC Mounting hardware Instruction manual, Power Strip 120V AC. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 24 total outlets (22 NEMA 5-15R, 2 NEMA 5-20R) for high-density power distribution
- 20-amp circuit breaker and on/off switch for safety and control
- 15-foot power cord provides flexible placement options
- Rack-mountable 0U vertical design saves rack space
- Metal construction in silver and black for durability
- 72-inch length with 2.80-inch outlet spacing accommodates bulky plugs
- 120V AC operation with 2.40 kW power rating
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | PS7224-20 |
| Brand Name | Tripp Lite series |
| Product Name | Power Strip 120V AC |
| Product Type | Power Strip |
| Technical Information | |
| Plug/Connector Type | NEMA 5-20P |
| Receptacles | 22 x NEMA 5-15R,2 x NEMA 5-20R |
| Receptacles Spacing | 2.80" (70.99 mm) |
| Cord Length | 15 ft (4.57 m) |
| Circuit Breaker | Yes |
| Power Description | |
| Input Voltage | 120 V AC |
| Maximum Output Voltage | 120 V AC |
| Maximum Input Current | 20 A |
| Maximum Frequency | 60 Hz |
| Power Switch | Yes |
| Power Rating | 2.40 kW |
| Physical Characteristics | |
| Color Family | Dual Color |
| Product Color | Silver,Black |
| Product Material | Metal |
| Form Factor | Rack-mountable |
| Rack Height | 0U |
| Mount Type | Vertical |
| Height | 1.50" (38.10 mm) |
| Width | 1.50" (38.10 mm) |
| Depth | 72" (1828.80 mm) |
| Weight (Approximate) | 6.50 lb (2948.35 g) |
| Miscellaneous | |
| Package Contents | Power Strip 120V AC Mounting hardware Instruction manual |
| Country of Origin | Vietnam |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
How many outlets does the Tripp Lite PS7224-20 power strip have?
The PS7224-20 provides 24 outlets total: 22 are standard NEMA 5-15R outlets, and 2 are higher-capacity NEMA 5-20R outlets. This high-density layout is designed for IT environments where multiple devices need power within a single rack or cabinet.
What is the input voltage and current rating for this power strip?
This power strip operates on 120V AC input with a maximum input current of 20 amps. It supports a power rating of 2.40 kW, making it suitable for powering multiple servers, networking equipment, or other rack-mounted devices in standard North American electrical environments.
Is the PS7224-20 rack-mountable, and what are its mounting specifications?
Yes, it is designed for rack mounting with a vertical 0U form factor. This means it mounts along the side of a standard 19-inch rack without consuming any rack units, saving space for equipment. It includes mounting hardware for straightforward installation in server racks or network cabinets.
Does this power strip include any safety features?
The PS7224-20 includes a 20-amp circuit breaker for overload protection and a master on/off switch for convenient power control. The metal construction also adds durability, and the outlet spacing of 2.80 inches helps prevent larger plugs from blocking adjacent outlets.
What is the length of the power cord, and how long is the strip itself?
The power cord is 15 feet (4.57 meters) long, offering flexibility in placement relative to power sources. The strip body has a depth of 72 inches (1828.80 mm), with a slim profile of 1.50 inches in height and width, making it compact yet capable of housing 24 outlets.
What warranty coverage does Tripp Lite offer for this power strip?
Tripp Lite provides a lifetime limited warranty for the PS7224-20, ensuring long-term reliability and support. This warranty covers defects in materials and workmanship, reflecting the product's durable metal construction and design for continuous use in IT environments.
What power capacity is listed for this UPS?
Power specifications help show where the unit fits best, including the type of load level, electrical environment, and backup role it is intended to support. These are usually the most decision-critical facts in a UPS or power-protection comparison.
What voltage details are listed?
The listed power specification is 120 V AC, which helps position the unit for the right load level and installation role.
