APC by Schneider Electric SMX3000HVTUS APC Smart-UPS X 3kVA/2700W Line Interactive UPS - 4U Rack/Tower Convertible - 208V - 11 Outlets - Sine Wave
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This line-interactive UPS delivers 3kVA (3000VA) with a 2700W watt rating, providing 6.3 minutes of runtime at full load. The 208V AC input and output configuration is optimized for commercial power systems, with a wide input voltage range of 141-280V AC for compatibility with varying power conditions.
The unit features 11 total outlets with a mix of NEMA L6-20R and IEC C13/C19 connectors to accommodate different equipment types. With 2ms transfer time and pure sine wave output, connected devices experience seamless transitions during power events without risk of damage or data corruption.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Smart-UPS X combines robust power protection with flexible deployment options. The rack/tower convertible design allows installation in standard 4U server racks or as a standalone tower, while the hot-swappable batteries enable maintenance without powering down connected equipment.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Scalable Runtime, Management & Monitoring.
Scalable Runtime
Supports up to 10 external battery packs (SMX120BP) for extended runtime requirements, allowing customization based on specific backup needs.
Management & Monitoring
Includes PowerChute Serial Edition software for graceful shutdown of connected servers via serial or USB cables, protecting data and equipment during extended outages.
Deployment / Use Cases
This 3kVA UPS is engineered for environments requiring substantial power capacity with professional-grade management features. The 208V configuration makes it particularly suitable for commercial buildings, data centers, and industrial applications where three-phase power is distributed as single-phase 208V circuits.
The combination of sufficient outlet count, scalable runtime options, and comprehensive monitoring capabilities positions this unit as a core component of business continuity plans for IT infrastructure.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Server Room Protection
Ideal for protecting servers, storage arrays, and network infrastructure in commercial environments where clean power and battery backup are essential for business continuity.
Network Equipment Support
Provides reliable power to routers, switches, hubs, and security systems, ensuring network availability during power disturbances that could disrupt communications.
Physical Profile
The black chassis measures 17.01" (432mm) high, 7.01" (178mm) wide, and 19.02" (483mm) deep, occupying 4U of standard rack space. At approximately 85.19 lb (38.64 kg), the unit is substantial yet manageable for rack installation. The short-depth design is particularly valuable in racks with limited depth, while the included rack mounting brackets facilitate secure installation in standard server racks.
- Width
- 7.01" (178 mm)
- Depth
- 19.02" (483 mm)
- Height
- 17.01" (432 mm)
- Weight
- 85.19 lb (38641.53 g)
- Length
- 8 ft (2.44 m)
What's in the Box
The package includes all essential components for immediate deployment and management of the UPS system.
Package contents include Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V CD with software Documentation CD Rack mounting brackets Smart UPS signalling RS-232 cable USB cable User manual, Powerchute Serial Edition, Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- 3kVA/2700W line interactive UPS with pure sine wave output
- 4U rack/tower convertible design with short-depth chassis
- 208V input and output voltage for commercial applications
- 11 total outlets: 2×IEC C19, 2×NEMA L6-20R, 4×IEC C13
- Supports up to 10 external battery packs for extended runtime
- Includes PowerChute Serial Edition for graceful server shutdown
- Automatic Voltage Regulation maintains stable output
- Hot-swappable batteries enable maintenance without downtime
- LCD front panel for real-time status monitoring
- 3-year UPS warranty with 2-year battery warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMX3000HVTUS |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS X |
| Product Model | SMX3000HVTUS |
| Product Name | Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V |
| Product Type | Line-interactive UPS |
| Technical Information | |
| Plug/Connector Type | NEMA L6-20P |
| Receptacle Type | NEMA L6-20P |
| Receptacle Detail | 2 x IEC 320-C19,2 x NEMA L6-20R,3 x IEC Jumper,4 x IEC 320-C13 |
| Number of Battery & Surge Outlets | 11 |
| Cord Length | 8 ft (2.44 m) |
| Transfer Time | 2 ms |
| Phase | Single Phase |
| Application/Usage | Server,Router,Network Switch,Network Hub,Security System,Network Device |
| Power Description | |
| Load Capacity (VA) | 3 kVA |
| Load Capacity (Watt) | 2.70 kW |
| Input Voltage | 208 V AC |
| Input Voltage Range | 141 V AC - 280 V AC |
| Output Voltage | 208 V AC |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 645 J |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 6.30 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 3 Hour |
| Physical Characteristics | |
| Product Color | Black |
| Height | 17.01" (432 mm) |
| Width | 7.01" (178 mm) |
| Depth | 19.02" (483 mm) |
| Rack Height | 4U |
| Form Factor | Rack-mountable |
| Weight (Approximate) | 85.19 lb (38641.53 g) |
| Miscellaneous | |
| Package Contents | Smart-UPS X 3000VA Short Depth Tower/Rack Convertible LCD 208V CD with software Documentation CD Rack mounting brackets Smart UPS signalling RS-232 cable USB cable User manual |
| Software Included | Powerchute Serial Edition |
| Energy Star | Yes |
| Country of Origin | Philippines |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | UPS: 36 month(s)|Battery: 24 month(s) |
User Manual
FAQ
What is the power capacity of this APC Smart-UPS X?
This Smart-UPS X delivers 3kVA (3000VA) with a 2700W watt rating. The line-interactive design provides battery backup and voltage regulation for connected equipment, with pure sine wave output ensuring compatibility with sensitive servers and networking gear.
How long will this UPS run at full load during a power outage?
At full load (2700W), the internal batteries provide approximately 6.3 minutes of runtime. This allows sufficient time for connected servers to perform graceful shutdowns via PowerChute software or for short-duration power interruptions to resolve without system disruption.
What types of outlets does this UPS include?
The unit features 11 total outlets: 2 IEC 320-C19 connectors, 2 NEMA L6-20R receptacles, and 4 IEC 320-C13 connectors, plus 3 IEC jumper outlets. This mix accommodates various equipment types commonly found in server rooms and network closets.
Can I extend the runtime of this UPS?
Yes, this Smart-UPS X supports up to 10 external battery packs (model SMX120BP) for significantly extended runtime. This scalability allows customization based on specific backup requirements for different applications and environments.
Is this UPS rack-mountable or tower-style?
This is a convertible 4U unit that can be installed as either a rack-mounted device or a standalone tower. The package includes rack mounting brackets for standard server rack installation, while the design also functions effectively as a tower unit where rack space isn't available.
What management software is included with this UPS?
The package includes PowerChute Serial Edition software, which enables graceful shutdown of connected servers via the included serial or USB cables. This protects data and equipment during extended power outages by properly closing applications and shutting down operating systems.
What power capacity is listed for this UPS?
The listed power specification is 3 kVA, which helps position the unit for the right load level and installation role.
How many outlets are available?
The product includes 11, which helps buyers understand how many connected devices it can support in its intended deployment.
