Product Features
Technical Overview
This camera delivers 4-megapixel resolution at a maximum 2560x1440 pixel count, producing high-definition footage essential for identifying details in surveillance scenarios. The 30 fps frame rate ensures smooth video playback, reducing motion blur for accurate monitoring. Video compression includes advanced H.265+ and H.264+ codecs, which significantly reduce file sizes and network load compared to standard formats, ideal for continuous recording setups.
Imaging capabilities are enhanced by a CMOS sensor that offers power efficiency and cost-effectiveness while maintaining HD video quality. The lens features an f/2.2 maximum aperture, allowing more light intake for better performance in varied lighting. Network connectivity is wired via Fast Ethernet, with remote management enabling configuration and monitoring from centralized systems.
This section brings together practical product details such as HD Recording, Night Vision, Night Vision Distance, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The VIGI C340I(2.8MM) combines high-resolution imaging with durable outdoor design, offering a practical solution for security monitoring. Its infrared night vision extends to 98.43 feet, ensuring reliable performance in darkness, while the IP67 rating guarantees protection against water and dust ingress. These features make it a dependable choice for perimeter surveillance, parking lots, and building exteriors.
Advanced Video Compression
Support for H.265+ and H.264+ codecs reduces bandwidth usage and storage requirements, enabling longer recording times and lower infrastructure costs.
- Efficient bandwidth utilization
- Extended storage capacity
- Compatible with modern NVR systems
Intelligent Detection Features
Built-in human and vehicle detection, along with motion detection and privacy masking, enhances security accuracy and reduces false alarms.
- Targeted alerting
- Customizable privacy zones
- Wide dynamic range for challenging lighting
Deployment / Use Cases
This camera is designed for outdoor surveillance applications where durability and clear imaging are critical. Its bullet form factor and multiple mounting options allow flexible installation on ceilings, walls, or poles, adapting to various architectural needs. The PoE and DC power support simplifies wiring, making it suitable for both new and retrofit security systems.
Ideal use cases include monitoring entry points, parking areas, warehouses, and retail exteriors. The camera's weatherproof construction and wide operating temperature range ensure consistent performance in diverse climates, from cold winters to hot summers. Integration with network video recorders (NVRs) and VMS platforms enables scalable security solutions for small businesses and enterprise environments.
Outdoor Perimeter Security
Deploy along fences, gates, or building perimeters to deter intrusions and capture high-resolution evidence with night vision capability.
Commercial Property Monitoring
Use in retail lots, industrial sites, or office complexes to oversee assets and enhance safety with remote management features.
Physical Profile
The camera measures 6.85" (174 mm) in height, 2.91" (74 mm) in width, and 2.80" (71 mm) in depth, featuring a compact bullet design that minimizes visual intrusion. Its rugged housing supports ceiling, wall, and pole mounting, offering installation versatility for optimal viewing angles. The IP67 ingress protection ensures resistance to water, dust, and weather elements, maintaining reliability in outdoor settings.
- Width
- 2.91" (74 mm)
- Depth
- 2.80" (71 mm)
- Height
- 6.85" (174 mm)
- Length
- 2.8 mm (0.11")
Highlights
- 4MP resolution delivers 2560x1440 video at 30 fps for detailed surveillance
- Infrared night vision covers up to 98.43 ft (30 m) for low-light monitoring
- IP67-rated weatherproof and dustproof construction for outdoor durability
- Supports H.265+, H.265, H.264+, and H.264 video compression formats
- PoE and 12 V DC power options for flexible installation
- Fixed 2.8 mm lens with 106.5° diagonal field of view
- Human and vehicle detection with motion sensing for smart alerts
- Operating temperature range of -22°F to 140°F for all-season use
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | VIGI C340I(2.8MM) |
| Brand Name | VIGI |
| Product Model | C340I |
| Product Name | VIGI 4MP Outdoor IR Bullet Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 98.43 ft (30 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/3" |
| Color Supported | Color |
| Field of View | Diagonal FOV: 106.5° |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | H.265+,H.265,H.264,H.264+ |
| Maximum Video Resolution | 2560 x 1440 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 2.8 mm (0.11") |
| Lens Included | Yes |
| Lens Mount Type | M12-mount |
| Maximum Aperture | f/2.2 |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | PoE,DC |
| Physical Characteristics | |
| Mount Type | Ceiling Mount,Wall Mount,Pole Mount |
| Form Factor | Bullet |
| Durability | Water Proof,Weather Proof,Rain Resistant,Dust Resistant |
| Height | 6.85" (174 mm) |
| Width | 2.91" (74 mm) |
| Depth | 2.80" (71 mm) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Miscellaneous | |
| Features | Human Detection,Vehicle Detection,Wide Dynamic Range,3D Digital Noise Reduction,Motion Detection,White Balance,Cross Line Detection,Password Protection,HTTPS Encryption,Mirror,Privacy Masking |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP67 |
User Manual
FAQ
What is the resolution and frame rate of the VIGI C340I camera?
The camera provides 4-megapixel resolution with a maximum video resolution of 2560 x 1440 pixels. It records at 30 frames per second, ensuring smooth and detailed video footage suitable for identifying objects and activities in surveillance applications.
How far does the night vision reach, and what type is it?
The infrared night vision has an effective distance of 98.43 feet (30 meters). It uses infrared technology to illuminate scenes in complete darkness, allowing the camera to capture clear monochrome video without additional lighting.
Is this camera suitable for outdoor use, and what is its durability rating?
Yes, it is designed for outdoor use with an IP67 ingress protection rating. This means it is waterproof, dustproof, and resistant to weather conditions like rain. It also operates in temperatures from -22°F to 140°F, ensuring reliability in harsh environments.
What power options does the camera support?
The camera supports both Power over Ethernet (PoE) and 12 V DC power sources. PoE allows for simplified installation using a single Ethernet cable for data and power, while DC power provides an alternative for locations without PoE switches.
What video compression formats are supported?
It supports H.265+, H.265, H.264+, and H.264 formats. H.265+ and H.264+ are advanced codecs that reduce bandwidth and storage requirements by up to 50% compared to standard versions, making them efficient for continuous recording systems.
What mounting options are available for installation?
The camera can be mounted on ceilings, walls, or poles, offering flexibility for various surveillance setups. Its bullet form factor and included mounting hardware facilitate easy installation in optimal positions for wide-area coverage.
What display size or resolution is listed?
It features a display specification of 4 Megapixel, giving you clear visuals for work and media use.
