Webex CS-BARPRO-C-K9 Room Bar Pro TTC4-01 Video Conference Equipment - Medium Room - 4K UHD 60fps - Gigabit Ethernet
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The Room Bar Pro TTC4-01 features a 1/1.3-inch image sensor that captures detailed 4K UHD video at 3840 x 2160 resolution. Video encoding includes H.263, H.264, and H.265 for efficient bandwidth usage and compatibility. Audio is handled by an internal microphone array with support for G.711, G.722, G.722.1, G.729, AAC-LD, and Opus codecs, ensuring high-quality voice transmission.
Network connectivity is robust with four Gigabit Ethernet ports, 10/100/1000Base-T technology, and integrated wireless LAN. The unit includes one HDMI input and one HDMI output for display connectivity, along with an audio line-in port and USB for peripheral expansion. ITU-T recommendations such as H.460.18/19 and H.235v3 are supported for enhanced security and performance in enterprise environments.
Relevant factors for this section include ITU-T Recommendation, Features, Room Size, Image Sensor Size. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Webex Room Bar Pro TTC4-01 combines high-resolution video, professional audio, and flexible mounting to create a complete meeting-room solution. Its 4K UHD camera and 60fps frame rate deliver lifelike video quality, while noise reduction and echo cancellation technologies ensure clear audio even in acoustically challenging spaces.
Advanced Video Quality
4K UHD resolution at 60fps provides sharp, smooth video that enhances remote participant engagement and meeting effectiveness.
- 3840 x 2160 resolution
- 60 frames per second
- H.265 encoding support
Comprehensive Connectivity
Four Gigabit Ethernet ports, wireless LAN, HDMI in/out, and USB offer extensive options for integrating displays, peripherals, and network infrastructure.
- 4x RJ-45 ports
- Wireless LAN included
- HDMI input and output
Flexible Deployment
Designed for wall mounting, display mounting, or tabletop use, this unit adapts to various room layouts and installation preferences.
- Wall mountable
- Display mount compatible
- Tabletop ready
Deployment / Use Cases
The Room Bar Pro TTC4-01 is ideal for medium-sized conference rooms, huddle spaces, and executive offices where professional video conferencing is required. Its medium room size support makes it suitable for spaces accommodating 6 to 12 participants, providing adequate audio pickup and camera coverage.
Common use cases include daily team meetings, client presentations, remote training sessions, and cross-departmental collaborations. The device's support for H.323, SIP, and other standards ensures compatibility with platforms like Webex, Zoom, Microsoft Teams, and legacy video conferencing systems. Its tabletop form factor allows for quick setup in temporary meeting areas, while wall or display mounting offers a permanent, clean installation in dedicated conference rooms.
Medium Conference Rooms
Optimized for rooms where participants are typically seated around a central table, delivering clear audio and video to all attendees.
Hybrid Meeting Environments
Supports seamless integration with cloud-based and on-premises conferencing platforms, facilitating collaboration between in-room and remote participants.
Physical Profile
The Room Bar Pro TTC4-01 has a sleek Carbon Black finish that blends with modern office aesthetics. Its dimensions are 37.80 inches wide, 4.30 inches high, and 3.50 inches deep, with a weight of approximately 9.86 pounds. This form factor is designed for discreet placement under displays or on walls, minimizing visual clutter. The unit includes mounting hardware for secure installation, and its tabletop option allows for flexible placement without permanent modifications.
- Width
- 37.80" (960.12 mm)
- Depth
- 3.50" (88.90 mm)
- Height
- 4.30" (109.22 mm)
- Weight
- 9.86 lb (4472.42 g)
What's in the Box
The package includes all necessary components for setup and operation.
Highlights
- 4K UHD video resolution at 60fps for crisp, fluid conferencing
- Internal microphone with noise reduction and echo cancellation
- Supports H.323, SIP, H.239, and other industry-standard protocols
- Four Gigabit Ethernet ports and wireless LAN connectivity
- Wall mountable, display mount, or tabletop form factor
- Runs on RoomOS for easy management and updates
- Medium room size support ideal for 6-12 participants
- Carbon Black finish for professional appearance
- Includes mounting kit and necessary cables
- Environmentally compliant with RoHS and WEEE directives
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CS-BARPRO-C-K9 |
| Brand Name | Webex |
| Product Line | Room Bar Pro |
| Product Model | TTC4-01 |
| Product Name | Room Bar Pro TTC4-01 Video Conference Equipment |
| Product Type | Video Conference Equipment |
| Technical Information | |
| ITU-T Recommendation | H.460.18/19,H.239,H.323,SIP,H.235v3,H.245 |
| Features | Noise Reduction,Echo Cancellation,Ultrasound Technology,Dual Stream |
| Room Size | Medium |
| Camera | |
| Image Sensor Size | 1/1.3 |
| Video | |
| Graphics Modes (Live) | 4K UHD |
| Maximum Video Resolution (Live) | 3840 x 2160 |
| Maximum Frame Rate | 60 fps |
| Video Encoding | H.263,H.264,H.265 |
| Audio | |
| Microphone Form Factor | Internal |
| Audio Encoding | G.711,G.722,G.722.1,G.729,AAC-LD,Opus |
| Network & Communication | |
| Network Technology | 10/100/1000Base-T |
| Ethernet Technology | Gigabit Ethernet |
| Wireless Specifications | |
| Wireless LAN | Yes |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| Audio Line In | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Number of HDMI Inputs | 1 |
| Number of Audio Line In | 1 |
| Operating System | |
| Operating System Supported | RoomOS,RoomOS 11.5.2.x,RoomOS 11.5.1.x |
| Physical Characteristics | |
| Product Color | Carbon Black |
| Form Factor | Wall Mountable,Display Mount,Tabletop |
| Height | 4.30" (109.22 mm) |
| Width | 37.80" (960.12 mm) |
| Depth | 3.50" (88.90 mm) |
| Weight (Approximate) | 9.86 lb (4472.42 g) |
| Miscellaneous | |
| Package Contents | Room Bar Pro TTC4-01 Video Conference Equipment Mounting Kit for Cisco Room Bar Pro Ethernet cable HDMI cable Room Navigator for Table Ethernet cable Power cord |
| Application/Usage | Video Conferencing |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 90 Day |
User Manual
FAQ
What video resolution does the Webex Room Bar Pro TTC4-01 support?
The Room Bar Pro TTC4-01 supports 4K UHD video at a maximum resolution of 3840 x 2160 pixels. This high resolution ensures detailed and clear video quality for remote participants, enhancing the overall meeting experience. The device also operates at 60 frames per second for smooth motion during presentations and discussions.
What audio features are included in this conference bar?
This unit includes an internal microphone array with noise reduction and echo cancellation technologies. It supports audio encoding codecs such as G.711, G.722, G.722.1, G.729, AAC-LD, and Opus, providing clear voice transmission and compatibility with various conferencing systems. These features help minimize background noise and ensure participants are heard clearly.
How many network ports does the device have?
The Room Bar Pro TTC4-01 has four Gigabit Ethernet (RJ-45) ports, allowing for multiple network connections or daisy-chaining with other devices. It also supports 10/100/1000Base-T network technology and includes wireless LAN for flexible connectivity options. This robust networking capability ensures reliable performance for video and audio streaming.
What mounting options are available for this conference bar?
The device is designed for wall mounting, display mounting, or tabletop use, providing flexibility for different room layouts and installation preferences. A mounting kit is included in the package for secure installation. This versatility allows it to be integrated into permanent conference room setups or used temporarily in huddle spaces.
What operating system does the Room Bar Pro use?
The Room Bar Pro TTC4-01 runs on RoomOS, specifically supporting versions like RoomOS 11.5.2.x and 11.5.1.x. RoomOS provides a consistent user interface, remote management capabilities, and regular updates for security and feature enhancements. This operating system is optimized for Cisco collaboration devices.
What is included in the package with the Room Bar Pro?
The package includes the Room Bar Pro TTC4-01 video conference equipment, a mounting kit for Cisco Room Bar Pro, an Ethernet cable, an HDMI cable, a Room Navigator for table use, an additional Ethernet cable, and a power cord. These components provide everything needed for initial setup and operation in various configurations.
