Axiom 100GBASE-CWDM4 QSFP28 Transceiver for Juniper-QSFP-100G-CWDM-C - For Data Networking, Optical Network - 1 x LC 100GBASE-CWDM4 - (QSFP-100G-CWDM-C-AX)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Application/Usage: Data Networking,Optical Network
Features: Digital Optical Monitoring (DOM)
Total Number of Ports: 1
Connector Type: LC
Interfaces/Ports Details: 1 x LC 100GBASE-CWDM4 Network
Media Type Supported: Optical Fiber
Fiber Optic Cable Wavelength: 1264.50 nm,1277.50 nm,1284.50 nm,1297.50 nm,1304.50 nm,1317.50 nm,1324.50 nm,1337.50 nm
Fiber Mode Supported: Single-mode
Ethernet Technology: 100 Gigabit Ethernet
Network Technology: 100GBase-CWDM4
Maximum Distance Supported: 2 km (1.24 Mile)
Maximum Data Transfer Rate: 100 Gbit/s
Compatibility:
MSA Compliant
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: Lifetime
- With 100GBase-CWDM4 technology, get up to 100Gbps data transfer rate using coarse wavelength-division multiplexing with 4 lanes
- 100 Gigabit Ethernet - High bandwidth performance, ease of use and reliable connectivity
- Optical fiber cable compatible - Spans afar and provides speedy data transmission rates between servers and network components
- For transmitting data at gigabit speed over hundreds of miles with little integrity loss, single-mode fiber optic is an ideal solution
[custom-specifications]
| Specifications | |
| Manufacturer | Axiom Memory Solutions |
| Manufacturer Part Number | QSFP-100G-CWDM-C-AX |
| Manufacturer Website Address | http://search.axiomupgrades.com |
| Brand Name | Axiom |
| Product Model | QSFP-100G-CWDM-C-AX |
| Product Name | 100GBASE-CWDM4 QSFP28 Transceiver for Juniper-QSFP-100G-CWDM-C |
| Product Type | QSFP28 |
| Technical Information | |
| Application/Usage | Data Networking,Optical Network |
| Features | Digital Optical Monitoring (DOM) |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC 100GBASE-CWDM4 Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Optic Cable Wavelength | 1264.50 nm,1277.50 nm,1284.50 nm,1297.50 nm,1304.50 nm,1317.50 nm,1324.50 nm,1337.50 nm |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | 100 Gigabit Ethernet |
| Network Technology | 100GBase-CWDM4 |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Maximum Data Transfer Rate | 100 Gbit/s |
| Miscellaneous | |
| Compatibility | MSA Compliant |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | Lifetime |
[/custom-specifications]
