Wisenet XNV-8082R 6MP Indoor/Outdoor Network Dome Camera - White - Vandal Resistant - 131. 23 ft IR Night Vision - H. 265 - Varifocal Lens
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera captures video at up to 6 megapixels (3328 x 1872) with a maximum frame rate of 30 frames per second, ensuring smooth, detailed footage. It supports modern video compression standards including H.265 and H.264 variants, optimizing bandwidth and storage efficiency without sacrificing image quality.
The 1/2.8" CMOS sensor works in conjunction with a varifocal lens (2.8mm to 8.4mm) offering a 3x optical zoom. Key imaging technologies include Wide Dynamic Range (WDR) for challenging lighting, Back Light Compensation (BLC), digital image stabilization, defog, and day/night functionality with an infrared cut filter.
This section brings together practical product details such as HD Recording, Night Vision, Night Vision Distance, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
Beyond its core imaging specs, the XNV-8082R includes practical features for operational efficiency. Local storage via microSD card offers a backup recording option, while audio compression, motion detection, and privacy masking tools help tailor the surveillance system to specific site requirements.
Superior Low-Light Performance
Integrated infrared LEDs provide clear monochrome imaging at distances up to 131.23 feet (40 meters), enabling reliable surveillance around the clock regardless of ambient light conditions.
- Infrared night vision
- Auto day/night switching
- Digital noise reduction
Enterprise-Grade Durability
The dome housing is rated IK10+ for impact resistance and IP66/IP67/IP6K9K for dust and water ingress protection, ensuring operation in harsh environments from -58°F to 140°F.
- Vandal-resistant construction
- Wide temperature tolerance
- 95% max humidity rating
Deployment / Use Cases
This camera is designed for integration into IP-based surveillance systems. Its Power over Ethernet (PoE) capability simplifies installation by delivering both data and power over a single cable, reducing wiring complexity and cost. The wired network connection ensures stable, high-bandwidth video streaming for central recording or live viewing.
Typical deployments include commercial buildings, educational campuses, retail environments, industrial facilities, and public spaces where reliable, high-resolution video evidence and deterrent visibility are required. The multiple mount types—ceiling, wall, parapet, pole, and corner—provide installation flexibility for various architectural conditions.
Perimeter & Entryway Monitoring
The varifocal lens and long-range infrared make this camera ideal for covering parking lots, building entrances, gates, and loading docks where adjustable field of view and night vision are critical.
High-Traffic Indoor Areas
Deploy in retail stores, lobbies, warehouses, or schools. The white dome blends with ceilings, while features like WDR handle mixed lighting, and the vandal-resistant rating deters tampering.
Physical Profile
The camera features a compact dome form factor with a 7.09-inch (180 mm) diameter and weighs approximately 4.19 pounds (1900 grams). Its white color and low-profile design facilitate discreet mounting on white or light-colored surfaces. The included varifocal lens allows for precise adjustment of the viewing angle during installation to optimize coverage for the specific scene.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4.19 lb (1900 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 4.19 lb (1900 g)
- Length
- 2.8 mm (0.11")
Highlights
- 6-megapixel CMOS sensor for high-definition 3328 x 1872 video
- Infrared night vision effective up to 131.23 feet (40 meters)
- Vandal-resistant IK10+ and weatherproof IP66/IP67/IP6K9K ratings
- Varifocal lens (2.8-8.4mm) with 3x optical zoom for flexible framing
- Supports H.265 and H.264 compression for efficient bandwidth use
- Power over Ethernet (PoE) and 12V DC dual power input options
- Wide operating temperature range from -58°F to 140°F (-50°C to 60°C)
- Includes features: WDR, motion detection, privacy masking, digital stabilization
- Multiple mounting types: ceiling, wall, parapet, pole, corner
- 3-year manufacturer limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | XNV-8082R |
| Brand Name | Wisenet |
| Product Series | X |
| Product Model | XNV-8082R |
| Product Name | 6MP Network IR Vandal Dome Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 131.23 ft (40 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Field of View | H: 114°(Wide)~40.2°(Tele) / V: 62.0°(Wide)~22.5°(Tele) / D: 133.0°(Wide)~46.3°(Tele) |
| Effective Camera Resolution | 6 Megapixel |
| Video | |
| Video Formats | H.265,H.264,H.264M,H.264H,MJPEG |
| Maximum Video Resolution | 3328 x 1872 |
| Maximum Frame Rate | 30 fps |
| Analog Video Signal Format | CVBS |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 2.8 mm (0.11") |
| Maximum Focal Length | 8.4 mm (0.33") |
| Lens Included | Yes |
| Minimum Aperture | f/1.2 |
| Maximum Aperture | f/2.8 |
| Optical Zoom | 3x |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 1/5 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | DC,PoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Mount Type | Ceiling Mount,Parapet Mount,Pole Mount,Wall Mount,Corner Mount |
| Form Factor | Dome |
| Durability | Vandal Resistant |
| Diameter | 7.09" (180 mm) |
| Weight (Approximate) | 4.19 lb (1900 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -58°F (-50°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | SD Card Local Storage,Day/Night,Audio Compression,Motion Detection,Privacy Masking,Back Light Compensation (BLC),Wide Dynamic Range,Digital Image Stabilization,Defog,Digital Noise Reduction |
| Indoor/Outdoor | Indoor/Outdoor |
| Impact Protection Rating | IK10+ |
| Ingress Protection Rating | IP66,IP67,IP6K9K |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum video resolution of the Wisenet XNV-8082R?
The camera captures video at a maximum resolution of 3328 x 1872 pixels, which is 6 megapixels. This high resolution provides detailed imagery suitable for identifying faces, license plates, or other critical details in surveillance footage, especially when zooming in digitally during playback.
How far does the night vision reach, and what type is it?
The integrated infrared night vision illuminates scenes up to 131.23 feet (40 meters) in total darkness. It uses infrared LEDs, which provide clear monochrome imaging without visible light, making it ideal for discreet 24/7 monitoring in low-light or no-light conditions.
Is this camera suitable for outdoor use?
Yes, the XNV-8082R is rated for both indoor and outdoor use. It carries ingress protection ratings of IP66, IP67, and IP6K9K, meaning it is dust-tight and protected against powerful water jets and temporary immersion. Combined with its wide operating temperature range, it can withstand harsh weather conditions.
What power options does this network camera support?
The camera supports two power methods: standard 12V DC input and Power over Ethernet (PoE). PoE allows you to deliver both data and power over a single Ethernet cable, simplifying installation and reducing wiring costs, which is particularly advantageous for ceiling or remote mount locations.
What mounting options are available for installation?
The camera supports ceiling mount, parapet mount, pole mount, wall mount, and corner mount configurations. This flexibility allows installers to adapt the camera to various architectural environments, ensuring optimal viewing angles and coverage for specific surveillance needs.
Does the camera include local storage capability?
Yes, it supports local storage via a microSD memory card. This provides an on-board recording option that can serve as a backup to network video recorder (NVR) storage or as a primary storage solution in smaller deployments, adding redundancy and flexibility to the surveillance system.
What processor does this product use?
Wisenet XNV-8082R 6 Megapixel Indoor/Outdoor Network Camera - Color - Dome - White - 131.23 ft (40 m) Infrared Night Vision - H.265, - (XNV-8082R) is positioned around the listed processor configuration, giving buyers a clearer view of expected performance for business workloads and everyday deployment needs.
