APC by Schneider Electric APDU11452ME NetShelter Advanced Gen 2 Rack PDU - Metered - 3-Phase - 17. 3kW - 208V 60A - 42 Outlets - 0U Vertical Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This metered PDU operates on three-phase power with a 230V AC input and delivers 208V AC output at 60A current capacity. The 17.3 kW load capacity supports demanding power requirements for contemporary IT equipment, while the intelligent metering provides real-time power consumption data at the PDU level.
The outlet configuration includes 42 receptacles with a versatile 4-in-1 combination design that accommodates C13, C15, C19, and C21 connectors in a single outlet footprint. This flexibility simplifies cable management and supports mixed equipment deployments without requiring multiple PDU types.
This section brings together practical product details such as PDU Type, Phase, Plug/Connector Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The NetShelter Advanced Gen 2 PDU combines high power density with intelligent management features that address the evolving needs of modern data centers. The Live Swap NMC3 provides enhanced cybersecurity features and compatibility with EcoStruxure IT infrastructure management software, creating a secure and integrated power management ecosystem.
Intelligent Power Management
The NMC3 management card enables detailed power monitoring, remote configuration, and alerting through multiple interface options, helping optimize power utilization and prevent overload conditions.
- Web-based management interface
- SNMP v1/v2c/v3 support
- Command-line interface access
- Enhanced cybersecurity features
Flexible Outlet Configuration
The 4-in-1 combination outlet design eliminates the need for multiple PDU types by supporting four different connector types in each outlet position.
- C13, C15, C19, and C21 compatibility
- 21 outlets of each configuration type
- Simplified cable management
- Reduced inventory requirements
Deployment / Use Cases
This PDU is engineered for deployment in data centers, server rooms, and network closets where high-density power distribution and intelligent management are required. The 0U vertical mounting design makes it ideal for side-mount installation in standard 19-inch racks, preserving valuable rack space for active equipment.
The unit excels in environments supporting AI infrastructure, high-performance computing clusters, and enterprise server deployments where power density and monitoring capabilities are critical. The three-phase power distribution and 17.3 kW capacity make it suitable for powering multiple high-wattage servers, storage arrays, and networking equipment from a single distribution point.
Physical Profile
The PDU features a compact vertical design measuring 70.08 inches in height, 2.20 inches in width, and 2.95 inches in depth, optimized for side-mount installation in standard server racks. The 0U rack height requirement means it occupies no vertical rack units, preserving all available space for active equipment. The unit includes a 9.8-foot power cord for flexible installation options within rack enclosures.
- Width
- 2.20" (55.88 mm)
- Depth
- 2.95" (74.93 mm)
- Height
- 0U
- Weight
- 23.59 lb (10700.24 g)
- Length
- 9.8 ft (3 m)
Highlights
- 17.3 kW three-phase power capacity for high-density applications
- 42 outlets with 4-in-1 combination design (C13/C15/C19/C21 compatible)
- Live Swap Network Management Card 3 with web, SNMP, and CLI interfaces
- Vertical 0U rack mounting preserves valuable rack space
- Enhanced cybersecurity features and EcoStruxure IT compatibility
- 230V AC input to 208V AC output at 60A current rating
- Includes 1-year free subscription to Secure NMC3 System
- 3-year limited warranty with RoHS, REACH, and China RoHS compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | APDU11452ME |
| Brand Name | APC by Schneider Electric |
| Product Line | NetShelter |
| Product Name | NetShelter 42-Outlets PDU |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Metered |
| Phase | Three Phase |
| Plug/Connector Type | IEC 60309 60A 3P+PE |
| Receptacle Type | IEC 60320 C13/C15/C19/C21,IEC 60320 C13/C15 |
| Receptacle Detail | 21 x IEC 60320 C13/C15/C19/C21,21 x IEC 60320 C13/C15 |
| Load Capacity (Watt) | 17.30 kW |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Power Source | Power Supply |
| Input Current | 60 A |
| Management | |
| Management | NMC3 Web SNMP CLI |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Mounting Orientation | Vertical |
| Mount Type | Rack-mountable |
| Form Factor | Rack |
| Placement | Side |
| Rack Height | 0U |
| Cord Length | 9.8 ft (3 m) |
| Height | 70.08" (1780.03 mm) |
| Width | 2.20" (55.88 mm) |
| Depth | 2.95" (74.93 mm) |
| Weight (Approximate) | 23.59 lb (10700.24 g) |
| Environmental Conditions | |
| Maximum Operating Temperature | 140°F (60°C) |
| Miscellaneous | |
| Application/Usage | IT Equipment,Data Center,Server/Network Rack |
| TAA Compliant | No |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this APC NetShelter PDU?
This PDU provides 17.3 kW (17,300 watts) of load capacity, making it suitable for high-density server deployments and AI infrastructure. The three-phase configuration delivers this power through 42 outlets with intelligent metering capabilities for precise power monitoring and management.
How many outlets does this rack PDU have and what types are supported?
The PDU features 42 outlets with a versatile 4-in-1 combination design. It includes 21 outlets supporting C13, C15, C19, and C21 connectors in a single footprint, plus 21 additional outlets supporting C13 and C15 connectors. This configuration accommodates a wide range of server, storage, and networking equipment power cords.
What rack mounting options are available for this power distribution unit?
This PDU is designed for vertical 0U rack mounting, meaning it installs on the side of standard 19-inch server racks without consuming any vertical rack units. The vertical orientation and 0U footprint maximize usable rack space for active equipment while providing comprehensive power distribution.
What management capabilities does the NMC3 card provide?
The Live Swap Network Management Card 3 offers web-based management, SNMP (v1/v2c/v3) support, and command-line interface access for remote monitoring and configuration. It includes enhanced cybersecurity features and is compatible with EcoStruxure IT software for integrated infrastructure management.
What input and output voltages does this three-phase PDU support?
The PDU accepts 230V AC three-phase input and delivers 208V AC output at 60A current capacity. This voltage configuration is standard for North American data center environments and supports efficient power distribution to server and networking equipment.
What is included with the Secure NMC3 System subscription?
The PDU includes a 1-year free subscription to the Secure NMC3 System, which provides enhanced security features for the network management card. This subscription helps protect against cybersecurity threats while maintaining compatibility with EcoStruxure IT infrastructure management platforms.
What power capacity is listed for this UPS?
The listed power specification is 17.30 kW, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 230 V AC, which helps position the unit for the right load level and installation role.
