AddOn FX527AV-AO HP Gigabit Ethernet Card - Single-Port PCIe 2.0 x 4 NIC with Intel 82574 Chipset
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Gigabit Ethernet card utilizes a PCI Express 2.0 x4 host interface, delivering 2000 MB/s bandwidth for high-speed data transfer between the network and host system. The Intel 82574 chipset provides hardware-accelerated packet processing and advanced features like TCP/IP checksum offloading, reducing CPU overhead during network operations.
The single RJ-45 port supports auto-negotiation for 10/100/1000 Mbps speeds and auto-MDI/MDIX crossover detection, eliminating the need for special crossover cables. Twisted pair media support extends to 100-meter cable runs, making this adapter suitable for both office and data center deployments.
Relevant factors for this section include Chipset Manufacturer, Chipset Model, Host Interface, Total Number of Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This network interface card combines enterprise-grade reliability with straightforward installation, making it an ideal choice for network infrastructure upgrades or replacement of failed onboard Ethernet controllers.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Intel Reliability, Flexible Installation.
Intel Reliability
The proven Intel 82574 chipset ensures stable operation and compatibility with major server and workstation platforms.
- Hardware-accelerated processing
- Advanced power management
- Wide driver support
Flexible Installation
Included half-height and full-height brackets accommodate different chassis sizes, from compact workstations to full-size servers.
- Dual bracket design
- Standard PCIe mounting
- Tool-free installation in most cases
Deployment / Use Cases
The AddOn FX527AV-AO serves as a dependable networking solution for various computing environments where reliable wired connectivity is essential. Its server designation makes it particularly suitable for rack-mounted systems requiring additional network interfaces or replacement of malfunctioning onboard Ethernet ports.
Small to medium businesses can deploy this card in file servers, application servers, or workstations that demand consistent network performance for data-intensive tasks. The 100-meter cable support enables flexible office layouts while maintaining full Gigabit speeds throughout the network infrastructure.
Relevant factors for this section include Chipset Manufacturer, Chipset Model, Host Interface, Total Number of Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Server Expansion
Add secondary network interfaces to servers for load balancing, failover configurations, or dedicated management networks.
Workstation Connectivity
Provide high-speed network access to CAD workstations, video editing systems, or other performance-oriented computing platforms.
Physical Profile
Measuring 4.20 inches in height, 0.80 inches in width, and 4.70 inches in depth, this plug-in card maintains a standard profile that fits most PCIe slots without obstruction. The 9.60-ounce weight ensures secure mounting while minimizing stress on the motherboard connector. The low-profile design with included brackets accommodates both standard and small form factor systems.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4.20" (106.68 mm), 0.80" (20.32 mm), 4.70" (119.38 mm), 9.60 oz (272.16 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 0.80" (20.32 mm)
- Depth
- 4.70" (119.38 mm)
- Height
- 4.20" (106.68 mm)
- Weight
- 9.60 oz (272.16 g)
What's in the Box
This product ships complete with all necessary components for immediate installation and operation.
Package contents include HP Gigabit Ethernet Card Half-height and full-height brackets. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Single-port Gigabit Ethernet card with PCI Express 2.0 x4 interface
- Intel 82574 chipset for reliable network performance
- Supports 10/100/1000Base-T network technology
- 2000 MB/s bandwidth for high-speed data transfer
- Twisted pair media support up to 100 meters
- Includes both half-height and full-height mounting brackets
- Plug-in card form factor for easy installation
- Server-grade design for demanding environments
- Lifetime limited warranty for long-term reliability
- Compact dimensions: 4.20" H × 0.80" W × 4.70" D
Specifications
| Specifications | |
|---|---|
| Manufacturer | AddOn |
| Manufacturer Part Number | FX527AV-AO |
| Brand Name | AddOn |
| Product Name | HP Gigabit Ethernet Card |
| Packaged Quantity | 1 |
| Product Type | Gigabit Ethernet Card |
| Technical Information | |
| Chipset Manufacturer | Intel |
| Chipset Model | 82574 |
| Interfaces/Ports | |
| Host Interface | PCI Express 2.0 x4 |
| Total Number of Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Network & Communication | |
| Network Technology | 10/100/1000Base-T |
| Physical Characteristics | |
| Form Factor | Plug-in Card |
| Height | 4.20" (106.68 mm) |
| Width | 0.80" (20.32 mm) |
| Depth | 4.70" (119.38 mm) |
| Weight (Approximate) | 9.60 oz (272.16 g) |
| Miscellaneous | |
| Package Contents | HP Gigabit Ethernet Card Half-height and full-height brackets |
| Device Supported | Server |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of host interface does this network card use?
This Gigabit Ethernet card utilizes a PCI Express 2.0 x4 host interface, providing 2000 MB/s of bandwidth for high-speed data transfer between the network and your system. The x4 lane configuration offers sufficient throughput for Gigabit Ethernet operations while maintaining compatibility with standard PCIe slots found in most servers and workstations.
Does this card support auto-negotiation for different network speeds?
Yes, the AddOn FX527AV-AO supports auto-negotiation for 10/100/1000 Mbps network speeds. This feature allows the card to automatically detect and configure the optimal connection speed with compatible network switches and routers, ensuring seamless integration into existing network infrastructures without manual configuration.
What type of cables can I use with this Ethernet card?
This network interface card supports standard twisted pair cables (Category 5e or higher) commonly used in Ethernet networks. The RJ-45 port is compatible with cables up to 100 meters in length, providing flexibility for office layouts and server room configurations while maintaining full Gigabit performance throughout the cable run.
What mounting options are included with this card?
The product includes both half-height and full-height mounting brackets, allowing installation in various chassis sizes. The half-height bracket accommodates compact systems and small form factor workstations, while the full-height bracket fits standard server and desktop cases. This dual-bracket design ensures compatibility with most computing platforms.
Is this network card suitable for server environments?
Yes, this Gigabit Ethernet card is designated for server support and features an enterprise-grade Intel 82574 chipset. Its robust design, reliable performance, and included full-height bracket make it well-suited for rack-mounted servers, tower servers, and other server-class systems requiring additional or replacement network interfaces.
What warranty coverage does this product include?
The AddOn FX527AV-AO comes with a lifetime limited warranty, providing long-term protection against manufacturing defects. This warranty coverage reflects the product's reliability and durability, offering peace of mind for business deployments where network uptime and component longevity are critical considerations.
