Adtran 1700102G1 QUAD FXS VIM2 Voice Interface Module - 4 x RJ-11 FXS Ports for NetVanta 6000 Series
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This voice interface module implements the VIM2 architecture with dedicated FXS circuitry for reliable analog signaling. Each of the four RJ-11 ports provides standard FXS functionality with proper voltage and signaling for analog station equipment.
The module operates as a dedicated voice resource within compatible NetVanta gateways, handling call processing and signaling conversion between analog endpoints and IP telephony systems. The interface maintains compatibility with traditional analog device requirements while integrating with modern VoIP protocols.
Key Product Advantages
The QUAD FXS VIM2 delivers practical advantages for businesses maintaining mixed telephony environments. The module's four-port design offers efficient density for connecting multiple analog devices through a single expansion slot.
Legacy Device Support
Maintains connectivity for POTS phones, FAX machines, and modems that remain essential for business operations.
- Standard FXS signaling
- RJ-11 compatibility
- Analog voltage requirements
Gateway Integration
Designed specifically for NetVanta 6000 Series gateways, ensuring proper mechanical and electrical compatibility.
- Direct slot insertion
- Power from gateway
- Management integration
Deployment Flexibility
Supports various NetVanta 6330 configurations including 8, 16, and 24 FXS models, plus the NetVanta 6310 gateway.
- Multiple gateway options
- Scalable port counts
- Consistent configuration
Deployment / Use Cases
The QUAD FXS VIM2 serves critical roles in telephony migration scenarios and mixed-environment deployments. Organizations transitioning from traditional PBX systems to VoIP solutions can use this module to maintain essential analog connections during phased migrations.
Common deployment scenarios include connecting lobby phones, emergency lines, elevator phones, FAX machines for legal or medical documentation, and analog modems for alarm systems or legacy equipment. The module also supports analog phones in areas where IP phones may not be practical or cost-effective.
PBX Migration
Enables gradual transition from traditional phone systems by maintaining analog device functionality while deploying IP telephony.
Specialized Device Support
Provides connectivity for equipment that requires analog interfaces, such as medical alert systems, building security devices, and legacy business machines.
Highlights
- Four RJ-11 FXS ports for analog device connectivity
- Designed for NetVanta 6000 Series IP business gateways
- Supports POTS phones, FAX machines, and modems
- VIM2 architecture for reliable analog signaling
- Compatible with NetVanta 6310 and 6330 gateways
- Enables mixed analog and IP telephony environments
- Preserves legacy equipment investments
- Direct slot insertion with gateway power
Specifications
| Specifications | |
|---|---|
| Manufacturer | Adtran |
| Manufacturer Part Number | 1700102G1 |
| Brand Name | Adtran |
| Product Name | QUAD FXS VIM2 |
| Product Type | Voice Module |
| Technical Information | |
| Application/Usage | Voice |
| Interfaces/Ports | |
| Total Number of Ports | 4 |
| Connector Type | RJ-11 |
| Interfaces/Ports Details | 4 x RJ-11 FXS Network |
| Miscellaneous | |
| Compatibility | NetVanta 6000 Series IP Business Gateways: NetVanta 6310 NetVanta 6330, 16 FXS NetVanta 6330, 24 FXS NetVanta 6330, 8 FXS |
FAQ
What types of analog devices can I connect to this module?
The QUAD FXS VIM2 supports standard analog devices including POTS (Plain Old Telephone Service) phones, FAX machines, and analog modems. These connections maintain traditional telephony functionality while integrating with IP-based voice systems through compatible NetVanta gateways.
Which NetVanta gateways are compatible with this voice interface module?
This module is designed for the NetVanta 6000 Series IP Business Gateways, specifically the NetVanta 6310 and various NetVanta 6330 configurations including 8 FXS, 16 FXS, and 24 FXS models. The module inserts directly into compatible expansion slots on these gateways.
How many analog devices can I connect with a single module?
The QUAD FXS VIM2 provides four RJ-11 FXS ports, allowing connection of up to four separate analog devices. Each port delivers standard FXS signaling with proper voltage and interface characteristics for reliable analog device operation.
What is the difference between FXS and FXO ports?
FXS (Foreign Exchange Station) ports provide dial tone and connect to end devices like phones and FAX machines. FXO (Foreign Exchange Office) ports receive dial tone and connect to telephone company lines. This module features FXS ports specifically for connecting analog station equipment.
