APC by Schneider Electric SRTL5KRM2UT APC Smart-UPS Ultra On-Line - 5000VA/4. 9kVA Lithium-ion - 2U Rack/Tower - 208V - 2 L6-20R + 2 L6-30R Outlets
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This double-conversion online UPS provides complete isolation from input power irregularities, with sine wave output maintaining compatibility with power factor corrected (PFC) power supplies. The 4.90 kVA/5 kW capacity supports substantial server loads, while the 208V single-phase configuration matches common North American commercial power distribution. Input frequency tolerance of 70 Hz and output frequency of 60 Hz ensure stable operation across varying grid conditions.
The lithium-ion battery system delivers 2592 kJ of energy with a rapid 1.5-hour recharge time. DC system voltage operates at 180 V DC, and the unit includes an EPO (Emergency Power Off) port for safety integration. Thermal dissipation of 1047 BTU/h and sound emission of 55 dB(A) make this suitable for occupied server environments.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Smart-UPS Ultra combines lithium-ion battery technology with enterprise-grade power protection for reliable uptime. The 10-year battery life significantly reduces total cost of ownership by eliminating frequent battery replacements common with traditional lead-acid UPS systems. Extended runtime capability supports adding up to 10 external battery packs (SRTL180RM2UBP) for mission-critical applications requiring longer backup durations.
Network Management
Includes a 1-year subscription to secure network management capabilities for monitoring power quality, configuring alerts, and managing graceful shutdowns across physical servers, virtual machines, and HCI clusters.
- Remote monitoring via network interface
- Graceful shutdown automation
- Virtual machine protection
Deployment Flexibility
Rack/tower convertible design with included mounting brackets allows installation in standard 19-inch racks or as a standalone tower unit based on infrastructure requirements.
- 2U rack height compatibility
- Rail kit included
- Silver Gray finish
Deployment / Use Cases
This 5000VA UPS is engineered for medium-density server racks, network closets, and telecommunications equipment requiring clean, uninterrupted power. The 208V configuration makes it ideal for commercial buildings with three-phase power distribution stepped down to single-phase 208V circuits. Four NEMA outlets (2 L6-20R and 2 L6-30R) provide flexible connectivity for servers, storage arrays, and networking gear with different plug requirements.
Typical deployments include protecting virtualization hosts, database servers, and converged infrastructure where power anomalies could cause data corruption or system crashes. The double-conversion topology ensures zero transfer time during utility failures, making it suitable for applications where even momentary power interruptions are unacceptable. The unit operates at elevations up to 10,000 feet and in environments with 0-95% relative humidity storage conditions.
Data Center Rack
Install in standard 19-inch server racks to protect critical infrastructure with clean sine wave power and network-managed shutdown capabilities.
- 2U rack space efficient
- Front LCD for at-a-glance status
- EPO port for safety systems
Server Room Protection
Deploy as a tower unit in smaller server rooms or network closets where rack space is limited but power protection remains essential.
- Standalone tower configuration
- 64.37 lb weight for stability
- 55 dB(A) quiet operation
Physical Profile
The Smart-UPS Ultra measures 3.39" (86 mm) in height, 17.01" (432 mm) in width, and 27.60" (701 mm) in depth, occupying 2U of standard rack space. The Silver Gray finish provides a professional appearance that blends with enterprise hardware. At 64.37 lb, the unit has substantial weight for rack stability while remaining manageable for installation. The form factor supports both rack-mounted and tower deployments with included mounting hardware.
- Width
- 17.01" (432 mm)
- Depth
- 27.60" (701 mm)
- Height
- 3.39" (86 mm)
- Weight
- 55 dB(A)
- Length
- 10 ft (3.05 m)
What's in the Box
The package includes everything needed for immediate deployment of the UPS system.
Highlights
- 5000VA/4.9kVA double-conversion on-line pure sine wave UPS
- Lithium-ion battery with 10-year typical lifespan
- 2U rack/tower convertible design with included rail kit
- 208V input and output voltage, single phase
- 2 x NEMA L6-20R and 2 x NEMA L6-30R outlets
- 1-year secure network management card subscription included
- Supports up to 10 external battery packs for extended runtime
- Multi-function LCD status and control console
- Energy Star certified for energy efficiency
- 5-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SRTL5KRM2UT |
| Brand Name | APC by Schneider Electric |
| Product Name | Smart-UPS Ultra On-Line Lithium ion, 5KVA/5KW, 2U Rack/Tower, 208V |
| Packaged Quantity | 4 Pack |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA L6-30P |
| Receptacle Detail | 2 x NEMA L6-20R,2 x NEMA L6-30R |
| Cord Length | 10 ft (3.05 m) |
| Phase | Single Phase |
| Power Description | |
| Load Capacity (VA) | 4.90 kVA |
| Load Capacity (Watt) | 5 kW |
| Input Voltage | 208 V AC |
| Output Voltage | 208 V AC |
| Input Frequency | 70 Hz |
| Output Frequency | 60 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 1260 J |
| Controls/Indicators | |
| Status Indicators | Multi-function LCD Status and Control Console |
| Interfaces/Ports | |
| EPO Port | Yes |
| USB (HID Compliant) Port | No |
| Battery Information | |
| DC System Voltage | 180 V DC |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Energy | 2592 kJ |
| Battery Life | 10 Year |
| Typical Battery Recharge Time | 1.50 Hour |
| Environmental Conditions | |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Storage Relative Humidity | 0% - 95% |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Thermal Dissipation | 1047 BTU/h |
| Physical Characteristics | |
| Product Color | Silver Gray |
| Height | 3.39" (86 mm) |
| Width | 17.01" (432 mm) |
| Depth | 27.60" (701 mm) |
| Rack Height | 2U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 64.37 lb (29197.74 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS Ultra On-Line Lithium ion, 5KVA/5KW, 2U Rack/Tower, 208V 1 x CD (Software and Documentation) Network Cable Rack Mounting Brackets |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the power capacity of this APC Smart-UPS Ultra?
This Smart-UPS Ultra provides 4.90 kVA (5000VA) of apparent power and 5 kW of real power capacity. It operates at 208V input and output voltage with single-phase configuration, making it suitable for commercial server and network equipment requiring substantial power protection.
How does the lithium-ion battery compare to traditional UPS batteries?
The lithium-ion battery offers a 10-year typical lifespan, significantly longer than the 3-5 year lifespan of traditional lead-acid batteries. This reduces maintenance frequency and total cost of ownership. Lithium-ion batteries also recharge faster (1.5 hours typical) and maintain consistent performance throughout their lifecycle.
Can this UPS be installed in both rack and tower configurations?
Yes, this Smart-UPS Ultra is designed as a rack/tower convertible unit. It occupies 2U of rack space (3.39" height) and includes rack mounting brackets for standard 19-inch racks. The same unit can also be deployed as a standalone tower for environments where rack mounting isn't available or preferred.
What types of equipment plugs are supported by the outlets?
The UPS includes four NEMA outlets: two L6-20R receptacles and two L6-30R receptacles. These locking connectors are commonly used for server, network, and telecommunications equipment in commercial environments. The unit comes with a NEMA L6-30P plug on a 10-foot power cord for connection to 208V power sources.
How can I monitor and manage this UPS remotely?
A 1-year secure network management card subscription is included, allowing remote monitoring via network connection. This enables power quality monitoring, configuration of alerts, and graceful shutdown of physical servers, virtual machines, and HCI clusters. The multi-function LCD on the front panel provides local status information.
What warranty coverage does this APC Smart-UPS Ultra include?
The unit comes with a 5-year limited warranty from APC by Schneider Electric. The lithium-ion battery has a 10-year typical lifespan expectation. The product is Energy Star certified and complies with RoHS (Restriction of Hazardous Substances) environmental standards.
What power capacity is listed for this UPS?
The listed power specification is 4.90 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 208 V AC, which helps position the unit for the right load level and installation role.
