AXIS 01633-001 T8504-R Industrial PoE Switch - 4-Port Gigabit with 2 SFP Inputs - 240W Surge Protected - Cabinet Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The T8504-R delivers 240 watts of total output power across its four Gigabit Ethernet ports, providing ample power for multiple high-demand PoE devices simultaneously. The switch features two input options: dual Gigabit Ethernet ports and two SFP slots for fiber connectivity, offering deployment flexibility in mixed-media network environments.
Built-in surge protection safeguards connected equipment from voltage spikes and electrical disturbances, while the industrial design ensures reliable operation in temperature-variable and vibration-prone installations. The compact footprint measures just 5.31" x 2.44" x 5.12" (135 x 62 x 130 mm), making efficient use of cabinet space in control rooms, industrial facilities, and surveillance installations.
Relevant factors for this section include Protection Type, Maximum Output Power. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The AXIS T8504-R combines industrial reliability with surveillance-optimized power delivery in a compact, easily deployable package. Its surge protection and robust construction make it suitable for installations where power quality cannot be guaranteed, while the flexible input options support both copper and fiber network backbones.
Surge Protection for Critical Systems
Built-in surge protection guards connected surveillance cameras and network devices against voltage spikes, reducing downtime and equipment damage in industrial and outdoor installations.
- Protects against electrical disturbances
- Reduces equipment failure risk
- Maintains system uptime
Flexible Network Connectivity
Dual Gigabit Ethernet inputs plus two SFP slots provide deployment options for copper or fiber network backbones, supporting mixed-media infrastructure without requiring separate media converters.
- Copper and fiber input options
- No separate converters needed
- Simplifies network design
Industrial-Grade Construction
Designed for challenging environments with cabinet-mountable form factor and robust components that withstand vibration, temperature variations, and continuous operation demands.
- Cabinet mountable design
- Industrial temperature tolerance
- Vibration resistant
Deployment / Use Cases
The T8504-R Industrial PoE Switch serves as a reliable power source for surveillance systems, industrial control networks, and specialized PoE applications where standard switches may not provide sufficient protection or deployment flexibility.
In surveillance installations, the switch powers multiple Axis cameras, door stations, and illuminators while protecting them from electrical disturbances. The surge protection is particularly valuable for outdoor cameras and perimeter security systems exposed to lightning-induced surges and power fluctuations.
Surveillance System Power Hub
Power multiple Axis fixed cameras, PTZ cameras, door controllers, and illuminators from a single compact switch with built-in surge protection for entire camera clusters.
- Supports Axis camera ecosystems
- Powers camera clusters
- Protects entire surveillance segments
Industrial Network Power Distribution
Deploy in manufacturing facilities, transportation hubs, and utility sites to power network devices in environments with challenging power conditions and space constraints.
- Industrial environment suitable
- Space-efficient cabinet mounting
- Reliable in variable conditions
Physical Profile
The T8504-R features a compact black enclosure measuring 5.31" high, 2.44" wide, and 5.12" deep (135 x 62 x 130 mm), with a weight of just 1.32 pounds (600 grams). The cabinet-mountable design includes appropriate mounting hardware for secure installation in control room racks, industrial cabinets, or surveillance equipment enclosures. The black finish provides a professional appearance that blends with network infrastructure while the small footprint maximizes space utilization in crowded equipment areas.
- Width
- 2.44" (62 mm)
- Depth
- 5.12" (130 mm)
- Height
- 5.31" (135 mm)
- Weight
- 1.32 lb (600 g)
Highlights
- 240W total PoE output power for multiple devices
- 4 Gigabit Ethernet output ports with PoE
- 2 Gigabit Ethernet + 2 SFP input options
- Built-in surge protection for equipment safety
- Cabinet-mountable industrial design
- Compact 5.31" x 2.44" x 5.12" footprint
- TAA compliant for government deployments
- Compatible with extensive Axis device ecosystem
- Black finish for professional appearance
- 1.32 lb lightweight construction
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 01633-001 |
| Brand Name | AXIS |
| Product Model | T8504-R |
| Product Name | T8504-R Industrial PoE Switch |
| Product Type | PoE Injector |
| Technical Information | |
| Protection Type | Surge Protection |
| Power Description | |
| Maximum Output Power | 240 W |
| Interfaces/Ports | |
| Input Ports | 2 x 10/100/1000Base-T,2 x SFP |
| Output Ports | 4 x 10/100/1000Base-T |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Cabinet Mountable |
| Height | 5.31" (135 mm) |
| Width | 2.44" (62 mm) |
| Depth | 5.12" (130 mm) |
| Weight (Approximate) | 1.32 lb (600 g) |
| Miscellaneous | |
| TAA Compliant | Yes |
FAQ
What is the total power output of the AXIS T8504-R PoE Switch?
The AXIS T8504-R Industrial PoE Switch delivers 240 watts of total output power across its four Gigabit Ethernet ports. This substantial power budget supports multiple Power-over-Ethernet devices simultaneously, including high-power surveillance cameras, illuminators, and network devices that require PoE+ or higher power levels for optimal operation.
How many devices can this PoE switch power simultaneously?
The T8504-R provides four Gigabit Ethernet output ports, each capable of delivering PoE power to connected devices. The switch can power up to four PoE devices simultaneously, with the total combined power draw not exceeding the 240-watt maximum output. This configuration is ideal for powering camera clusters, door controller systems, or small groups of network devices in surveillance and industrial applications.
What types of input connections does this switch support?
The AXIS T8504-R offers flexible input connectivity with two 10/100/1000Base-T Gigabit Ethernet ports and two SFP (Small Form-factor Pluggable) slots. This dual-input approach allows deployment with standard copper Ethernet connections or fiber optic links, providing options for different network backbone infrastructures without requiring separate media conversion equipment.
Does this PoE switch include surge protection?
Yes, the T8504-R Industrial PoE Switch features built-in surge protection that safeguards connected equipment from voltage spikes and electrical disturbances. This protection is particularly valuable in industrial environments, outdoor installations, and locations with unstable power quality where surges could damage sensitive surveillance cameras and network devices.
How is this switch mounted in an installation?
The AXIS T8504-R is designed for cabinet mounting with appropriate hardware included for secure installation. The compact form factor measures 5.31" x 2.44" x 5.12" (135 x 62 x 130 mm), allowing efficient use of space in control room racks, industrial cabinets, surveillance equipment enclosures, or other structured mounting environments.
What devices are compatible with this PoE switch?
The T8504-R is compatible with a wide range of Axis surveillance and network devices, including fixed cameras, PTZ cameras, door controllers, door stations, illuminators, I/O relay modules, and positioning units. The switch is specifically tested and validated to work with Axis ecosystem products, ensuring reliable power delivery and network connectivity for surveillance and security installations.
