Tripp Lite series SmartOnline SU2200RTXLCDN 2000VA Rack/Tower UPS - 2U Rack/Tower - 3 Hour Recharge - 7.70 Minute Stand-by - 120 V AC (SU2200RTXLCDN)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- SmartOnline SU2200RTXLCDN 2000VA Rack/Tower UPS
- WEBCARDLXE Network Management Card
- USB Cable
- DB9 RS232 Cable
- Rack-mounting Hardware
- Tower Support Stands
- Safety Instructions
- Quick Start Guide
Plug/Connector Type: NEMA 5-15P
Receptacle Type: NEMA 5-20R,NEMA L5-20R
Receptacle Detail: 6 x NEMA 5-20R,1 x NEMA L5-20R
Overload Protection: Yes
Transfer Time: 0 ns
EMI/RFI Noise Filter: Yes
Phase: Single Phase
Energy Saving: High efficiency economy mode operation; Individually controllable load banks
Application/Usage: Education,Healthcare,Military,Government,IT Equipment,Mission Critical Equipment
Load Capacity (VA): 2 kVA
Load Capacity (Watt): 1.80 kW
Input Voltage: 120 V AC
Output Voltage: 100 V AC,110 V AC,115 V AC,120 V AC,127 V AC
Input Frequency: 60 Hz
Output Frequency: 60 Hz
Waveform Type: Pure Sine Wave
Surge Energy Rating: 190 J
Input Power Factor: 0.99
Output Power Factor: 0.9
Display: LCD
Network Management: SNMP
Alarm: Remote Shutdown,UPS StartUp,Power Failure,Overload,UPS Fault,Low Battery
Status Indicators: 4 x status-indicating LEDs
Serial Port: Yes
USB: Yes
DC System Voltage: 72 V DC
Battery Characteristics: Valve-regulated
Battery Chemistry: Lead Acid
Backup/Run Time (Full Load): 7.70 Minute
Backup/Run Time (Half Load): 20.20 Minute
Hot Swappable: Yes
Typical Battery Recharge Time: 3 Hour
Replaceable Battery: Yes
Maximum Operating Elevation: 9842.52 ft (3000000 mm)
Storage Temperature: 32°F (0°C) - 104°F (40°C)
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Sound Emission: 47 dB
Height: 3.41" (86.61 mm)
Width: 17.33" (440.18 mm)
Depth: 23.82" (605.03 mm)
Rack Height: 2U
Form Factor: Rack/Tower
Weight (Approximate): 61.51 lb (27900.47 g)
Package Contents:
Energy Star: Yes
Country of Origin: Philippines
Environmentally Friendly: Yes
Environmental Compliance: Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS)
Limited Warranty: 2 Year
- Updated design for 2023
- Protects equipment against blackouts, brownouts, transient surges and line noise
- Keeps equipment running during outages to allow time for file saves and safe shutdown
- Zero transfer time between on-line and battery modes for uninterrupted operation
- Included WEBCARDLXE network card enables full remote access and control 24/7
- Menu-driven LCD keeps you up to date with status info and other vital analytics
[custom-specifications]
| Specifications | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SU2200RTXLCDN |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Brand Name | Tripp Lite series |
| Product Line | SmartOnline |
| Product Model | SU2200RTXLCDN |
| Product Name | SmartOnline SU2200RTXLCDN 2000VA Rack/Tower UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-20R,NEMA L5-20R |
| Receptacle Detail | 6 x NEMA 5-20R,1 x NEMA L5-20R |
| Overload Protection | Yes |
| Transfer Time | 0 ns |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Energy Saving | High efficiency economy mode operation; Individually controllable load banks |
| Application/Usage | Education,Healthcare,Military,Government,IT Equipment,Mission Critical Equipment |
| Power Description | |
| Load Capacity (VA) | 2 kVA |
| Load Capacity (Watt) | 1.80 kW |
| Input Voltage | 120 V AC |
| Output Voltage | 100 V AC,110 V AC,115 V AC,120 V AC,127 V AC |
| Input Frequency | 60 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Pure Sine Wave |
| Surge Energy Rating | 190 J |
| Input Power Factor | 0.99 |
| Output Power Factor | 0.9 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | SNMP |
| Alarm | Remote Shutdown,UPS StartUp,Power Failure,Overload,UPS Fault,Low Battery |
| Controls/Indicators | |
| Status Indicators | 4 x status-indicating LEDs |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| Battery Information | |
| DC System Voltage | 72 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 7.70 Minute |
| Backup/Run Time (Half Load) | 20.20 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 3 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Elevation | 9842.52 ft (3000000 mm) |
| Storage Temperature | 32°F (0°C) - 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission | 47 dB |
| Physical Characteristics | |
| Height | 3.41" (86.61 mm) |
| Width | 17.33" (440.18 mm) |
| Depth | 23.82" (605.03 mm) |
| Rack Height | 2U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 61.51 lb (27900.47 g) |
| Miscellaneous | |
| Package Contents | |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
