Tripp Lite by Eaton OMNIVS800 OMNIVS800800VA Line-Interactive UPS - Tower - 475W - 6 Battery Outlets + 1 Surge - USB - 110V/120V
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This line-interactive UPS employs pulse-width modulated sine wave output to deliver clean, regulated power to connected equipment. The 800VA/475W capacity supports typical office devices including desktop computers, networking gear, and point-of-sale systems. Voltage regulation circuitry actively corrects under-voltage conditions without switching to battery power, extending runtime availability during common power fluctuations.
The battery subsystem utilizes lead-acid chemistry with a six-year typical battery life and four-hour recharge time after complete discharge. Status indicators provide clear visual feedback for line power, battery operation, low battery conditions, and voltage regulation activity. An audible alarm alerts users during utility power failures and when operating on battery power.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The OMNIVS800 delivers essential power protection with features specifically optimized for business continuity. Its intelligent design balances runtime capacity with practical deployment considerations for typical office environments.
Intelligent Voltage Management
Corrects brownouts as low as 89V without consuming battery power, preserving runtime for actual outages while protecting equipment from under-voltage damage.
- Active voltage regulation
- Extended battery life
- Reduced maintenance cycles
Comprehensive Outlet Protection
Six battery-backed outlets provide runtime protection for critical devices, while one dedicated surge-only outlet offers basic protection for less essential equipment.
- 6 UPS-supported outlets
- 1 surge-only outlet
- NEMA 5-15R compatibility
Integrated Connectivity Options
USB connectivity enables communication with connected systems for automated shutdown procedures, while RJ-45 ports protect network connections from power surges.
- USB management port
- RJ-45 dataline protection
- Graceful shutdown support
Deployment / Use Cases
The OMNIVS800 is engineered for small to medium business environments where reliable power protection is essential but extensive runtime requirements are not necessary. Its 800VA capacity and tower form factor make it particularly suitable for individual workstations, point-of-sale systems, and network infrastructure components.
In retail settings, this UPS can protect cash registers, barcode scanners, and receipt printers during brief power interruptions. For office deployments, it provides sufficient runtime for desktop computers, monitors, and VoIP phones to complete graceful shutdowns or continue operation through short outages. The compact tower design allows placement directly under desks or on shelves near protected equipment.
Workstation Protection
Provides sufficient runtime for desktop computers and peripherals to complete work and shut down properly during power failures.
Network Infrastructure Support
Protects routers, switches, and modems to maintain network connectivity during brief outages that might otherwise disrupt communications.
Physical Profile
The black tower enclosure measures 10.75" high × 5.25" wide × 7.25" deep (273.05 × 133.35 × 184.15 mm) with a weight of approximately 21.20 pounds (9616.16 g). This compact footprint requires minimal desk or floor space while providing stable placement for the unit. The six-foot (1.83 m) NEMA 5-15P input cord offers flexible positioning relative to wall outlets.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 10.75" (273.05 mm), 5.25" (133.35 mm), 7.25" (184.15 mm), 21.20 lb (9616.16 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 5.25" (133.35 mm)
- Depth
- 7.25" (184.15 mm)
- Height
- 10.75" (273.05 mm)
- Weight
- 21.20 lb (9616.16 g)
- Length
- 6 ft (1.83 m)
What's in the Box
The package includes the complete UPS unit with all necessary components for immediate deployment.
Highlights
- 800VA/475W line-interactive UPS with tower form factor
- Corrects brownouts as low as 89V without using battery power
- 6 battery-supported outlets plus 1 surge-only outlet
- USB connectivity for system communication and graceful shutdown
- RJ-45 dataline protection for network connections
- Pulse-width modulated sine wave output
- 4-hour battery recharge time after complete discharge
- 6-year typical battery life
- NEMA 5-15P input plug with 6-foot cord
- 3-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | OMNIVS800 |
| Brand Name | Tripp Lite series |
| Product Series | VS |
| Product Name | OMNIVS800 800VA UPS |
| Product Type | Line-interactive UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 6 x NEMA 5-15R,1 x NEMA 5-15R |
| Dataline Protection | RJ-45 |
| Cord Length | 6 ft (1.83 m) |
| Power Description | |
| Load Capacity (VA) | 800 VA |
| Load Capacity (Watt) | 475 W |
| Input Voltage | 110 V AC |
| Output Voltage | 120 V AC |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Surge Energy Rating | 480 J |
| Management | |
| Alarm | On Battery,Utility Power Failure |
| Controls/Indicators | |
| Status Indicators | Line Power Battery Power Battery Low/Replace Voltage Regulation operation |
| Interfaces/Ports | |
| USB | Yes |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3.50 Minute |
| Backup/Run Time (Half Load) | 11.50 Minute |
| Battery Life | 6 Year |
| Typical Battery Recharge Time | 4 Hour |
| Environmental Conditions | |
| Maximum Operating Temperature | 122°F (50°C) |
| Physical Characteristics | |
| Product Color | Black |
| Height | 10.75" (273.05 mm) |
| Width | 5.25" (133.35 mm) |
| Depth | 7.25" (184.15 mm) |
| Form Factor | Tower |
| Weight (Approximate) | 21.20 lb (9616.16 g) |
| Miscellaneous | |
| Package Contents | OMNIVS800 800VA UPS USB and telephone cable User manual with warranty information |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the actual runtime I can expect from this UPS?
At full 475W load, the OMNIVS800 provides approximately 3.5 minutes of runtime. At half load (237.5W), runtime extends to approximately 11.5 minutes. These figures allow sufficient time for graceful shutdown of connected equipment or continuation through brief power interruptions.
How many devices can I connect to this UPS?
The unit features seven total outlets: six NEMA 5-15R outlets that provide both battery backup and surge protection, plus one additional NEMA 5-15R outlet that offers surge protection only. This configuration allows you to prioritize critical equipment on the battery-backed outlets while protecting less essential devices with basic surge suppression.
What type of power correction does this UPS provide?
This is a line-interactive UPS that employs active voltage regulation to correct brownouts as low as 89V without switching to battery power. It delivers pulse-width modulated sine wave output, which provides cleaner power than basic stepped approximations while maintaining efficiency for typical office equipment.
How do I manage this UPS with connected computers?
The integrated USB port enables communication between the UPS and connected systems. Compatible software can monitor power status, initiate graceful shutdown procedures during extended outages, and provide runtime estimates based on current load conditions.
What is the recharge time after a complete battery discharge?
The battery typically recharges to 90% capacity within four hours after a complete discharge. This relatively quick recharge time minimizes downtime between power events and ensures the UPS is ready to protect equipment again promptly.
Is this UPS suitable for rack mounting?
No, the OMNIVS800 features a tower form factor designed for under-desk, shelf, or floor placement. Its dimensions (10.75"H × 5.25"W × 7.25"D) and 21.2-pound weight make it portable between locations while providing stable placement in office environments.
What power capacity is listed for this UPS?
The listed power specification is 800 VA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 110 V AC, which helps position the unit for the right load level and installation role.
