Ubiquiti UVC-G5-TURRET-ULTRA-B UniFi G5 Turret Ultra 4MP 2K Outdoor Network Camera - Color - 98. 43 ft Night Vision - 2688 x 1512
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At its core, the G5 Turret Ultra utilizes a 1/2.4" CMOS image sensor that balances power efficiency with high-quality 4-megapixel output. The fixed lens system is optimized for the camera's 102.4° horizontal and 54.9° vertical field of view, delivering consistent focus across its surveillance range. Video processing includes 2D and 3D noise reduction alongside automatic white balance, contributing to clear imagery in varying lighting conditions.
Network integration is streamlined through a wired Fast Ethernet connection with Power over Ethernet (PoE) support, accepting input voltages of 37-57 V DC. This allows for single-cable deployment that simplifies installation and reduces clutter. Remote management capabilities enable administrators to configure, monitor, and maintain the camera from a centralized UniFi console, supporting scalable security system deployments.
This section brings together practical product details such as HD Recording, Recording Formats, Night Vision, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The G5 Turret Ultra stands out with its combination of extended night vision range, high-resolution imaging, and rugged outdoor design. Its 98.43 ft infrared illumination ensures reliable performance in complete darkness, while the 4MP sensor captures fine details essential for identification and forensic review. The camera's IP66 and IK04 ratings guarantee protection against dust, water jets, and physical impacts, making it a dependable choice for harsh environments.
Enhanced Low-Light Clarity
Infrared night vision paired with a removable IR cut-off filter and advanced noise reduction delivers clear monochrome footage in darkness, maintaining surveillance integrity around the clock.
- 98.43 ft (30 m) illumination range
- Removable IR cut-off filter for accurate color daytime imaging
- 2D and 3D noise reduction minimize grain
Simplified Deployment & Power
PoE support enables installation with a single Ethernet cable, reducing wiring complexity and providing both data and power. The camera's low 4W power consumption supports energy-efficient operations.
- Power over Ethernet (PoE) compliant
- Fast Ethernet connectivity
- 4W max power draw for efficiency
Deployment / Use Cases
This camera is designed for outdoor surveillance applications where durability, image quality, and night performance are paramount. Its turret design offers a balance of visibility and discretion, suitable for both deterrence and unobtrusive monitoring. The versatile mounting options—surface, wall, or ceiling—allow flexible placement to cover critical angles and blind spots.
Ideal use cases include securing retail storefronts, monitoring warehouse perimeters, overseeing parking facilities, and protecting residential properties. The wide field of view and high resolution make it effective for capturing license plates, facial details, and activity across expansive areas. Integration into UniFi ecosystems provides seamless management alongside other Ubiquiti security devices, supporting unified video feeds and alert systems.
Commercial Perimeter Security
Deploy along building exteriors or fences to monitor unauthorized access, with night vision ensuring continuous coverage during overnight hours.
Retail & Entryway Monitoring
Install above doors or in parking lots to capture high-traffic areas, using the 2K resolution for clear identification of individuals and vehicles.
Physical Profile
The camera features a compact turret form factor with a 3.54" (90 mm) diameter, designed for low-profile mounting that blends into architectural elements. Its black finish and aluminum alloy housing provide a professional appearance while resisting corrosion and UV degradation. The included fixed lens is protected within the turret dome, safeguarding optical components from weather and vandalism.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 11.64 oz (330 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 11.64 oz (330 g)
Highlights
- 4MP resolution delivers detailed 2688 x 1512 2K video at 30 fps
- 98.43 ft (30 m) infrared night vision with removable IR cut-off filter
- Wide 120.6° diagonal field of view for extensive area coverage
- Power over Ethernet (PoE) support for simplified single-cable installation
- IP66 weatherproof and IK04 impact-resistant construction
- AI-powered imaging with 2D/3D noise reduction and white balance
- Operates in temperatures from -22°F to 122°F (-30°C to 50°C)
- Built-in microphone for audio monitoring capabilities
- Surface, wall, or ceiling mounting options for flexible placement
- Remote management via UniFi console for centralized control
Specifications
| Specifications | |
|---|---|
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | UVC-G5-TURRET-ULTRA-B |
| Brand Name | Ubiquiti |
| Product Line | UniFi |
| Product Model | G5 |
| Product Name | G5 Turret Ultra |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | 2K |
| Night Vision | Yes |
| Night Vision Distance | 98.43 ft (30 m) |
| Night Vision Type | Infrared |
| AI-powered | Yes |
| Infrared (IR) Cut-off Filter | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.4" |
| Color Supported | Color |
| Field of View | H: 102.4°, V: 54.9°, D: 120.6° |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Maximum Video Resolution | 2688 x 1512 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Fixed |
| Lens Included | Yes |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 4 W |
| Input Voltage | 37 V DC,57 V DC |
| Power Source Type | PoE,DC |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Product Material | Aluminum Alloy,Polycarbonate |
| Mount Type | Surface Mount,Wall Mount,Ceiling Mount |
| Form Factor | Turret |
| Durability | Tamper Resistant,Weather Proof |
| Diameter | 3.54" (90 mm) |
| Weight (Approximate) | 11.64 oz (330 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Humidity (Non-condensing) | 0% |
| Maximum Operating Humidity (Non-condensing) | 90% |
| Miscellaneous | |
| Features | Removable IR Cut-off Filter,White Balance,3D Noise Reduction,2D Noise Reduction,Light Sensor,Built-in Microphone |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK04 |
| Ingress Protection Rating | IP66 |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
FAQ
What is the maximum video resolution of this Ubiquiti camera?
The Ubiquiti UniFi G5 Turret Ultra records at a maximum resolution of 2688 x 1512, which is considered 2K quality. This 4-megapixel output provides sharp, detailed footage suitable for identifying faces, license plates, and other critical details in surveillance scenarios.
How far does the night vision reach on this outdoor camera?
The camera's infrared night vision effectively illuminates scenes up to 98.43 ft (30 m) in total darkness. This extended range is supported by AI-powered imaging and a removable IR cut-off filter, ensuring clear monochrome video for overnight security monitoring.
Can this camera be powered using Power over Ethernet (PoE)?
Yes, the G5 Turret Ultra supports Power over Ethernet (PoE), accepting input voltages of 37-57 V DC through its Fast Ethernet port. This allows for installation with a single cable that delivers both data and power, simplifying setup and reducing wiring clutter.
What mounting options are available for this turret camera?
The camera is designed for surface, wall, or ceiling mounting, providing flexibility to cover various angles and locations. Its turret form factor and 3.54" diameter enable discreet placement while maintaining a wide 120.6° diagonal field of view.
Is this camera suitable for outdoor use in harsh weather conditions?
Absolutely. The camera is rated IP66 for dust and water jet resistance, and IK04 for impact protection, making it weatherproof and tamper-resistant. It operates reliably in temperatures from -22°F to 122°F (-30°C to 50°C) and humidity up to 90% non-condensing.
Does this camera include audio recording capabilities?
Yes, the G5 Turret Ultra features a built-in microphone, enabling audio monitoring alongside video. This allows for capturing ambient sound, which can be valuable for comprehensive security surveillance and incident review.
What display size or resolution is listed?
It features a display specification of 4 Megapixel, giving you clear visuals for work and media use.
