APC by Schneider Electric SRT6KXLT-IEC APC Smart-UPS SRT 6000VA 208V IEC Double-Conversion Online UPS - 6kVA/6kW Tower with Network Card & SmartSlot
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This double-conversion online UPS operates with single-phase input and output, accepting 208V or 240V AC and delivering the same voltage with a sine wave output. The transfer time is 0 nanoseconds, providing seamless power continuity for sensitive electronics. The DC system voltage is 192V DC, powered by a single hot-swappable lead-acid battery that is user-replaceable.
Management capabilities include SNMP/Webcard support, a multifunction LCD status and control console, and interfaces such as serial, network RJ-45, EPO, and USB HID-compliant ports. The unit features overload protection and a surge energy rating of 480 joules for added safety.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Smart-UPS SRT series combines robust power protection with advanced management features, making it ideal for environments where uptime is critical. Its double-conversion technology isolates connected equipment from power anomalies, while the pure sine wave output ensures compatibility with sensitive server power supplies and medical equipment.
Network-Based Management
The embedded network management card enables remote monitoring, configuration, and graceful shutdown of physical servers, virtual machines, and HCI clusters via a 1-year secure subscription included.
- SNMP/Webcard support
- Remote monitoring and alerts
- Graceful shutdown capabilities
Scalable Runtime
Support for up to 10 external SRT192BP battery packs allows for runtime extension to meet specific backup requirements, providing flexibility for growing IT loads.
- External battery pack support
- Extended runtime options
- Scalable power backup
Rack/Tower Convertible Design
The unit ships as a tower with removable support feet and can be converted to rack mount using optional rail kits (SRTRK2 or SRTRK3), adapting to various installation environments.
- Tower form factor
- Rack-mountable option
- Installation flexibility
Deployment / Use Cases
This UPS is designed for IT equipment in environments where power quality and availability are paramount. Its 6kVA capacity and double-conversion topology make it suitable for protecting servers, storage arrays, voice/data networks, and medical lab equipment from power disturbances.
Common deployment scenarios include small to medium server rooms, network closets, and light industrial applications. The ability to add external battery packs extends its use to situations requiring longer runtime, such as during extended power outages or for critical processes that cannot tolerate interruption.
Server and Storage Protection
Provides clean, uninterrupted power to rack-mounted servers and storage systems, ensuring data integrity and system availability during power events.
Network Infrastructure Support
Ideal for powering switches, routers, and other networking hardware in data centers or branch offices, maintaining network connectivity through power fluctuations.
Physical Profile
The UPS features a black finish and measures 17.01" (432 mm) in height, 6.85" (174 mm) in width, and 28.31" (719 mm) in depth, with a weight of approximately 131.99 lb (59.87 kg). Its rack-mountable design allows for integration into standard server racks, while the tower configuration with removable feet offers stability for floor placement. The compact footprint optimizes space utilization in equipment rooms.
- Width
- 6.85" (174 mm)
- Depth
- 28.31" (719 mm)
- Height
- 17.01" (432 mm)
- Weight
- 55 dB(A)
What's in the Box
The package includes all necessary components for setup and operation, ensuring a complete out-of-the-box experience.
Highlights
- 6kVA/6kW double-conversion online UPS with pure sine wave output
- Zero transfer time for seamless power continuity
- Tower form factor convertible to rack mount (rails sold separately)
- Embedded network management card with 1-year secure subscription
- Supports up to 10 external battery packs for extended runtime
- 12 outlets including IEC C13 and C19 receptacles
- Hot-swappable, user-replaceable lead-acid battery
- Multifunction LCD status and control console
- SmartSlot for additional communication options
- Energy Star certified and RoHS compliant
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SRT6KXLT-IEC |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS SRT |
| Product Name | Smart-UPS SRT 6000VA 208V IEC |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | Hard Wire 3-wire (2P + E) |
| Receptacle Type | IEC 60320 C13,IEC Jumper,IEC 60320 C19 |
| Receptacle Detail | 1 x Hard Wire 3-wire (2PH + G),6 x IEC 60320 C13,2 x IEC Jumper,4 x IEC 60320 C19 |
| Number of Battery & Surge Outlets | 12 |
| Overload Protection | Yes |
| Transfer Time | 0 ns |
| Phase | Single Phase |
| Application/Usage | IT Equipment |
| Power Description | |
| Load Capacity (VA) | 6 kVA |
| Load Capacity (Watt) | 6 kW |
| Input Voltage | 208 V AC,240 V AC |
| Output Voltage | 208 V AC,240 V AC |
| Input Frequency | 70 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 480 J |
| Management | |
| Network Management | SNMP/Webcard |
| Alarm | UPS Power Condition |
| Controls/Indicators | |
| Status Indicators | Multifunction LCD status and control console |
| Interfaces/Ports | |
| Serial Port | Yes |
| Network (RJ-45) | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| DC System Voltage | 192 V DC |
| Number of Batteries | 1 |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 2.30 Minute |
| Backup/Run Time (Half Load) | 8.30 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 1.50 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Thermal Dissipation | 1402 BTU/h |
| Physical Characteristics | |
| Product Color | Black |
| Height | 17.01" (432 mm) |
| Width | 6.85" (174 mm) |
| Depth | 28.31" (719 mm) |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 131.99 lb (59869.66 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS SRT 6000VA 208V IEC CD with software Documentation CD Installation guide Removable support feet Temperature probe USB cable Warranty card Web/SNMP management card |
| Software Included | Powerchute |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Battery: 24 month(s)|UPS: 36 month(s) |
User Manual
FAQ
What is the power capacity of this APC Smart-UPS SRT?
This UPS has a load capacity of 6 kVA (6000 VA) and 6 kW, making it suitable for protecting medium-density server racks, storage systems, and network infrastructure. The double-conversion online topology ensures consistent power delivery even during input fluctuations.
What are the input and output voltage specifications?
The input voltage range is 208V to 240V AC, and the output voltage is also 208V to 240V AC, providing compatibility with standard North American commercial power systems. This allows the UPS to support equipment designed for these voltages without requiring additional transformers.
How many outlets does this UPS have, and what types are they?
There are 12 battery and surge-protected outlets in total. These include 6 IEC 60320 C13 outlets, 4 IEC 60320 C19 outlets, and 2 IEC jumper outlets, along with a hard-wire 3-wire (2PH + G) receptacle for direct connection. This mix accommodates various server and networking power cords.
What is the runtime at full and half load?
At full load (6 kW), the runtime is approximately 2.3 minutes. At half load (3 kW), the runtime extends to about 8.3 minutes. These times are based on the internal battery; runtime can be significantly extended by adding optional external battery packs.
Does this UPS include network management capabilities?
Yes, it comes with an embedded network management card that supports SNMP and web-based monitoring. A 1-year secure subscription is included, enabling remote management, alerts, and graceful shutdown of connected servers and virtual machines over the network.
Can this UPS be mounted in a server rack?
Yes, the unit is rack-mountable and ships as a tower with removable support feet. To install it in a rack, you will need to purchase an optional rail kit (SRTRK2 or SRTRK3 separately). This convertible design offers flexibility for both floor and rack deployment.
What power capacity is listed for this UPS?
The listed power specification is 6 kVA, which helps position the unit for the right load level and installation role.
How many outlets are available?
The product includes 12, which helps buyers understand how many connected devices it can support in its intended deployment.
