Aten VE8900T HDMI over IP Transmitter - Full HD 1080p - 1 Computer - Network & USB - KVM Extender
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The VE8900T operates as the transmitting component in an HDMI-over-IP system, converting HDMI and USB signals into network packets for distribution across standard Ethernet infrastructure. This technical approach enables flexible deployment scenarios where traditional point-to-point HDMI cables would be impractical or impossible due to distance constraints.
The transmitter features ATEN's EDID Expert™ technology, which automatically selects optimal Extended Display Identification Data settings to ensure smooth system startup and maintain the best possible video resolution across different display devices. This intelligent handshake management eliminates common compatibility issues that can occur in multi-display environments with varying monitor capabilities.
Relevant factors for this section include Connectivity Technology, Number of Computers Supported, Graphic Mode, Maximum Video Resolution. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This HDMI over IP transmitter provides several distinct advantages for professional AV deployments. The network-based distribution approach fundamentally changes how AV systems can be architected, moving beyond simple point-to-point connections to enable truly scalable multi-point configurations.
Advanced Video Processing
Utilizes ATEN's proprietary video lossless compression technology to maintain stunning visual quality while optimizing bandwidth usage across the network.
- Visually lossless 1080p video
- Adjustable compression rates (Smooth, Balance, High Quality)
- Up to 60 Hz refresh rate support
Network Flexibility
Leverages standard Ethernet infrastructure to eliminate distance limitations, enabling AV distribution across entire buildings or campuses using existing network cabling.
- Works with standard LAN networks
- No special cabling required
- Scalable multi-point deployment
Multi-Function Capability
Beyond basic extension, the transmitter supports various AV distribution patterns including splitting, matrix switching, video wall configurations, and daisy-chaining for complex display setups.
- Extender, splitter, and matrix functions
- Video wall support
- Daisy-chain capable
Deployment / Use Cases
The VE8900T transmitter is particularly valuable in environments where computer sources need to be located away from display destinations. Corporate boardrooms benefit from clean installation aesthetics with source equipment housed in dedicated equipment rooms while displays remain in presentation spaces. Educational institutions can centralize computer labs while distributing signals to multiple classroom displays throughout a building.
Digital signage networks represent another ideal application, where content management systems can control multiple displays from a centralized location. The network-based approach allows for easy expansion as signage networks grow, with new displays added simply by connecting to the existing network infrastructure rather than running new dedicated AV cables.
Corporate AV Systems
Deploy in conference rooms, training centers, and executive suites where source equipment consolidation improves security, maintenance access, and cable management.
Digital Signage Networks
Integrate into large-scale signage deployments across retail spaces, transportation hubs, and public venues where centralized control and network distribution are essential.
Highlights
- Extends HDMI and USB signals over standard network infrastructure
- Delivers visually lossless Full HD 1080p video at up to 60 Hz
- Supports a single computer source with comprehensive connectivity
- Features ATEN's EDID Expert™ for optimal display compatibility
- Offers adjustable video compression rates for bandwidth optimization
- Enables multi-point to multi-point AV distribution via LAN
- Functions as extender, splitter, matrix switch, and video wall controller
- Compatible with ATEN Control System for integrated management
- Provides 5V DC power input for flexible installation
- Manufactured in Taiwan with environmentally friendly design
Specifications
| Specifications | |
|---|---|
| Manufacturer | ATEN Technology, Inc |
| Manufacturer Part Number | VE8900T |
| Brand Name | ATEN |
| Product Line | VanCryst |
| Product Model | VE8900T |
| Product Name | VE8900T HDMI over IP Transmitter |
| Product Type | KVM Extender |
| Technical Information | |
| Connectivity Technology | Wired |
| Number of Computers Supported | 1 |
| Video | |
| Graphic Mode | Full HD |
| Maximum Video Resolution | 1920 x 1080 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| HDMI | Yes |
| Number of HDMI Ports | 1 |
| Number of Network (RJ-45) Ports | 1 |
| Number of USB Ports | 1 |
| Power Description | |
| Input Voltage | 5 V DC |
| Miscellaneous | |
| Platform Supported | PC |
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
User Manual
FAQ
What type of video quality does the VE8900T transmitter deliver?
The VE8900T delivers Full HD 1080p video resolution at up to 60 Hz refresh rates with visually lossless quality. It uses ATEN's advanced video compression technology to maintain excellent image integrity while optimizing network bandwidth usage. The transmitter supports different compression rate settings including Smooth, Balance, and High Quality modes, allowing users to select the optimal balance between video quality and network performance based on their specific application requirements.
How many computers can this HDMI over IP transmitter support?
This transmitter is designed to support a single computer source. It connects to one computer via HDMI and USB ports, then distributes those signals over the network to compatible receivers. For multi-computer applications, multiple transmitter units would be required, with each transmitter dedicated to a specific computer source. The single-source design ensures dedicated bandwidth and signal integrity for professional AV applications where consistent performance is critical.
What types of connections does the VE8900T transmitter provide?
The transmitter features one HDMI port for video input, one USB port for peripheral extension, and one RJ-45 network port for connection to standard Ethernet infrastructure. The HDMI port accepts video signals from the computer source, while the USB port allows keyboard, mouse, or other USB peripheral signals to be extended alongside the video. The RJ-45 port connects to the local area network, enabling distribution of both video and USB signals across the network to compatible receivers.
What distance limitations apply to this HDMI over IP solution?
Unlike traditional HDMI extenders with fixed cable length limitations, this network-based solution leverages standard Ethernet infrastructure, effectively eliminating distance constraints. The signals can travel as far as the network reaches, making it suitable for building-wide or campus-wide deployments. The actual practical distance is determined by the network infrastructure rather than the transmitter itself, allowing for flexible installation scenarios where source and display equipment may be located in different rooms, floors, or even buildings.
What power requirements does the VE8900T transmitter have?
The transmitter operates on 5V DC power input, providing flexible installation options in various environments. This low-voltage requirement makes it suitable for integration with standard power supplies and UPS systems commonly used in professional AV installations. The specific power adapter requirements would be detailed in the manufacturer's documentation, but the 5V DC specification indicates compatibility with common power solutions in corporate and institutional settings.
How is the VE8900T transmitter managed and controlled?
The transmitter offers multiple management options including compatibility with the ATEN Control System for integrated operation. Users can directly control the VE8900T via CLI Telnet or RS-232 protocol for advanced configuration and automation. Additionally, the VE Manager software provides intuitive control interfaces, allowing operators to manage transmitters, receivers, and connected displays through touch panels, keypads, or computer interfaces for comprehensive system control in professional AV environments.
