Tripp Lite by Eaton SU2200RTXL2UA Tripp Lite SmartOnline 2200VA/1600W Double Conversion UPS - 2U Rack/Tower - 4. 5 Min Full Load - SNMP/USB
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SmartOnline UPS utilizes double conversion online technology, providing full isolation from input power anomalies. It accepts 110-120V AC input and delivers regulated 110-120V AC output with ±2% voltage accuracy, ensuring compatibility with standard North American equipment. The unit features a high-efficiency economy mode option to reduce energy consumption during normal operation.
Battery management is robust, with hot-swappable batteries that allow for replacement without powering down connected devices. The internal battery supports a runtime of 4.5 minutes at full load (1600W) and extends to 14 minutes at half load, with a typical recharge time of 5 hours. Expandable runtime options are available for extended backup needs.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The SU2200RTXL2UA combines high power capacity with intelligent features for superior uptime protection. Its double conversion topology ensures that connected equipment receives clean, consistent power regardless of utility fluctuations, surges, or outages.
Flexible Installation
Mount as a standalone tower or integrate into a standard 19-inch rack with included hardware. The 2U height and 19-inch depth optimize space in rack enclosures.
- Tower or 2U rack-mount
- Includes mounting hardware
- 19" installed depth
Advanced Management
Manage the UPS locally via USB or serial connections, or remotely using optional SNMP/WEB cards. PowerAlert software enables automated shutdowns and monitoring across platforms.
- SNMP/WEB card support
- PowerAlert software included
- EPO port for emergency shutdown
Reliable Runtime
Hot-swappable batteries allow for maintenance without downtime, and the unit supports expandable runtime modules for critical applications requiring longer backup periods.
- Hot-swap battery design
- Expandable runtime
- 5-hour recharge time
Deployment / Use Cases
This UPS is ideal for protecting mid-range servers, network switches, storage arrays, and telecom equipment in small to medium business environments. Its 2200VA capacity and multiple outlet configurations support mixed loads of IT hardware, ensuring comprehensive coverage for essential infrastructure.
Common deployments include server rooms where space efficiency is critical, network closets supporting PoE switches and routers, and office settings requiring tower-style backup for workstations and peripherals. The unit's SNMP capability integrates seamlessly into existing network management systems, providing centralized power monitoring and control.
Server Room Protection
Safeguard critical servers and storage from power interruptions, with enough capacity to support multiple devices and allow for graceful shutdowns during extended outages.
Network Infrastructure
Ensure continuous operation for switches, routers, and firewalls, with dataline protection for connected Ethernet equipment and flexible outlet types for various power cords.
Physical Profile
The UPS measures 3.5" (88.9 mm) in height, 17.5" (444.5 mm) in width, and 19" (482.6 mm) in depth, with a weight of approximately 47.4 lbs (21.5 kg). Its compact 2U rack-mount design minimizes space consumption in standard server racks, while the tower form factor includes a stable base for standalone placement. The finish is durable and designed for professional environments, with clear status indicators and accessible ports on the front or rear depending on orientation.
- Width
- 17.50" (444.50 mm)
- Depth
- 19" (482.60 mm)
- Height
- 3.50" (88.90 mm)
- Weight
- 47.40 lb (21500.28 g)
What's in the Box
The package includes all necessary components for immediate deployment and management.
Highlights
- 2200VA / 1600W double conversion online UPS for clean power output
- Flexible 2U rack-mount or tower installation with included hardware
- 4.5-minute full load runtime, expandable with additional battery modules
- Hot-swappable batteries enable maintenance without downtime
- SNMP, USB, and serial management interfaces for remote monitoring
- 7 output receptacles (1x NEMA 5-15/20R, 6x NEMA L5-20R) for versatile connectivity
- Includes PowerAlert software for automated shutdown and event logging
- 2-year limited warranty for reliable long-term protection
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SU2200RTXL2UA |
| Brand Name | Tripp Lite series |
| Product Line | SmartOnline |
| Product Model | SU2200RTXL2UA |
| Product Name | SmartOnline SU2200RTXL2UA 2200VA Tower/Rack Mountable UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA 5-15/20R,NEMA L5-20R |
| Receptacle Detail | 1 x NEMA 5-15/20R,6 x NEMA L5-20R |
| Dataline Protection | RJ-45 |
| Power Description | |
| Load Capacity (VA) | 2.20 kVA |
| Load Capacity (Watt) | 1.60 kW |
| Input Voltage | 110 V AC,120 V AC |
| Input Current | 16 A |
| Output Voltage | 110 V AC,120 V AC |
| Management | |
| Network Management | SNMP Manageable |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| Battery Information | |
| Backup/Run Time (Full Load) | 4.50 Minute |
| Backup/Run Time (Half Load) | 14 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 5 Hour |
| Physical Characteristics | |
| Height | 3.50" (88.90 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 19" (482.60 mm) |
| Rack Height | 2U |
| Form Factor | Tower |
| Weight (Approximate) | 47.40 lb (21500.28 g) |
| Miscellaneous | |
| Package Contents | SmartOnline SU2200RTXL2UA 2200VA Tower/Rack Mountable UPS PowerAlert software CD-ROM and complete cabling Mounting hardware for 4 post rack enclosures Instruction manual with warranty information |
| Software Included | PowerAlert UPS Monitoring Software |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the power capacity of this UPS in watts and VA?
This Tripp Lite SmartOnline UPS has a load capacity of 2200VA (2.2kVA) and 1600 watts. It provides sufficient power to support mid-range servers, network equipment, and storage devices, ensuring reliable backup during outages or fluctuations.
How long will the UPS run at full load and half load?
At full load (1600W), the UPS provides approximately 4.5 minutes of runtime. At half load (800W), runtime extends to about 14 minutes. These times allow for graceful shutdowns of connected equipment or short-term operation during brief power interruptions.
Can I install this UPS in a server rack?
Yes, the SU2200RTXL2UA is designed for both tower and 2U rack-mount installations. It includes mounting hardware for standard 4-post server racks, with a depth of 19 inches to fit typical rack enclosures without obstruction.
What management options are available for this UPS?
The UPS supports local management via USB and serial ports, and it is SNMP manageable for network integration. Included PowerAlert software enables remote monitoring, shutdowns, and alerts. Optional SNMP/WEB cards can be added for advanced network management features.
Are the batteries hot-swappable?
Yes, the batteries are hot-swappable, allowing you to replace them without powering down connected equipment. This feature minimizes downtime during maintenance and ensures continuous protection for critical systems.
What types of power outlets does this UPS have?
It includes 7 output receptacles: 1 NEMA 5-15/20R and 6 NEMA L5-20R outlets. This mix supports a variety of equipment power cords, from standard IT devices to higher-power networking gear, providing flexible connectivity options.
What power capacity is listed for this UPS?
The listed power specification is 2.20 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 110 V AC,120 V AC, which helps position the unit for the right load level and installation role.
