APC by Schneider Electric APDU10350SM APC NetShelter Switched Rack PDU - 48 Outlets - 17. 3kW/17. 3kVA - 3-Phase - IEC 60309 Input - Vertical 0U
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switched PDU features a robust power architecture with dual input voltage support (415V and 480V) and a wide input range from 200-240V AC to 346-415V AC. The output delivers consistent 240V AC power to connected equipment, with active monitoring of volts, amps, kW, and kWh through the integrated network interface.
The outlet configuration includes 24 IEC 60320 C13/C15/C19/C21 receptacles and 24 IEC 60320 C13/C15 receptacles, providing flexibility for various equipment power cords. The IEC 60309 30A 3P+N+PE input connector ensures secure three-phase power connection, while the 5.9-foot power cord offers installation flexibility.
This section brings together practical product details such as PDU Type, Phase, Plug/Connector Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Advanced Power Management, High-Density Power Distribution.
For buyers comparing similar models, the strongest advantage is usually the balance between dependable day-to-day operation and a simpler rollout experience. That means less time spent troubleshooting fit, compatibility, or user adoption after installation, which is especially important for shared business environments and repeat purchasing decisions.
Advanced Power Management
Network connectivity enables remote monitoring, outlet-level control, and power sequencing through web, SNMP, or Telnet interfaces. The interactive LCD provides local status and configuration access without network dependency.
High-Density Power Distribution
With 48 outlets in a compact vertical form factor, this PDU maximizes power availability while minimizing rack space consumption. The 0U side-mount design preserves valuable rack units for equipment installation.
Deployment / Use Cases
This PDU is engineered for demanding environments where power density, management, and reliability are critical. It serves as the foundation for power distribution in data center racks, network closets, and server rooms supporting enterprise IT infrastructure.
The switched functionality makes it ideal for environments requiring remote power cycling of individual devices for troubleshooting or maintenance. The three-phase power capacity supports high-density server deployments, blade chassis, and storage arrays that demand substantial power budgets.
This section brings together practical product details such as PDU Type, Phase, Plug/Connector Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Data Center Racks
Provides managed power distribution for full-height server racks with mixed equipment types, enabling load balancing and remote management of critical infrastructure.
Network Equipment Closets
Delivers reliable power to switches, routers, and security appliances with outlet-level control for network device management and recovery procedures.
Physical Profile
The PDU features a sleek black design with vertical mounting orientation for side-rack installation. With dimensions of 70.08" height × 2.20" width × 2.95" depth (1780 × 56 × 75 mm) and weighing approximately 21.16 lb (9.6 kg), it maintains a low-profile presence while delivering substantial power capacity. The 0U rack height preserves all usable rack space for equipment, and the vertical form factor promotes organized cable routing along the rack side.
- Width
- 2.20" (56 mm)
- Depth
- 2.95" (75 mm)
- Height
- 0U
- Weight
- 21.16 lb (9598.01 g)
- Length
- 5.9 ft (1.80 m)
Highlights
- 48 total outlets: 24 C13/C15/C19/C21 + 24 C13/C15 receptacles
- 17.3kW/17.3kVA three-phase power capacity
- Switched PDU with network management capability
- Interactive LCD display for local monitoring
- Vertical 0U side-mount rack installation
- IEC 60309 30A 3P+N+PE input connector
- Active power measurements (volts, amps, kW, kWh)
- 3-year APC warranty with RoHS compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | APDU10350SM |
| Brand Name | APC by Schneider Electric |
| Product Line | NetShelter |
| Product Name | NetShelter 48-Outlets PDU |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Switched |
| Phase | Three Phase |
| Plug/Connector Type | IEC 60309 30A 3P+N+PE |
| Receptacle Type | IEC 60320 C13/C15/C19/C21,IEC 60320 C13/C15 |
| Receptacle Detail | 24 x IEC 60320 C13/C15/C19/C21,24 x IEC 60320 C13/C15 |
| Power Description | |
| Input Voltage | 415 V,480 V |
| Input Voltage Range | 200 V AC - 240 V AC,346 V AC - 415 V AC |
| Output Voltage | 240 V AC |
| Power Rating (VA) | 17.30 kVA |
| Power Rating (Watt) | 17.30 kW |
| Input Current | 30 A |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Mounting Orientation | Vertical |
| Form Factor | Rack |
| Placement | Side |
| Rack Height | 0U |
| Cord Length | 5.9 ft (1.80 m) |
| Height | 70.08" (1780 mm) |
| Width | 2.20" (56 mm) |
| Depth | 2.95" (75 mm) |
| Weight (Approximate) | 21.16 lb (9598.01 g) |
| Miscellaneous | |
| Country of Origin | India |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this APC NetShelter PDU?
This PDU delivers 17.3 kilowatts (17.3 kW) and 17.3 kilovolt-amperes (17.3 kVA) of three-phase power capacity. It supports input currents up to 30 amps and provides 240V AC output to connected equipment, making it suitable for high-density rack environments with substantial power requirements.
How many outlets does this rack PDU provide and what types are they?
The PDU features 48 total outlets configured as 24 IEC 60320 C13/C15/C19/C21 receptacles and 24 IEC 60320 C13/C15 receptacles. This mixed configuration accommodates various equipment power cords, from standard server and network device cables to higher-amperage connections for power-hungry equipment.
What rack mounting options does this PDU support?
This is a vertical-mount PDU designed for side installation in standard 19-inch racks. It occupies 0U of rack height, preserving all usable rack space for equipment. The vertical orientation promotes organized cable management along the rack side while maintaining a compact profile of just 2.20 inches wide.
What network management capabilities does this switched PDU offer?
The PDU includes full-featured network management through its RJ-45 interface, supporting web, SNMP, and Telnet access. It provides outlet-level control for individual power cycling, power sequencing capabilities, and active monitoring of voltage, current, power (kW), and energy consumption (kWh). The integrated interactive LCD display offers local access to status and configuration without network dependency.
What input voltage does this three-phase PDU require?
This PDU accepts 415V or 480V three-phase input power with a wide input voltage range from 200-240V AC to 346-415V AC. It uses an IEC 60309 30A 3P+N+PE connector for secure three-phase power connection, making it compatible with standard three-phase power distribution systems in data centers and commercial facilities.
What warranty coverage does this APC PDU include?
APC provides a 3-year limited warranty for this NetShelter PDU. The unit is also RoHS (Restriction of Hazardous Substances) compliant and manufactured in India with environmentally friendly construction practices, ensuring reliable performance and regulatory compliance for enterprise deployments.
What power capacity is listed for this UPS?
The listed power specification is 17.30 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 415 V,480 V, which helps position the unit for the right load level and installation role.
