Ubiquiti USW-ENTERPRISE-24-POE Switch Enterprise 24 PoE - 24-Port Layer 3 Managed Switch with 400W PoE Budget - 12 x 2.5GbE PoE+ - 12x Gigabit PoE+
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch operates as a full Layer 3 device, supporting advanced routing protocols for scalable network segmentation and efficient traffic management. It adheres to key networking standards including IEEE 802.3af and IEEE 802.3at for reliable PoE and PoE+ device compatibility across all 24 RJ-45 ports.
The internal power system is designed for stability and redundancy, accepting a wide input voltage range from 120V AC to 230V AC and supporting redundant power supply configurations. With a total power consumption rating of 550W, the switch efficiently manages its 400W PoE budget to power access points, IP phones, and other PoE devices without external injectors.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Uplink Port, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Switch Enterprise 24 PoE stands out with its balanced mix of high-density PoE, multi-gigabit connectivity, and enterprise-grade management. The 400W PoE budget is substantial for powering modern high-demand devices like Wi-Fi 6 access points or multi-sensor security cameras directly from the switch, simplifying cabling and reducing total cost of ownership.
Future-Proof Port Speed Mix
The combination of 12x 2.5GbE and 12x Gigabit PoE+ ports allows for a phased upgrade path, connecting newer 2.5GbE devices while maintaining compatibility with existing Gigabit infrastructure.
- Supports 2.5GBase-T, 10/100/1000Base-T
- Backward compatible with Gigabit devices
High-Speed Uplink Flexibility
Dual SFP+ slots provide 10 Gigabit uplink capacity using either optical fiber for long-distance runs or DAC cables for short-reach, high-bandwidth connections to core switches or servers.
- Supports 10GBase-X fiber standards
- Enables scalable network backbone design
Deployment / Use Cases
This switch is ideally deployed as an access or distribution layer switch in medium to large office buildings, educational campuses, or hospitality environments where a high density of PoE devices and varied connection speeds are required.
Common deployment scenarios include powering and connecting a full floor of UniFi Wi-Fi 6 access points and IP phones, serving as the network backbone for a small to medium business with future expansion in mind, or acting as a distribution switch in a multi-building campus using fiber uplinks.
Enterprise Office Floor
Deploy as the primary switch for an office floor, providing PoE to 20+ devices including phones, access points, and security cameras, with 2.5GbE ready for high-performance workstations.
Education or Hospitality
Use in classrooms or hotel wings to deliver network access and power to multiple devices, with Layer 3 features enabling VLAN segmentation for different user groups or services.
Physical Profile
Housed in a durable galvanized cold-rolled steel (SGCC) chassis, the switch is built for rack-mount deployment in standard 19-inch racks. Its 1U height (1.72 inches) conserves valuable rack space, while the 17.42-inch width and 12.80-inch depth provide a compact footprint. The switch weighs 11.27 pounds, making it manageable for installation in server rooms, wiring closets, or network cabinets.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.72" (43.70 mm), 17.42" (442.40 mm), 12.80" (325 mm), 11.27 lb (5110 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.42" (442.40 mm)
- Depth
- 12.80" (325 mm)
- Height
- 1.72" (43.70 mm)
- Weight
- 11.27 lb (5110 g)
Highlights
- 24 total RJ-45 ports with PoE+ support across all ports.
- 400W total PoE budget for powering high-demand devices like Wi-Fi 6 APs.
- 12 ports of 2.5 Gigabit Ethernet PoE+ for faster client connections.
- 12 ports of Gigabit Ethernet PoE+ for standard devices.
- 2 x SFP+ slots for 10 Gigabit fiber or copper uplinks.
- Full Layer 3 switching and routing capabilities.
- Managed via UniFi Controller for centralized network management.
- Supports redundant power supply for increased reliability.
- 1U rack-mount design with durable steel construction.
- Complies with IEEE 802.3af/at PoE standards.
Specifications
| Specifications | |
|---|---|
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | USW-ENTERPRISE-24POE |
| Brand Name | Ubiquiti |
| Product Line | UniFi |
| Product Name | Switch Enterprise 24 PoE |
| Packaged Quantity | 1 |
| Product Type | Layer 3 Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 12 x 2.5 Gigabit Ethernet PoE+,12 x Gigabit Ethernet PoE+,2 x 10 Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | 2.5 Gigabit Ethernet,Gigabit Ethernet,10 Gigabit Ethernet |
| Network Technology | 2.5GBase-T,10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 2 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3af,IEEE 802.3at |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 400 W |
| Input Voltage | 120 V AC,230 V AC,52 V DC,11.5 V DC |
| Power Source | Power Supply,AC/DC,PoE+ |
| Redundant Power Supply Supported | Yes |
| Power Consumption | 550 W |
| Physical Characteristics | |
| Product Material | Galvanized Cold Rolled Steel (SGCC) |
| Height | 1.72" (43.70 mm) |
| Width | 17.42" (442.40 mm) |
| Depth | 12.80" (325 mm) |
| Weight (Approximate) | 11.27 lb (5110 g) |
FAQ
What is the total PoE budget of this switch?
The Ubiquiti Switch Enterprise 24 PoE provides a total PoE budget of 400 watts. This budget is allocated across all 24 RJ-45 ports, which support both PoE (802.3af) and PoE+ (802.3at) standards, allowing you to power a significant number of devices like access points, IP phones, and cameras directly from the switch without needing separate power injectors.
How many 2.5GbE ports does this switch have?
This switch includes 12 dedicated ports that operate at 2.5 Gigabit Ethernet speeds with PoE+ capability. These ports are designed for connecting newer, higher-bandwidth devices such as modern Wi-Fi 6/6E access points, high-performance workstations, or network-attached storage, providing a speed upgrade over traditional Gigabit connections while maintaining PoE power delivery.
What are the uplink options available?
The switch features two SFP+ expansion slots that support 10 Gigabit Ethernet uplinks. These slots can be used with SFP+ optical transceivers for fiber optic connections to cover longer distances or with SFP+ direct-attach copper cables for short-range, high-speed links to core switches or servers, providing flexible backbone connectivity for your network.
Is this a Layer 2 or Layer 3 switch?
This is a Layer 3 managed switch. It supports advanced routing functions such as static routing and routing protocols, allowing for network segmentation, inter-VLAN routing, and more efficient traffic management. This makes it suitable for more complex network designs where routing between different subnets is required without needing a separate router.
What is the rack-mount size of this switch?
The switch has a 1U rack-mount form factor, with dimensions of 1.72 inches in height, 17.42 inches in width, and 12.80 inches in depth. It is designed to fit standard 19-inch equipment racks, making it ideal for installation in server rooms, network closets, or data centers where space optimization is important.
Does this switch support redundant power?
Yes, the Switch Enterprise 24 PoE supports redundant power supply configurations. This feature enhances reliability by allowing you to connect a secondary power supply, so if the primary unit fails, the switch can continue operating without interruption, which is critical for maintaining network uptime in business environments.
