AddOn MFP7E10-N050-AO Compatible 50m MPO-12/APC to MPO-12/APC OM4 Aqua LSZH 12-Strand Fiber Patch Cable - 164 ft
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This fiber optic patch cable is rated OM4, optimized for high-speed multi-mode applications. The 50/125 µm core/cladding specification provides high bandwidth over longer distances compared to OM3. The MPO-12/APC female connectors on both ends support 12-fiber strands, enabling parallel optics for 100 GbE and other high-density interconnects.
The cable is unshielded and features an OFNG (Optical Fiber Non-conductive General Purpose) and LSZH jacket, ensuring compliance with fire safety standards for riser and plenum spaces. It is intended for indoor use and weighs approximately 2.50 lb (1.13 kg). The green connector color helps identify APC polish, which reduces back reflection for improved signal integrity.
Key Product Advantages
This AddOn fiber patch cable delivers reliable high-performance connectivity for demanding network environments. The OM4 rating ensures support for 100 Gbit/s data rates over distances up to 150 meters, while the MPO-12/APC connectors provide secure multi-fiber connections with low insertion loss and high return loss.
High-Speed Readiness
Supports 100 Gbit/s data transfer, future-proofing your network for bandwidth-intensive applications.
- OM4 multi-mode fiber
- 50/125 µm core/cladding
- MPO-12/APC interface
Safety & Compliance
LSZH jacket reduces toxic smoke in case of fire, ideal for indoor installations in confined spaces.
- OFNG rated
- Low smoke zero halogen
- Indoor use
Connector Quality
APC polish minimizes back reflection for cleaner optical signals, critical for high-speed networks.
- Angled Physical Contact
- Green connector color
- Standard boot
Deployment / Use Cases
This cable is designed for use in data centers, server rooms, and enterprise networks where high-density fiber connectivity is required. The 50-meter length is well-suited for rack-to-rack or row-to-row connections within a data center, providing a clean and organized cabling infrastructure.
Common applications include linking top-of-rack switches to aggregation switches, connecting servers to storage area networks (SANs), and interconnecting network devices requiring 100 GbE links. The MPO-12/APC interface is compatible with parallel optics transceivers such as QSFP28 and allows for quick deployment with pre-terminated cassettes or adapter panels.
Data Center Cabling
Ideal for high-speed spine-leaf architectures, supporting 100 Gbit/s uplinks between switches.
- 50 m reach
- OM4 performance
- 12-fiber strands
SAN and HPC Connectivity
Suitable for storage area networks and high-performance computing clusters requiring low-latency, high-bandwidth links.
- 100 Gbit/s per link
- Multi-mode duplex
- APC connectors
Physical Profile
The cable has an outer diameter of 0.12 inches (3 mm), making it flexible and easy to manage in cable trays or troughs. The aqua jacket color indicates OM4 fiber type, while the green connector boots signify APC polish. Weighing approximately 2.50 lb, the cable is lightweight for its length. The MPO-12/APC female connectors feature a standard boot design and are keyed for proper orientation.
- Weight
- 2.50 lb (1133.98 g)
- Length
- 164 ft (50 m)
Highlights
- OM4 multi-mode fiber supports 100 Gbit/s data transfer over 50 meters
- MPO-12/APC female connectors on both ends for secure, low-loss connections
- 12-strand fiber count enables parallel optics applications
- Aqua LSZH jacket ensures safety and easy identification of OM4 fiber
- Angled Physical Contact (APC) polish minimizes back reflection
- Compatible with NVIDIA/Mellanox and other OEM 100G optics
- Indoor-rated OFNG jacket suitable for riser and general building use
- Lifetime limited warranty from AddOn
Specifications
| Specifications | |
|---|---|
| Manufacturer | AddOn |
| Manufacturer Part Number | MFP7E10-N050-AO |
| Brand Name | AddOn |
| Product Name | Fiber Optic Patch Network Cable |
| Packaged Quantity | 1 Piece |
| Product Type | Network Cable |
| Technical Information | |
| Cable Type | Fiber Optic |
| Cable Characteristic | Patch Cable |
| Fiber Optic Mode | Multi-mode |
| Fiber Type | Duplex |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm |
| Fiber Category | OM4 |
| Cable Length | 164 ft (50 m) |
| Outer Diameter | 0.12" (3 mm) |
| Connector Type on First End | MPO-12/APC Network - Female |
| Connector Gender on First End | Female |
| Connector on First End Details | 1 x MPO-12/APC Network - Female |
| Connector Type on Second End | MPO-12/APC Network - Female |
| Connector Gender on Second End | Female |
| Connector on Second End Details | 1 x MPO-12/APC Network - Female |
| Shielding | No |
| Jacket Type | OFNG,LSZH |
| Device Supported | Network Device |
| Data Transfer Rate | 100 Gbit/s |
| Boot Type | Standard |
| Features | Angled Physical Contact (APC) |
| Physical Characteristics | |
| Color Family | Green |
| Product Color | Aqua |
| Connector Color | Green |
| Jacket Material | Low Smoke Zero Halogen |
| Weight (Approximate) | 2.50 lb (1133.98 g) |
| Miscellaneous | |
| Application/Usage | Indoor |
| Country of Origin | China |
| TAA Compliant | No |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum data rate this cable supports?
This OM4 fiber patch cable supports data transfer rates up to 100 Gbit/s, making it suitable for 100 Gigabit Ethernet (100GbE) and other high-speed applications over distances up to the rated 50 meters. The OM4 category is optimized for 100G parallel optics and can also support lower speeds like 40G and 25G with appropriate transceivers.
What type of connectors does this cable use?
The cable has MPO-12/APC female connectors on both ends. MPO-12 refers to a 12-fiber multi-fiber push-on connector, while APC (Angled Physical Contact) means the fiber end face is polished at an 8-degree angle to reduce back reflection. The connectors are color-coded green for APC single-mode or APC multi-mode identification.
Is this cable compatible with standard QSFP28 modules?
Yes, this cable is designed for use with QSFP28 and other 100G optical transceivers that feature MPO-12/APC interfaces. It works with both SR4 and PSM4 optics, provided the transceiver supports multi-mode fiber and the correct connector polarity. Always verify compatibility with your specific equipment.
What is the jacket material and its rating?
The jacket is made of Low Smoke Zero Halogen (LSZH) material and is rated OFNG (Optical Fiber Non-conductive General Purpose). This means the cable is suitable for indoor use in riser or general-purpose spaces and emits low smoke and no halogen toxic gases in case of fire, enhancing safety in confined areas.
Is this cable shielded?
No, this fiber optic cable does not have metal shielding. Fiber cables are immune to electromagnetic interference (EMI) and radio frequency interference (RFI), so shielding is not required for data integrity. The lack of shielding also reduces weight and cost.
What is the difference between OM4 and OM3 fiber?
OM4 fiber has a higher modal bandwidth than OM3, typically 4700 MHz·km compared to 2000 MHz·km for OM3. This allows OM4 to support longer distances at high data rates: for 100GbE, OM4 reaches 150 meters while OM3 reaches 100 meters. The 50-meter length of this cable is well within the capability of both, but OM4 provides additional margin and future-proofing.
