Tripp Lite by Eaton SU6000RT3UTAA SmartOnline 6000VA 5. 4kW Rack/Tower UPS - 3U AVR Pure Sine Wave - 3 Min Full Load Runtime
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SmartOnline UPS employs double-conversion online topology, delivering zero transfer time and complete isolation from input power anomalies. The unit accepts a wide input voltage range from 200V to 240V AC and outputs a stable, pure sine wave at 220-240V AC, maintaining a 0.9 output power factor for efficient load support.
Advanced energy-saving modes achieve up to 98% efficiency in ECO operation, reducing thermal dissipation and operating costs. The integrated EMI/RFI noise filter and surge suppression protect connected equipment from electrical noise and transient spikes, while the built-in circuit breaker adds an extra layer of safety.
This section brings together practical product details such as AVR, Plug/Connector Type, Receptacle Type, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The SU6000RT3UTAA combines industrial-grade power protection with enterprise management capabilities in a versatile 3U package. Its hot-swappable, valve-regulated lead-acid batteries support maintenance without downtime, and the replaceable battery design extends the system's service life.
Multi-Voltage Compatibility
Supports input and output voltages from 200V to 240V AC, making it suitable for global deployments and facilities with varying power standards.
- Wide input range: 200-240V AC
- Stable output: 220-240V AC
- 50/60 Hz operation
Comprehensive Monitoring
An LCD display provides real-time status, while dry contact, RS-232, USB, and optional SNMP/HTTP network card interfaces enable local and remote management.
- LCD status display
- Four status-indicating LEDs
- EPO port for emergency shutdown
High-Efficiency Operation
Green energy-saving technology delivers 93% efficiency in AC mode and 98% in ECO mode, reducing heat output and electricity consumption in always-on applications.
- 98% ECO mode efficiency
- Energy Star certified
- 1895 BTU/h thermal dissipation
Deployment / Use Cases
This 6000VA UPS is engineered for environments where power continuity directly impacts operations and revenue. Its 3-minute full-load runtime provides sufficient buffer for graceful shutdowns or transfer to backup generators during extended outages.
In data centers and network closets, the rack-mountable 3U design optimizes space while powering server racks, storage arrays, and core switches. For industrial and healthcare settings, the pure sine wave output and robust surge protection safeguard sensitive medical imaging, laboratory, and process control equipment from damaging power events.
IT Infrastructure Protection
Supports servers, networking equipment, and storage systems in enterprise data centers, preventing data loss and hardware damage during power disturbances.
Critical Facility Support
Provides reliable backup power for healthcare, military, government, and educational facilities where uptime is essential for safety and continuity.
Physical Profile
The SU6000RT3UTAA measures 5.10" high, 17.30" wide, and 27.03" deep, occupying 3U of rack space with a weight of 106 pounds. Its rack/tower form factor includes tower support stands for standalone use and comprehensive rack-mounting hardware for secure data center installation.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 5.10" (129.54 mm), 17.30" (439.42 mm), 27.03" (686.56 mm), 106 lb (48080.79 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.30" (439.42 mm)
- Depth
- 27.03" (686.56 mm)
- Height
- 5.10" (129.54 mm)
- Weight
- 106 lb (48080.79 g)
- Length
- 10 ft (3.05 m)
What's in the Box
The package includes all necessary components for immediate deployment in rack or tower configurations.
Highlights
- 6000VA/5.4kW double-conversion online UPS for mission-critical power protection
- 3-minute full load runtime provides buffer for graceful shutdowns or generator transfer
- Pure sine wave output ensures compatibility with sensitive servers and industrial equipment
- Automatic voltage regulation (AVR) corrects brownouts and overvoltages without battery use
- 3U rack/tower form factor with included hardware for flexible deployment
- Hot-swappable, valve-regulated lead-acid batteries support maintenance without downtime
- Wide input voltage range (200-240V AC) with multi-voltage output support
- LCD display and multiple management interfaces (USB, RS-232, dry contact, SNMP)
- Energy Star certified with 98% efficiency in ECO mode for reduced operating costs
- 2-year limited warranty with RoHS and REACH environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SU6000RT3UTAA |
| Brand Name | Tripp Lite series |
| Product Line | SmartOnline |
| Product Model | SU6000RT3UTAA |
| Product Name | SmartOnline SU6000RT3UTAA 6000VA Rack/tower UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | Hardwired,NEMA L6-30P |
| Receptacle Type | NEMA L6-20R,NEMA L6-30R,Hardwired |
| Receptacle Detail | 2 x NEMA L6-20R,2 x NEMA L6-30R |
| Cord Length | 10 ft (3.05 m) |
| Transfer Time | 0 ns |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Energy Saving | Green Energy-Saving |
| Efficiency Detail | 93% (AC Mode),98% (ECO Mode) |
| Application/Usage | Mission Critical Equipment,IT,Network,Education,Healthcare,Military,Government,Network Device,IT Equipment,Non-critical Device,Industrial Equipment |
| Surge Suppression | Yes |
| Features | Audible Alarm,Cold Start Function |
| Power Description | |
| Load Capacity (VA) | 6 kVA |
| Load Capacity (Watt) | 5.40 kW |
| Input Voltage | 200 V AC,208 V AC,220 V AC,230 V AC,240 V AC |
| Input Current | 24.80 A |
| Output Voltage | 220 V AC,230 V AC,240 V AC,208 V AC,200 V AC |
| Output Frequency | 60 Hz,50 Hz |
| Waveform Type | Pure Sine Wave |
| Circuit Breaker | Yes |
| Output Power Factor | 0.9 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Dry Contact,DB-9 RS-232,SNMP/HTTP Remote Monitoring,Network Card |
| Alarm | Low Battery,Overload,UPS Fault,Remote Shutdown,Utility Power Failure,Battery Fault |
| Controls/Indicators | |
| Status Indicators | LED Indicators: 4 Status-indicating LEDs |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| EPO Port | Yes |
| Number of USB Ports | 1 |
| Battery Information | |
| DC System Voltage | 180 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3 Minute |
| Backup/Run Time (Half Load) | 8 Minute |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Elevation | 3280 ft (999744 mm) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Thermal Dissipation | 1895 BTU/h |
| Physical Characteristics | |
| Height | 5.10" (129.54 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 27.03" (686.56 mm) |
| Rack Height | 3U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 106 lb (48080.79 g) |
| Miscellaneous | |
| Package Contents | SmartOnline SU6000RT3UTAA 6000VA Rack/tower UPS WEBCARDLXE Network Card USB Cable DB9 Cable Tower Support Stands Cable Gland for Hardwire Connection Rack-mounting Hardware Quick Start Guide |
| Energy Star | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the runtime of this UPS at full and half load?
The SU6000RT3UTAA provides 3 minutes of runtime at full load (5.4kW) and 8 minutes at half load (2.7kW). This runtime allows sufficient time for connected equipment to perform graceful shutdowns or transfer to backup power sources during utility outages.
What input and output voltages does this UPS support?
This UPS accepts input voltages from 200V to 240V AC and delivers output voltages from 200V to 240V AC, specifically supporting 200V, 208V, 220V, 230V, and 240V configurations. This wide range makes it suitable for various electrical standards and global deployments.
Can this UPS be installed in both rack and tower configurations?
Yes, the SU6000RT3UTAA features a rack/tower form factor. It occupies 3U of rack space and includes both rack-mounting hardware and tower support stands, providing flexibility for data center rack installation or standalone use in server rooms and equipment closets.
What type of waveform does this UPS produce?
This UPS delivers pure sine wave output, which is essential for powering sensitive electronic equipment like servers, networking gear, and medical devices. Pure sine wave power prevents compatibility issues and potential damage that can occur with simulated sine wave outputs.
How is this UPS managed and monitored?
Management options include a front-panel LCD display, four status-indicating LEDs, USB and RS-232 ports for local monitoring, and support for dry contact signals and an optional SNMP/HTTP network card for remote management. Alarms cover low battery, overload, UPS fault, and utility power failure conditions.
What is included in the package with this UPS?
The package contains the SmartOnline SU6000RT3UTAA UPS unit, WEBCARDLXE network card, USB cable, DB9 cable, tower support stands, cable gland for hardwire connections, rack-mounting hardware, and a quick start guide for comprehensive deployment in either rack or tower configurations.
What power capacity is listed for this UPS?
The listed power specification is 6 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
200 V AC,208 V AC,220 V AC,230 V AC,240 V AC.
