Tripp Lite by Eaton SRN4G12USDP SmartRack Rack Mount Enclosure - 12U - 32" Depth - Gray Metal Cabinet - Wall Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SmartRack enclosure features a NEMA 4-rated plug/connector type, ensuring protection against water ingress and environmental elements. The construction includes adjustable mounting rails for versatile equipment placement and a lockable door with tamper-resistant and anti-theft features to safeguard sensitive hardware.
The enclosure is designed with comprehensive environmental resistance, including snow, moisture, rain, water, and debris resistance, making it suitable for harsh or outdoor-adjacent installations. Cable management provisions help organize and protect wiring from heat, dust, light, and moisture, maintaining system reliability and reducing clutter.
This section brings together practical product details such as Rack Type, Application/Usage, Features, Plug/Connector Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The SRN4G12USDP combines robust physical protection with practical deployment features, offering a reliable solution for equipment housing in diverse settings.
Enhanced Security
A lockable door with tamper-resistant and anti-theft mechanisms provides physical security for valuable equipment, reducing the risk of unauthorized access or theft in shared or public spaces.
- Lockable door design
- Tamper-resistant features
- Anti-theft protection
Environmental Durability
With snow, moisture, rain, water, and debris resistance, this enclosure maintains equipment integrity in challenging environments, from industrial floors to outdoor-adjacent installations.
- NEMA 4 rating
- Multi-environment resistance
- Debris protection
Efficient Cable Management
Integrated cable management features enclose and protect wiring from environmental factors, reducing clutter and minimizing downtime due to cable damage or disorganization.
- Surface-mounted conduit
- Heat and dust protection
- Moisture resistance
Deployment / Use Cases
This rack mount enclosure is ideal for scenarios requiring secure, organized, and environmentally protected equipment housing. Its 12U capacity and 32" depth accommodate standard rack-mountable devices, making it versatile for various IT and networking deployments.
Common applications include housing DVR systems for surveillance setups, consolidating switches and patch panels in network closets, mounting PDUs and UPS units for power management, and serving as a central enclosure in small to medium-sized data centers or server rooms. The wall-mountable design is particularly useful in retail environments, warehouses, or facilities where floor space optimization is critical.
Physical Profile
The enclosure features a gray metal and steel construction with a sleek, professional appearance. Its dimensions of 24.08" H x 24" W x 34.05" D provide a balanced footprint for wall or floor placement, while the 12U rack height and 32" rack depth ensure compatibility with standard 19" rack-mountable equipment. The heavy-duty build supports substantial weight loads, and the design includes features like adjustable mounting rails for flexible installation.
- Width
- 24" (609.60 mm)
- Depth
- 34.05" (864.90 mm)
- Height
- 24.08" (611.63 mm)
- Weight
- 200 lb (90718.47 g)
What's in the Box
The package includes all necessary components for setup, with no assembly required.
Highlights
- 12U rack height with 32" depth for standard equipment compatibility
- Gray metal and steel construction for durability and professional appearance
- Wall-mountable form factor for space-efficient installation
- NEMA 4-rated plug/connector type for environmental protection
- Lockable door with tamper-resistant and anti-theft features
- Snow, moisture, rain, water, and debris resistance
- Adjustable mounting rails for versatile equipment placement
- Integrated cable management to protect wiring from environmental factors
- Maximum weight capacity of 200 lb for heavy-duty applications
- 5-year limited warranty with RoHS and REACH compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SRN4G12USDP |
| Brand Name | Tripp Lite series |
| Product Line | SmartRack |
| Product Model | SRN4G12USDP |
| Product Name | SmartRack SRN4G12USDP Rack Mount Enclosure |
| Product Type | Rack Mount Enclosure |
| Technical Information | |
| Rack Type | Enclosed Cabinet |
| Application/Usage | DVR,Switch,PDU,Patch Panel,UPS |
| Features | Snow Resistant,Moisture Resistant,Lockable Door,Damage Resistant,Tamper Resistant,Anti-theft,Cable Management,Adjustable Mounting Rails,Debris Resistant,Heavy Duty,Rain Resistant,Water Resistant |
| Power Description | |
| Plug/Connector Type | NEMA 4 |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Color Family | Gray |
| Product Color | Gray |
| Product Material | Metal,Steel |
| Maximum Weight Capacity | 200 lb (90718.47 g) |
| Static/Stationary Weight Capacity | 200.62 lb (91000 g) |
| Height | 24.08" (611.63 mm) |
| Width | 24" (609.60 mm) |
| Depth | 34.05" (864.90 mm) |
| Rack Height | 12U |
| Rack Depth | 32" (812.80 mm) |
| Weight (Approximate) | 131.73 lb (59750 g) |
| Miscellaneous | |
| Package Contents | SRN4G12USDP Industrial Enclosure 48 x 10-32 screws 48 x M6 washers 4 x LDPE sheet metal plugs 4 x M10 foam washers 2 x Keys Owner's manual |
| Assembly Required | No |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the rack height and depth of this enclosure?
The enclosure has a rack height of 12U and a rack depth of 32" (812.80 mm), providing ample space for standard 19" rack-mountable equipment like switches, PDUs, patch panels, and UPS units. The external dimensions are 24.08" H x 24" W x 34.05" D, offering a compact footprint suitable for various installation environments.
Can this rack enclosure be wall-mounted?
Yes, this enclosure features a wall-mountable form factor, allowing installation in spaces where floor space is limited or where elevated mounting is preferred for security and accessibility. This design enhances deployment flexibility in retail, warehouse, or facility settings.
What environmental protections does this enclosure offer?
The enclosure provides comprehensive environmental resistance, including snow, moisture, rain, water, and debris resistance, with a NEMA 4-rated plug/connector type. These features protect internal equipment from harsh conditions, making it suitable for industrial, outdoor-adjacent, or challenging environments.
What security features are included?
Security features include a lockable door with tamper-resistant and anti-theft mechanisms, safeguarding valuable equipment from unauthorized access or theft. This is particularly useful in shared or public spaces where physical security is a priority.
What is the weight capacity of this rack enclosure?
The enclosure supports a maximum weight capacity of 200 lb (90718.47 g) and a static/stationary weight capacity of 200.62 lb (91000 g), making it suitable for heavy-duty applications. Its own approximate weight is 131.73 lb (59750 g), reflecting a robust metal and steel construction.
What comes in the box with this enclosure?
The package includes the SRN4G12USDP industrial enclosure, 48 x 10-32 screws, 48 x M6 washers, 4 x LDPE sheet metal plugs, 4 x M10 foam washers, 2 keys, and an owner's manual. No assembly is required, ensuring a straightforward setup process.
