AIC XP1-P201AG01 HP201-AG 2U Rackmount Barebone System - Socket SP3 - AMD EPYC Support - DDR4-3200 - 24 Expansion Bays - Dual Power Supplies
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The HP201-AG features an AMD chipset architecture with comprehensive I/O connectivity including two USB 3.0 ports, dual SATA interfaces, and a VGA port for basic display output via the integrated AST2500 graphics controller. Network connectivity is provided through a single RJ-45 Ethernet port, supporting standard Ethernet technology for network integration.
Storage management is handled by a Serial ATA/600 controller, while the system includes two M.2 interfaces for high-speed NVMe storage options. The thermal design power of 280W ensures efficient heat dissipation, and the system complies with RoHS environmental standards for reduced hazardous substances.
Relevant factors for this section include Number of Nodes, Number of Processors Supported, Processor Socket, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This barebone system combines enterprise-grade expansion capacity with reliable power infrastructure in a compact 2U footprint. The 24 expansion bays provide exceptional storage scalability, while the dual redundant power supplies ensure continuous operation for critical workloads.
High-Density Expansion
With 24 expansion bays and three PCIe x16 slots, the HP201-AG supports extensive storage arrays and specialized hardware accelerators without requiring additional rack space.
- 24 total expansion bays
- 3 PCI Express x16 slots
- 2 M.2 interfaces for NVMe storage
Redundant Power Architecture
Dual 2kW power supplies with 120/230V AC input provide power redundancy and high-capacity delivery for demanding server configurations.
- 2 installed power supplies
- 2kW maximum wattage each
- 120/230V AC input voltage
Modern Memory Platform
Eight DDR4-3200 memory slots support up to 2TB of high-speed RAM, delivering optimal performance for memory-intensive applications and virtualization workloads.
- DDR4-3200/PC4-25600 standard
- 8 memory slots
- 2TB maximum capacity
Deployment / Use Cases
The HP201-AG is engineered for data center environments where rack space optimization, expansion flexibility, and power redundancy are critical requirements. Its 2U form factor makes it suitable for high-density server deployments while maintaining accessibility for maintenance and upgrades.
Primary deployment scenarios include storage servers with extensive drive arrays, virtualization hosts requiring substantial memory and expansion capabilities, and specialized compute nodes for HPC or AI workloads. The barebone configuration allows IT teams to customize processor, memory, and storage components to match specific application requirements while leveraging the robust chassis infrastructure.
Storage Server Deployment
Ideal for NAS or SAN implementations with the 24 expansion bays supporting multiple drive configurations and RAID arrays for data storage and backup solutions.
Virtualization Host Platform
Supports virtualization environments with substantial memory capacity, multiple PCIe slots for network adapters, and redundant power for continuous VM operation.
Physical Profile
The HP201-AG occupies a standard 2U rack space with dimensions of 3.50" (88.90 mm) height, 17.20" (436.88 mm) width, and 30.70" (779.78 mm) depth. The rack-mountable form factor includes standard mounting hardware for secure installation in 19-inch server racks. The compact 2U height maximizes rack density while providing sufficient internal space for cooling and component accessibility.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 2U, 17.20" (436.88 mm), 30.70" (779.78 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.20" (436.88 mm)
- Depth
- 30.70" (779.78 mm)
- Height
- 2U
Highlights
- 2U rackmount barebone system for data center deployment
- Supports single AMD EPYC processors with Socket SP3
- Eight DDR4-3200 memory slots supporting up to 2TB RAM
- 24 total expansion bays for extensive storage arrays
- Three PCI Express x16 slots for expansion cards
- Dual 2kW power supplies with 120/230V AC input
- Two M.2 interfaces for high-speed NVMe storage
- Serial ATA/600 controller for storage management
- Integrated AST2500 graphics controller with VGA output
- RoHS compliant for reduced environmental impact
Specifications
| Specifications | |
|---|---|
| Manufacturer | Advanced Industrial Computer, Inc |
| Manufacturer Part Number | XP1-P201AG01 |
| Brand Name | AIC |
| Product Model | HP201-AG |
| Product Name | HP201-AG Barebone System |
| Product Type | Barebone System |
| Processor | |
| Number of Nodes | 4 |
| Number of Processors Supported | 1 |
| Processor Socket | Socket SP3 |
| Processor Supported | EPYC |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Maximum Memory Supported | 2 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-3200/PC4-25600 |
| Total Number of Memory Slots | 8 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Display & Graphics | |
| Graphics Controller Model | AST2500 |
| Network & Communication | |
| Ethernet Technology | Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 24 |
| Total Number of Expansion Slots | 3 |
| Number of PCI Express x16 Slots | 3 |
| Number of M.2 Interfaces | 2 |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of SATA Interfaces | 2 |
| Number of VGA Ports | 1 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 2 kW |
| Thermal Design Power | 280 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.50" (88.90 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 30.70" (779.78 mm) |
| Miscellaneous | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
What processor socket does the HP201-AG barebone system use?
The HP201-AG utilizes the Socket SP3 processor socket, which is designed specifically for AMD EPYC server processors. This socket supports single processor configurations and provides the necessary interface for EPYC CPUs with their advanced memory and I/O capabilities in server environments.
How much memory can the HP201-AG system support?
This barebone system supports up to 2TB of DDR4 memory across eight memory slots. It uses DDR4-3200/PC4-25600 memory technology, which provides high-speed data transfer rates while maintaining power efficiency for server workloads requiring substantial RAM capacity.
What expansion capabilities does the HP201-AG offer?
The HP201-AG provides extensive expansion with 24 total expansion bays, three PCI Express x16 slots, and two M.2 interfaces. This configuration allows for substantial storage arrays, multiple network adapters, GPU accelerators, and high-speed NVMe storage, making it suitable for storage servers and specialized compute applications.
What power supply configuration does this system include?
The system comes with two installed power supplies, each capable of delivering up to 2kW of power. These power supplies support 120V and 230V AC input voltages, providing redundancy for critical applications and sufficient power capacity for fully populated configurations with multiple drives and expansion cards.
What are the physical dimensions and rack requirements?
The HP201-AG measures 3.50" (88.90 mm) in height, 17.20" (436.88 mm) in width, and 30.70" (779.78 mm) in depth, occupying a standard 2U rack space. It is designed for installation in 19-inch server racks and includes the necessary mounting hardware for secure data center deployment.
What storage interfaces are available on the HP201-AG?
The system includes a Serial ATA/600 controller supporting two SATA interfaces for traditional storage drives, along with two M.2 interfaces for high-speed NVMe storage options. This combination allows for flexible storage configurations ranging from high-capacity SATA arrays to performance-optimized NVMe solutions.
