Tripp Lite by Eaton PINV2000SWL-120 2000W Light-Duty Compact Power Inverter - 12V DC to 120V AC Pure Sine Wave - 2x NEMA 5-15/20R Outlets
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This section brings together practical product details such as Plug/Connector Type, Receptacles, Input Voltage, Output Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Pure Sine Wave Output
Generates clean, stable AC power that matches utility-grade electricity, ensuring compatibility with sensitive electronics like laptops, medical equipment, and variable-speed motors without risk of damage or performance issues.
High-Efficiency Conversion
Converts 12V DC input to 120V AC output with optimized efficiency, minimizing power loss and heat generation during continuous operation at rated loads.
Key Product Advantages
This power inverter combines robust power delivery with user-centric features that enhance operational flexibility and safety in demanding environments.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Wired Remote Control, Comprehensive Protection.
Wired Remote Control
The included PINVSWRM wired remote kit allows power control from the cab of a vehicle or a convenient location, enabling safe operation without direct access to the inverter unit.
- Remote on/off control
- Extended reach installation
- Integrated status indicators
Comprehensive Protection
Built-in safeguards including GFCI outlets, overload protection, and thermal management ensure reliable operation and equipment safety under varying load conditions.
- GFCI outlet protection
- Overload shutdown
- Thermal cutoff
Deployment / Use Cases
The PINV2000SWL-120 is designed for scenarios where reliable AC power is needed but traditional grid connections are unavailable or impractical. Its light-duty construction and mobile-friendly features make it ideal for temporary power solutions.
Common applications include construction sites where power tools and temporary lighting require AC power, mobile offices in vehicles or trailers needing to run computers and peripherals, and emergency backup situations where essential equipment must remain operational. The compact design also suits marine applications, food trucks, and remote monitoring stations.
Mobile Work Environments
Provides AC power for tools, lighting, and equipment in service vehicles, utility trucks, or temporary work sites without access to grid power.
Remote Operations
Supports electronic equipment in field offices, monitoring stations, or emergency response vehicles where reliable power is critical for continuous operation.
Physical Profile
With dimensions of 4" high, 15.36" wide, and 9.82" deep, this compact inverter minimizes space requirements while delivering substantial power capacity. The 12.19 lb weight and included mounting hardware facilitate secure installation in vehicles, equipment racks, or wall-mounted configurations. The design prioritizes heat dissipation and durability in mobile environments where vibration and temperature fluctuations are common.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4" (101.60 mm), 15.36" (390.14 mm), 9.82" (249.43 mm), 12.19 lb (5529.29 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 15.36" (390.14 mm)
- Depth
- 9.82" (249.43 mm)
- Height
- 4" (101.60 mm)
- Weight
- 12.19 lb (5529.29 g)
What's in the Box
The package includes all components necessary for immediate deployment and operation.
Highlights
- 2000W continuous/4000W peak pure sine wave output for sensitive electronics
- Converts 12V DC to 120V AC with 60Hz frequency stability
- Two NEMA 5-15/20R GFCI outlets provide versatile equipment connection
- Integrated USB charging ports for smartphones, tablets, and laptops
- Includes PINVSWRM wired remote kit for convenient power control
- Compact design measures 4"H x 15.36"W x 9.82"D for space-constrained installations
- Comprehensive package includes all necessary cables and mounting hardware
- RoHS compliant and backed by a 2-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | PINV2000SWL-120 |
| Brand Name | Tripp Lite series |
| Product Model | PINV2000SWL-120 |
| Product Name | PINV2000SWL-120 2000W Light-Duty Compact Power Inverter |
| Product Type | Power Inverter |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15/20R |
| Receptacles | 2 x NEMA 5-15/20R |
| Power Description | |
| Input Voltage | 12 V DC |
| Output Voltage | 120 V AC |
| Maximum Frequency | 60 Hz |
| Peak Power Load | 4 kW |
| Continuous Power Load | 2 kW |
| Waveform Type | Pure Sine Wave |
| Physical Characteristics | |
| Height | 4" (101.60 mm) |
| Width | 15.36" (390.14 mm) |
| Depth | 9.82" (249.43 mm) |
| Weight (Approximate) | 12.19 lb (5529.29 g) |
| Miscellaneous | |
| Package Contents | PINV2000SWL-120 2000W Light-Duty Compact Power Inverter 4 x DC Battery Cables with Ring Terminals, 18 in. (45.7 cm) Ground Wire with Clamp PINVSWRM Wired Remote Kit Mounting Hardware Owner's Manual |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What type of power output does this inverter provide?
The PINV2000SWL-120 generates pure sine wave AC power, which matches the quality of utility grid electricity. This clean power output is essential for sensitive electronics like computers, medical equipment, and variable-speed motors that can be damaged or perform poorly with modified sine wave inverters.
What is the difference between continuous and peak power ratings?
The continuous power rating of 2000W represents the sustained load the inverter can handle indefinitely under normal operating conditions. The peak power rating of 4000W indicates the maximum short-term load capacity, typically needed for starting motors or equipment with high initial power demands that last only a few seconds.
What types of equipment can I power with this inverter?
This inverter can power a wide range of 120V AC equipment including power tools, lighting, small appliances, computers, and electronic devices. The pure sine wave output makes it particularly suitable for sensitive electronics that require clean power, while the 2000W continuous capacity handles most light-duty applications effectively.
How do I connect the inverter to a power source?
The inverter connects to a 12V DC power source using the included battery cables with ring terminals. These cables attach directly to battery terminals, while the ground wire with clamp provides proper grounding. The package includes all necessary hardware for secure electrical connections following standard installation practices.
What is the purpose of the wired remote kit?
The included PINVSWRM wired remote kit allows you to control the inverter's power from a convenient location, such as the cab of a vehicle or a nearby workstation. This provides safe and accessible operation without needing physical access to the inverter unit itself, which is particularly valuable in mobile or confined installations.
What safety features does this inverter include?
Safety features include GFCI-protected outlets that prevent electrical shock hazards, overload protection that automatically shuts down the unit if connected equipment exceeds rated capacity, and thermal management that prevents overheating during extended operation. These protections ensure safe operation for both the equipment and users.
What power capacity is listed for this UPS?
Power specifications help show where the unit fits best, including the type of load level, electrical environment, and backup role it is intended to support. These are usually the most decision-critical facts in a UPS or power-protection comparison.
What voltage details are listed?
The listed power specification is 12 V DC, which helps position the unit for the right load level and installation role.
