APC by Schneider Electric SRTL5KRM2UT-HW APC Smart-UPS Ultra On-Line 5kVA/4. 9kW Double-Conversion UPS - 208V - Lithium-ion - 2U Rack/Tower Convertible
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This double-conversion online UPS provides complete isolation from raw utility power, continuously converting AC to DC and back to AC to deliver a regulated, clean output. The 5 kVA/4.9 kW capacity supports substantial loads, while the 208V AC input and output are standard for commercial and data center power distribution.
The hardware configuration includes a NEMA L6-30P input plug and offers output via a hardwired 3-wire connection (1PH+N+G) alongside NEMA L6-20R and L6-30R receptacles, providing flexible installation options. The unit meets ENERGY STAR 2.0 efficiency standards and complies with RoHS and REACH environmental regulations.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Lithium-Ion Reliability, Rack/Tower Deployment Flexibility, Extended Runtime Scalability.
Lithium-Ion Reliability
The integrated lithium-ion battery chemistry offers a longer lifecycle and faster recharge (1.5 hours typical) compared to traditional lead-acid batteries, minimizing maintenance and replacement frequency over the UPS lifespan.
Rack/Tower Deployment Flexibility
Convertible between 2U rackmount and tower configurations with included rail kit and stabilization feet, allowing seamless integration into existing rack infrastructure or standalone placement as needed.
Extended Runtime Scalability
Support for up to 10 external battery packs (SRTL180RM2UBP) enables significant runtime extension for prolonged outages, ensuring operational continuity for critical systems.
Deployment / Use Cases
This Smart-UPS Ultra model is engineered for protecting high-density IT loads in environments where power disturbances can cause data loss, hardware damage, or downtime. Its 5kVA capacity and pure sine wave output make it ideal for sensitive server, storage, and networking equipment.
Typical applications include securing virtualized server clusters, hyperconverged infrastructure (HCI), data center racks, network operations centers, medical laboratory equipment, and light industrial control systems. The hardwired output option is particularly suited for permanent installations where direct wiring to a PDU or equipment panel is preferred.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Physical Profile
The UPS features a silver gray chassis with dimensions of 3.39" H x 17.01" W x 27.60" D (86.11 mm x 432.05 mm x 701.04 mm), occupying 2U of rack space. The convertible design includes rack mounting brackets, rail extensions, and stabilization feet for secure tower placement. At 64.37 lb, it is built with robust materials suitable for industrial use.
- Width
- 17.01" (432.05 mm)
- Depth
- 27.60" (701.04 mm)
- Height
- 3.39" (86.11 mm)
- Weight
- 64.37 lb (29197.74 g)
- Length
- 10 ft (3.05 m)
What's in the Box
The package includes all necessary components for immediate deployment and management.
Package contents include Smart-UPS Ultra On-Line 5kVA Tower/rack convertible UPS. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 5 kVA / 4.9 kW double-conversion online UPS with pure sine wave output
- Lithium-ion battery for long life and fast 1.5-hour recharge
- 2U rack/tower convertible form factor with included rail kit
- 208V AC input and output, single phase
- Hardwired 3-wire output plus NEMA L6-20R and L6-30R receptacles
- Includes network management card with 1-year subscription
- Supports up to 10 external battery packs for extended runtime
- ENERGY STAR 2.0 certified, RoHS and REACH compliant
- 5-year limited warranty
- Designed for servers, HCI, data centers, and network equipment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SRTL5KRM2UT-HW |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS Ultra |
| Product Name | Smart-UPS Ultra On-Line 5kVA Tower/rack convertible UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-30P |
| Receptacle Type | NEMA L6-20R,NEMA L6-30R,Hard Wire 3-wire |
| Receptacle Detail | 1 x Hard Wire 3-wire (1PH+N+G) |
| Cord Length | 10 ft (3.05 m) |
| Phase | Single Phase |
| Application/Usage | Network,Server,IT,Network Device,Network Equipment,Virtual Machine,Hyperconverged Infrastructure (HCI),Data Center,Storage,Voice/Data Network,Medical Laboratory,Light Industrial Application |
| Power Description | |
| Load Capacity (VA) | 5 kVA |
| Load Capacity (Watt) | 4.90 kW |
| Input Voltage | 208 V AC |
| Output Voltage | 208 V AC |
| Waveform Type | Pure Sine Wave |
| Surge Energy Rating | 1260 J |
| Management | |
| Network Management | Network Card |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Typical Battery Recharge Time | 1.50 Hour |
| Physical Characteristics | |
| Product Color | Silver Gray |
| Height | 3.39" (86.11 mm) |
| Width | 17.01" (432.05 mm) |
| Depth | 27.60" (701.04 mm) |
| Rack Height | 2U |
| Form Factor | Tower/Rack Convertible |
| Weight (Approximate) | 64.37 lb (29197.74 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS Ultra On-Line 5kVA Tower/rack convertible UPS Network cable Rack Mounting brackets USB cable front cover earth terminal block Temperature Sensor stabilization feet rail extension |
| Energy Star | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the power capacity of this APC Smart-UPS Ultra?
This UPS has a load capacity of 5 kVA (5000 VA) and 4.9 kW. It operates at 208V AC input and output, making it suitable for commercial and data center power systems supporting substantial IT loads like servers, storage arrays, and networking gear.
Does this UPS use a lithium-ion battery?
Yes, it features a lithium-ion (Li-Ion) battery. This chemistry offers advantages over traditional lead-acid, including a longer operational lifespan, reduced need for replacements, and a faster typical recharge time of 1.5 hours, enhancing reliability and lowering long-term maintenance costs.
Can this UPS be mounted in a server rack?
Yes, it is a tower/rack convertible unit designed for 2U rack mounting. The package includes rack mounting brackets and rail extensions for secure installation in standard 19-inch racks. It can also be deployed as a standalone tower using the provided stabilization feet.
What type of power output does it provide?
It delivers a pure sine wave output through double-conversion online topology, ensuring clean, stable power identical to utility quality. Output connections include one hardwired 3-wire terminal (1PH+N+G) and NEMA L6-20R and L6-30R receptacles, offering flexible wiring options for different installations.
Is network management included?
Yes, a network management card is included with a one-year subscription. This enables remote monitoring, configuration, and graceful shutdown of connected physical servers, virtual machines, and HCI clusters via network, helping to prevent data loss and equipment damage during extended power outages.
How can I extend the runtime of this UPS?
Runtime can be significantly extended by adding up to 10 external battery packs, specifically the SRTL180RM2UBP model. This scalability allows you to tailor backup duration to your critical load requirements, ensuring continuity for prolonged power interruptions in environments like data centers or medical facilities.
What power capacity is listed for this UPS?
The listed power specification is 5 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 208 V AC, which helps position the unit for the right load level and installation role.
