Ortronics UF-RJ45-10G-A Ubiquiti SFP+ Module - 10GBase-TX RJ-45 Copper Transceiver - 10GbE over Twisted Pair
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SFP+ module operates as a copper transceiver, converting electrical signals for transmission over Category 6a or better twisted pair cabling. It features a single RJ-45 port that supports 10GBase-TX network technology, delivering full-duplex 10GbE performance with low latency and reliable data integrity.
The module is designed for data networking applications where high-bandwidth copper connections are required. It supports standard Ethernet frames and auto-negotiation for seamless integration into existing network environments. Its environmental compliance with RoHS standards ensures it meets regulatory requirements for hazardous substance restrictions.
Key Product Advantages
This module offers several advantages for network deployments requiring high-speed copper connectivity. Its ability to leverage existing twisted pair infrastructure reduces cabling costs and simplifies upgrades to 10GbE networks.
Cost-Effective 10GbE Upgrade
Eliminates the need for expensive fiber optic cabling by utilizing standard Category 6a or better twisted pair cables for 10GbE performance.
- Uses existing copper infrastructure
- Reduces deployment costs
- Simplifies network upgrades
Ubiquiti Compatibility
Designed for seamless integration with Ubiquiti switches and other SFP+ compatible networking equipment that support copper transceivers.
- Hot-pluggable design
- Wide compatibility
- Easy installation
Reliable Performance
Delivers consistent 10GbE throughput with 10GBase-TX technology, ensuring stable data transfer for critical networking applications.
- Full-duplex operation
- Low latency
- Signal integrity
Deployment / Use Cases
The UF-RJ45-10G-A SFP+ module is ideal for scenarios where high-bandwidth copper connections are needed between network switches, servers, or storage devices. Its 10GbE capability makes it suitable for backbone links, server access connections, and network aggregation points in enterprise environments.
Common deployment scenarios include connecting switches in data center racks using existing copper cabling, upgrading campus network links to 10GbE without rewiring, and providing high-speed server connectivity in server rooms. The module's compact size and hot-pluggable design allow for flexible installation and easy maintenance in dense network environments.
Data Center Interconnects
Connect top-of-rack switches to aggregation switches using cost-effective copper cabling for 10GbE performance.
Enterprise Network Upgrades
Upgrade existing 1GbE copper links to 10GbE without replacing cabling infrastructure, extending the life of current installations.
Physical Profile
The module features a compact form factor measuring 0.55" (13.97 mm) in height, 0.54" (13.66 mm) in width, and 2.80" (71.12 mm) in depth. This small footprint allows for high-density installations in switch chassis with multiple SFP+ slots. The standard SFP+ dimensions ensure proper fit in compatible ports, while the RJ-45 connector provides a secure connection to twisted pair cables.
- Width
- 0.54" (13.66 mm)
- Depth
- 2.80" (71.12 mm)
- Height
- 0.55" (13.97 mm)
Highlights
- 10 Gigabit Ethernet copper SFP+ transceiver module
- 10GBase-TX technology for 10 Gbit/s data transfer
- Single RJ-45 port for twisted pair cabling
- Maximum distance of 0.03 km (0.02 miles)
- Hot-pluggable SFP+ form factor
- Compatible with Ubiquiti and other SFP+ switches
- RoHS compliant for environmental safety
- Lifetime limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | UF-RJ45-10G-A |
| Brand Name | Approved Networks |
| Product Name | Ubiquiti SFP+ Module |
| Product Type | SFP+ |
| Technical Information | |
| Application/Usage | Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | RJ-45 |
| Interfaces/Ports Details | 1 x RJ-45 10GBase-TX Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-TX |
| Maximum Distance Supported | 0.03 km (0.02 Mile) |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 0.55" (13.97 mm) |
| Width | 0.54" (13.66 mm) |
| Depth | 2.80" (71.12 mm) |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
FAQ
What type of cabling does this SFP+ module support?
This module supports twisted pair cabling, specifically Category 6a or better Ethernet cables. It uses standard RJ-45 connectors to deliver 10 Gigabit Ethernet performance over copper infrastructure, making it compatible with existing cabling systems in most enterprise environments.
What is the maximum data transfer rate of this module?
The module delivers a maximum data transfer rate of 10 Gbit/s using 10GBase-TX technology. This provides full-duplex 10 Gigabit Ethernet connectivity suitable for high-bandwidth applications such as data center interconnects, server access, and network backbone links.
How far can this module transmit data over copper cabling?
It supports transmission distances up to 0.03 km (approximately 0.02 miles or 30 meters) over twisted pair cabling. This distance is typical for 10GBase-TX copper connections and is sufficient for most rack-to-rack or within-room networking applications in data centers and enterprise environments.
Is this module compatible with non-Ubiquiti switches?
While designed for Ubiquiti equipment, this SFP+ module should work with any switch that supports standard SFP+ copper transceivers and 10GBase-TX technology. However, compatibility should be verified with the specific switch manufacturer's documentation, as some vendors may require coded modules for full functionality.
