VIGI INSIGHT S385PI 8MP Outdoor IR Panoramic Bullet Camera - 4K - 180° View - 65.62 ft Night Vision - IP67 - PoE
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At its core, the S385PI features a 1/2.7" CMOS sensor that outputs 8-megapixel video at a maximum resolution of 3840 x 2160 and 30 fps. It supports modern compression formats including H.265+, H.265, and H.264 variants, optimizing bandwidth and storage efficiency without compromising image quality. The camera's 120 dB wide dynamic range balances scenes with extreme lighting contrasts.
Network connectivity is handled via a wired Fast Ethernet interface with support for standard protocols like TCP/IP, RTSP, ONVIF, and IPv6, ensuring seamless integration into existing surveillance ecosystems. The camera includes a built-in microphone for audio capture and supports alarm triggering through its I/O interface.
Relevant factors for this section include HD Recording, Recording Formats, Night Vision, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The INSIGHT S385PI stands out with its combination of high-resolution panoramic imaging, extended night vision, and intelligent analytics. Its 180° horizontal view reduces the number of cameras needed to cover large areas, while the 4K resolution ensures critical details like license plates or facial features remain identifiable even at a distance.
Smart Detection & Analytics
Leverages AI for accurate people and vehicle classification, reducing false alarms. Features like smart detection and video enhancement technology improve monitoring accuracy in complex scenes.
- Human Detection
- Vehicle Detection
- Smart Video Enhancement
All-Weather Reliability
Rated IP67 for dust and water resistance and IK10 for vandal resistance. Operates in temperatures from -22°F to 140°F, making it suitable for year-round outdoor deployment in virtually any climate.
Deployment / Use Cases
This camera is ideal for securing commercial perimeters, parking lots, warehouses, and industrial facilities where broad, unobstructed coverage is required. Its panoramic view makes it perfect for monitoring entrance gates, long fences, or open yards with a single unit.
The PoE capability simplifies installation by delivering both power and data over a single Ethernet cable, reducing wiring complexity. The multiple mounting options—ceiling, wall, or pole—provide flexibility for various architectural and landscape requirements.
Relevant factors for this section include HD Recording, Recording Formats, Night Vision, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Perimeter Security
Deploy along property boundaries to monitor for intrusions with its wide field of view and long-range infrared illumination.
Parking & Logistics Areas
Use for overseeing vehicle traffic, parking spaces, and loading docks, utilizing its vehicle analytics and high-resolution detail for license plate recognition.
Physical Profile
The camera features a durable bullet form factor constructed from metal, measuring 10.50" in length, 4" in height, and 3.90" in width. It weighs approximately 2.23 lb, providing a solid, stable presence. The design includes integrated red-blue warning lights for visual deterrence. Its compact yet robust build is engineered for easy installation on various surfaces while withstanding environmental challenges.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4" (101.60 mm), 3.90" (99.06 mm), 2.23 lb (1010 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 3.90" (99.06 mm)
- Height
- 4" (101.60 mm)
- Weight
- 2.23 lb (1010 g)
- Length
- 1.7 mm (0.06")
What's in the Box
The package includes all necessary components for a complete installation.
Package contents include VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories, VIGI Network Camera. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 8MP resolution for 4K Ultra HD video clarity
- 180° panoramic field of view for wide-area coverage
- Infrared night vision effective up to 65.62 ft (20 m)
- AI-powered people and vehicle detection analytics
- IP67 weatherproof and IK10 vandal-proof ratings
- Power over Ethernet (PoE) support for simplified wiring
- H.265+ compression for efficient bandwidth and storage use
- Wide dynamic range (120 dB) for high-contrast scenes
- Built-in microphone for audio monitoring
- Supports ONVIF for easy system integration
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | INSIGHT S385PI |
| Brand Name | VIGI |
| Product Line | InSight |
| Product Model | S385PI |
| Product Name | 8MP Outdoor IR Panoramic Bullet Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | 4K |
| Night Vision | Yes |
| Night Vision Distance | 65.62 ft (20 m) |
| Night Vision Type | Infrared |
| Number of IR LEDs | 4 |
| Wide Dynamic Range Detail | 120 dB |
| AI-powered | Yes |
| Infrared (IR) Cut-off Filter | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.7" |
| Color Supported | Color |
| Field of View | Horizontal FOV: 180° ? Vertical FOV: 86° ? Diagonal FOV: 180° |
| Effective Camera Resolution | 8 Megapixel |
| Video | |
| Video Formats | H.265+,H.265,H.264,H.264+,H.264H,H.265M |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Frame Rate | 30 fps |
| Audio | |
| Audio Support | Yes |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 1.7 mm (0.06") |
| Lens Included | Yes |
| Lens Mount Type | M12-mount |
| Maximum Aperture | f/2.0 |
| Exposure | |
| Shortest Shutter Speed | 1/10000 Second |
| Longest Shutter Speed | 1/3 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | TCP/IP,UDP,ICMP,HTTP,HTTPS,DHCP,DNS,RTSP,NTP,UPnP,SSL/TLS,FTP,SFTP,RTP,IPv4,IPv6,ARP,ONVIF,API |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 21 W |
| Input Voltage | 12 V DC |
| Power Source Type | DC,PoE |
| Physical Characteristics | |
| Product Material | Metal |
| Mount Type | Ceiling Mount,Wall Mount,Pole Mount |
| Form Factor | Bullet |
| Durability | Water Proof,Weather Proof,Vandal Proof |
| Height | 4" (101.60 mm) |
| Width | 3.90" (99.06 mm) |
| Length | 10.50" (266.70 mm) |
| Weight (Approximate) | 2.23 lb (1010 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| Maximum Storage Temperature | 140°F (60°C) |
| Maximum Operating Humidity (Non-condensing) | 95% |
| Maximum Storage Humidity (Non-condensing) | 95% |
| Miscellaneous | |
| Features | Alarm Triggering,Vehicle Detection,Human Detection,Wide Dynamic Range,3D Digital Noise Reduction,Noise Reduction,White Balance,Built-in Microphone,Day/Night,Mirror |
| Indoor/Outdoor | Outdoor |
| Package Contents | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP67 |
User Manual
FAQ
What is the resolution and field of view of this camera?
The VIGI INSIGHT S385PI captures 8-megapixel video at a maximum resolution of 3840 x 2160 (4K). It offers a panoramic field of view with 180° horizontally, 86° vertically, and 180° diagonally, allowing it to monitor large areas with a single unit.
How far does the night vision reach and what type is it?
The camera features infrared night vision with four IR LEDs, providing clear monochrome imaging in total darkness up to a distance of 65.62 feet (20 meters). This ensures reliable surveillance during nighttime hours.
Is this camera suitable for outdoor use in harsh weather?
Yes, it is built for demanding outdoor environments. It carries an IP67 rating for dust and water resistance and an IK10 impact protection rating, making it both weatherproof and vandal-proof. It operates in temperatures from -22°F to 140°F.
What power options does the camera support?
The camera supports both 12V DC power and Power over Ethernet (PoE). PoE allows it to receive power and data over a single Ethernet cable, simplifying installation and reducing wiring clutter, with a maximum power consumption of 21 watts.
Does it include smart detection features?
Yes, it includes AI-powered analytics for human and vehicle detection and classification. These smart detection capabilities help reduce false alarms by accurately identifying relevant objects, and features like wide dynamic range and digital noise reduction enhance video quality in challenging conditions.
What video compression formats are supported?
The camera supports modern compression formats including H.265+, H.265, H.264, H.264+, H.264H, and H.265M. H.265+ technology is particularly efficient, reducing bandwidth and storage requirements while maintaining high video quality, which is beneficial for continuous recording.
