Ubiquiti Flex Mini USW-FLEX-2.5G-5 Ethernet Switch - 5 Ports - Manageable - 2.5 Gigabit Ethernet - 2.5GBase-T - 2 Layer Supported - W (USW-Flex-2.5G-5)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Features: Flow Control,Port Mirroring,Virtual LAN (VLAN),LED Indicator,Loop Protection
Total Number of Network Ports: 5
Network (RJ-45): Yes
Port/Expansion Slot Details: 5 x 2.5 Gigabit Ethernet Network
Media Type Supported: Twisted Pair
Ethernet Technology: 2.5 Gigabit Ethernet
Network Technology: 2.5GBase-T
Maximum Data Transfer Rate: 320 MB/s
Layer Supported: 2
Manageable: Yes
PoE (RJ-45) Port: Yes
Input Voltage: 4.8 V DC,5.2 V DC,44 V,57 V
Power Source: PoE,AC/DC
Power Consumption: 6.40 W
Product Material: Polycarbonate
Form Factor: Desktop,Compact
Height: 0.83" (21.20 mm)
Width: 4.61" (117.10 mm)
Depth: 3.54" (90 mm)
Weight (Approximate): 7.27 oz (206 g)
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
- Quickly and easily set up a wired network with 5 networking ports
- No need for power lines and outlets, the switch is capable of obtaining power from the PoE source
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- The desktop installation makes it ideal for deployments outside the wiring closet
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
[custom-specifications]
| Specifications | |
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | USW-Flex-2.5G-5 |
| Manufacturer Website Address | http://www.ui.com |
| Brand Name | Ubiquiti |
| Product Line | Flex Mini |
| Product Model | USW-FLEX-2.5G-5 |
| Product Name | Flex Mini USW-FLEX-2.5G-5 Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Flow Control,Port Mirroring,Virtual LAN (VLAN),LED Indicator,Loop Protection |
| Interfaces/Ports | |
| Total Number of Network Ports | 5 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 5 x 2.5 Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Network Technology | 2.5GBase-T |
| Maximum Data Transfer Rate | 320 MB/s |
| Network & Communication | |
| Layer Supported | 2 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| Input Voltage | 4.8 V DC,5.2 V DC,44 V,57 V |
| Power Source | PoE,AC/DC |
| Power Consumption | 6.40 W |
| Physical Characteristics | |
| Product Material | Polycarbonate |
| Form Factor | Desktop,Compact |
| Height | 0.83" (21.20 mm) |
| Width | 4.61" (117.10 mm) |
| Depth | 3.54" (90 mm) |
| Weight (Approximate) | 7.27 oz (206 g) |
| Miscellaneous | |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
[/custom-user-manual]
