Viewsonic LDM136-151 LDM136-151136" All-in-One Direct View LED Display - Full HD 1080p - Rockchip RK3399 - 4GB RAM - 32GB Flash - Android 9.0
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The ViewSonic LDM136-151 is a 136-inch All-in-One Direct View LED collaboration display engineered for modern meeting rooms and presentation spaces. This large-format display combines a high-brightness LED panel with integrated Android computing, creating a complete visual communication solution that eliminates the need for external media players or PCs in many scenarios.
With its 1920 x 1080 Full HD resolution and 600 cd/m² brightness, the display delivers clear, vibrant visuals even in well-lit environments. The ultra-narrow 6mm bezel creates a nearly seamless viewing surface, while the 170-degree horizontal and vertical viewing angles ensure content remains visible from virtually any position in the room. The integrated Rockchip RK3399 processor and 4GB of RAM provide responsive performance for running collaboration apps, web browsers, and media content directly on the display.
Technical Overview
This collaboration display features a Direct View LED backlight system that provides uniform illumination across the entire 136-inch viewing area. The display operates on Android 9.0 Pie, offering access to the Google Play Store for installing collaboration apps, video conferencing software, and productivity tools directly on the device.
Connectivity is comprehensive with HDMI input for external sources, seven USB ports for peripherals and media playback, Ethernet for network connectivity, and both Wi-Fi and Bluetooth for wireless connections. The integrated audio system includes two speakers delivering 60 watts of RMS power, sufficient for medium to large meeting spaces without requiring external sound reinforcement.
Relevant factors for this section include Display Screen Type, Backlight Technology, Screen Mode, Processor Model. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The LDM136-151 eliminates complexity in meeting room setups by integrating display, computing, and audio into a cohesive system. The detachable control box design allows for flexible installation options while keeping critical components accessible for maintenance. The durable glue-on board surface treatment enhances longevity in commercial environments.
All-in-One Design
Combines display, computing, and audio in a single unit with detachable system control box for flexible installation and maintenance access.
Meeting Room Ready
Pre-installed Android OS with app support for video conferencing, screen sharing, and digital signage without external computers.
Centralized Management
LAN control capabilities enable IT administrators to manage multiple displays remotely for updates, content scheduling, and monitoring.
Deployment / Use Cases
This display is particularly effective in environments where simplicity and reliability are paramount. The integrated Android platform reduces dependency on external computers while maintaining compatibility with standard presentation tools and collaboration software.
Installation flexibility is enhanced by the included wall mount and detachable control box, allowing the display to be mounted flush while keeping processing components accessible. The system supports content sharing from multiple sources including direct USB media playback, network streams, and HDMI-connected devices.
Corporate Boardrooms
Ideal for executive meeting spaces requiring large-format displays for presentations, video conferences, and data visualization with integrated computing capabilities.
Education & Training Centers
Serves as a primary display in lecture halls and training facilities where instructors need to share content from various sources without complex AV setups.
Digital Signage & Wayfinding
Functions as a high-impact informational display in lobbies, retail environments, and public spaces with scheduled content delivery via network management.
Localization and Operating System
The ViewSonic LDM136-151 operates on Android 9.0 Pie, providing a familiar and versatile platform for meeting room and digital signage applications. This operating system enables direct installation of collaboration apps, video conferencing software, and productivity tools from the Google Play Store, reducing reliance on external computers for basic functionality.
While the display does not include specific regional localization features such as keyboard layouts or language packs, its Android OS supports multiple languages and settings that can be configured during setup. This flexibility makes it suitable for diverse environments, from corporate offices to educational institutions, where users may require different interface languages or app preferences.
The integrated computing platform, powered by the Rockchip RK3399 processor, ensures smooth performance for Android-based tasks, including media playback, web browsing, and real-time collaboration. This all-in-one approach simplifies deployment by eliminating the need for separate media players or PCs, while maintaining compatibility with standard HDMI and USB inputs for external device connectivity.
Physical Profile
The display measures 118.58 inches wide by 66.75 inches tall with a remarkably slim 1.22-inch depth, creating a sleek profile when wall-mounted. Despite its large viewing area, the ultra-narrow 6mm bezel maximizes the active display surface. The unit weighs approximately 357 pounds, requiring proper structural support and professional installation. The included wall mount hardware accommodates standard VESA mounting patterns for secure installation.
- Width
- 0.24" (6 mm)
- Depth
- 1.22" (31 mm)
- Height
- 66.75" (1695.50 mm)
- Weight
- 357.15 lb (162000 g)
What's in the Box
The display ships complete with all necessary components for installation and operation.
Highlights
- 136-inch All-in-One Direct View LED display with Full HD 1080p resolution
- Integrated Rockchip RK3399 processor with 4GB RAM and 32GB flash storage
- Android 9.0 Pie operating system with Google Play Store access
- 600 cd/m² brightness with 170-degree horizontal and vertical viewing angles
- Integrated 60W audio system with two speakers
- Comprehensive connectivity: HDMI, 7x USB, Ethernet, Wi-Fi, Bluetooth
- Ultra-narrow 6mm bezel for nearly seamless viewing experience
- Detachable system control box for flexible installation and maintenance
- LAN control capabilities for centralized management of multiple displays
- Includes wall mount and all necessary installation components
Specifications
| Specifications | |
|---|---|
| Manufacturer | ViewSonic Corporation |
| Manufacturer Part Number | LDM136151 |
| Brand Name | ViewSonic |
| Product Model | LDM136-151 |
| Product Name | 136" All-in-One Direct View LED Display |
| Packaged Quantity | 1 |
| Product Type | Collaboration Display |
| Display & Graphics | |
| Display Screen Type | LCD |
| Backlight Technology | Direct View LED |
| Screen Mode | Full HD |
| Screen Resolution | 1920 x 1080 |
| Scan Format | 1080p |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 6,500:1 |
| Brightness | 600 cd/m² |
| Horizontal Viewing Angle | 170° |
| Vertical Viewing Angle | 170° |
| Processor & Chipset | |
| Processor Model | RK3399 |
| Memory | |
| Standard Memory | 4 GB |
| Storage | |
| Flash Memory Capacity | 32 GB |
| Audio | |
| Speakers | Yes |
| Number of Speakers | 2 |
| RMS Output Power | 60 W |
| Network & Communication | |
| Ethernet | Yes |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Interfaces/Ports | |
| HDMI | Yes |
| Total Number of USB Ports | 7 |
| USB | Yes |
| Network (RJ-45) | Yes |
| Audio Line Out | Yes |
| Serial | Yes |
| Software | |
| Operating System Platform | Android |
| Operating System | Android 9.0 Pie |
| Power Description | |
| Input Voltage | 120 V AC |
| Power Consumption | 1740 W |
| Physical Characteristics | |
| Bezel Width | 0.24" (6 mm) |
| Height | 66.75" (1695.50 mm) |
| Width | 118.58" (3012 mm) |
| Depth | 1.22" (31 mm) |
| Weight (Approximate) | 357.15 lb (162000 g) |
| Miscellaneous | |
| Package Contents | 136" All-in-One Direct View LED Display 1 x Wall Mount 1 x Remote Control 1 x Power Cord 1 x LAN Cable 1 x IR Extender 1 x Quick Setup Guide 1 x LD-MK-003 1 x LD-MK-004 |
| Energy Star | No |
| Country of Origin | China |
| TAA Compliant | No |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What screen size is listed?
ViewSonic 136" All-in-One Direct View LED Display - LCD RK3399 - 4 GB DDR4 SDRAM - 16:9 Aspect Ratio - 1920 x 1080 - Direct View LED - (LDM136-151) is best judged through its screen, connectivity, and installation specifications, which help buyers confirm visual fit and deployment suitability.
What resolution or display format is specified?
It features a display specification of 1920 x 1080, giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
The listed power specification is 600 cd/m², which helps position the unit for the right load level and installation role.
What input or connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
Does the display support VESA mounting or adjustment features?
ViewSonic 136" All-in-One Direct View LED Display - LCD RK3399 - 4 GB DDR4 SDRAM - 16:9 Aspect Ratio - 1920 x 1080 - Direct View LED - (LDM136-151) is best judged through its screen, connectivity, and installation specifications, which help buyers confirm visual fit and deployment suitability.
What panel or display technology is mentioned?
It features a display specification of LCD, giving you clear visuals for work and media use.
