Asus 90MR00R2-M00130 ExpertCenter PN52-BB5000 x 1TD-NL Barebone Mini PC - Ryzen 5 5600H 3. 20 GHz - 64 GB DDR4 - Windows 11 Pro/Home - 2. 5GbE - Wi-Fi 6
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This ExpertCenter barebone system features a modern compute architecture centered on the AMD Ryzen 5 5600H processor with a base clock of 3.20 GHz and maximum turbo frequency of 4.10 GHz. The platform supports up to 64 GB of DDR4 memory across two SO-DIMM slots, providing ample headroom for multitasking and application workloads.
Storage flexibility comes via both Serial ATA/600 and NVMe interfaces, allowing you to configure with 2.5-inch SATA SSDs or HDDs plus M.2 NVMe SSDs for faster boot and application loading. Graphics are handled by the integrated AMD Radeon Vega graphics with shared DDR4 memory, sufficient for dual 4K display output via HDMI and USB-C with DisplayPort alternate mode.
Relevant factors for this section include Number of Processors Supported, Processor Type, Processor Model, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The PN52-BB5000X1TD-NL combines compact dimensions with robust connectivity and modern platform features that make it suitable for various business and institutional environments.
Comprehensive I/O Suite
With 7 USB ports including both USB 3.2 Gen1 and Gen2 Type-A plus two Type-C ports (one with DisplayPort output and Power Delivery input), this system connects peripherals, displays, and charging devices without requiring additional hubs.
- HDMI output on rear panel
- 2.5 Gigabit Ethernet for fast wired networking
- Dual-band Wi-Fi 6 with Bluetooth 5.2
Flexible Storage Configuration
Support for both SATA and NVMe storage devices lets you balance capacity and performance needs, whether deploying with high-speed NVMe SSDs for responsive performance or larger capacity SATA drives for data storage.
- M.2 slot for NVMe SSDs
- 2.5-inch bay for SATA drives
- Dual storage capability
Deployment / Use Cases
This barebone mini PC serves well in environments where compact form factor and reliable performance are priorities. Its small footprint and versatile mounting options make it adaptable to various deployment scenarios.
For digital signage applications, the system can be mounted behind displays or in confined spaces while delivering smooth 4K video playback. In office settings, it functions as a space-efficient workstation for general productivity, web applications, and business software. Educational institutions can deploy these systems in computer labs or libraries where desk space is limited but computing capability is needed.
Space-Constrained Workstations
Ideal for reception desks, nursing stations, retail point-of-sale counters, and other locations where traditional desktop towers consume too much valuable workspace.
Digital Signage & Kiosks
The compact chassis and capable graphics support dual 4K displays for digital menu boards, information kiosks, wayfinding systems, and interactive displays in public spaces.
Physical Profile
Measuring just 2.28 inches in height, 4.72 inches in width, and 5.12 inches in depth, this mini PC occupies minimal desk or mounting space. The Eco Black finish presents a professional appearance suitable for business environments. The compact dimensions allow for vertical or horizontal orientation and support VESA mounting options for display attachment.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 2.28" (58 mm), 4.72" (120 mm), 5.12" (130 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 4.72" (120 mm)
- Depth
- 5.12" (130 mm)
- Height
- 2.28" (58 mm)
What's in the Box
This barebone system includes the core components needed to begin your configuration.
Package contents include ExpertCenter PN52-BB5000X1TD-NL Barebone System Power Adapter, ExpertCenter PN52-BB5000X1TD-NL Barebone System. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- AMD Ryzen 5 5600H processor with 6 cores and 12 threads for responsive computing
- Supports up to 64 GB of DDR4 memory across two SO-DIMM slots
- Dual storage support with both SATA/600 and NVMe interfaces
- Comprehensive connectivity with 2.5 Gigabit Ethernet, Wi-Fi 6, and Bluetooth 5.2
- 7 USB ports including USB 3.2 Gen1, Gen2, and Type-C with DisplayPort output
- Compact mini PC form factor measuring just 2.28" H × 4.72" W × 5.12" D
- Windows 11 Pro and Windows 11 Home operating system compatibility
- Energy Star certified and RoHS compliant for environmental responsibility
Specifications
| Specifications | |
|---|---|
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | 90MR00R2M00130 |
| Brand Name | Asus |
| Product Line | ExpertCenter |
| Product Series | PN52 |
| Product Model | PN52-BB5000X1TD-NL |
| Product Name | ExpertCenter PN52-BB5000X1TD-NL Barebone System |
| Product Type | Barebone System |
| Processor | |
| Number of Processors Supported | 1 |
| Processor Type | Ryzen 5 |
| Processor Model | 5600H |
| Processor Speed | 3.20 GHz |
| Maximum Turbo Speed | 4.10 GHz |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Controllers | |
| Controller Type | Serial ATA/600,NVMe |
| Display & Graphics | |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.2 |
| Interfaces/Ports | |
| HDMI (Rear) | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 3.2 Gen 1 Ports | 4 |
| Number of USB 3.2 Gen 2 Ports | 1 |
| USB Type-C (Front) | Yes |
| USB Type-C (Rear) | Yes |
| USB Type-C Detail | 1 x USB 3.2 Gen2 TypeC (w/ DP output & PowerDelivery input), 1 x USB 3.2 Gen1 Type C |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of SATA Interfaces | 1 |
| Operating System | |
| Operating System Supported | Windows 11 Pro,Windows 11 Home |
| Power Description | |
| Maximum Power Supply Wattage | 120 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Eco Black |
| Form Factor | Mini PC |
| Height | 2.28" (58 mm) |
| Width | 4.72" (120 mm) |
| Depth | 5.12" (130 mm) |
| Miscellaneous | |
| Package Contents | ExpertCenter PN52-BB5000X1TD-NL Barebone System Power Adapter |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
User Manual
FAQ
What components do I need to add to make this barebone system operational?
To complete this barebone system, you will need to add DDR4 SO-DIMM memory modules (up to 64 GB total), a storage device (either 2.5-inch SATA SSD/HDD or M.2 NVMe SSD), and an operating system (Windows 11 Pro or Home are supported). The system includes the processor, motherboard, cooling, power supply, and connectivity interfaces pre-installed.
What display outputs does this mini PC support?
This system provides HDMI output on the rear panel and DisplayPort output via the USB 3.2 Gen2 Type-C port. The integrated AMD Radeon graphics support dual 4K display output simultaneously, making it suitable for multi-monitor setups in office environments or digital signage applications requiring high-resolution content.
Can this system be mounted behind a monitor or in tight spaces?
Yes, the compact dimensions of 2.28" H × 4.72" W × 5.12" D make this mini PC ideal for space-constrained deployments. It supports VESA mounting with compatible brackets, allowing it to be attached directly to the back of monitors or mounted on walls and under desks where traditional desktop towers would not fit.
What wireless connectivity options are included?
This system features dual-band Wi-Fi 6 (802.11ax) for fast wireless networking with improved efficiency in crowded environments, plus Bluetooth 5.2 for connecting peripherals like keyboards, mice, headsets, and speakers. The wireless capabilities provide flexibility for deployments where running Ethernet cables is impractical or undesirable.
What power supply is included with this barebone system?
The system includes a 120 W external power adapter that provides sufficient power for the Ryzen 5 5600H processor, memory, storage, and connected peripherals. The compact power brick helps maintain the system's small footprint while delivering reliable power for continuous operation in business environments.
Is this system compatible with Windows 11?
Yes, this barebone system fully supports both Windows 11 Pro and Windows 11 Home editions. The AMD Ryzen 5 5600H processor meets Windows 11 system requirements, and the platform includes TPM 2.0 support for enhanced security features. You can install either Windows 11 edition according to your licensing and feature needs.
