AXIS 02676-001 M4215-V 2MP Indoor Full HD Network Camera - Color Dome - White - Zipstream - H. 265 - 60 fps - Varifocal Lens - PoE
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At its core, the M4215-V features a 1/2.8" RGB CMOS sensor that ensures accurate color reproduction and effective performance in various lighting conditions. The camera supports advanced video compression formats including H.265, H.264H, H.264M, and Axis Zipstream technology, which intelligently reduces bandwidth and storage requirements while maintaining video quality.
Network connectivity is handled through Fast Ethernet with Power over Ethernet (PoE) support, simplifying installation by delivering both data and power over a single cable. The camera is compatible with a wide range of industry-standard protocols including ONVIF, RTSP, and SNMP, ensuring seamless integration into existing surveillance systems.
Relevant factors for this section include HD Recording, Recording Formats, Wide Dynamic Range (WDR), Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The M4215-V combines imaging performance with practical deployment features that matter in real-world surveillance scenarios. Its 60 fps capability provides smoother video playback than standard 30 fps cameras, reducing motion blur and improving identification of fast-moving subjects.
Advanced Imaging Features
Includes Wide Dynamic Range (WDR), Digital WDR, day/night functionality, back light compensation, and 2D digital noise reduction to maintain image quality in challenging lighting conditions.
- Wide Dynamic Range
- Day/Night Operation
- Noise Reduction
Durable Construction
The vandal-resistant dome housing meets IK08 impact protection standards and IP42 ingress protection, offering reliable operation in environments where accidental contact or dust exposure may occur.
- IK08 Rated
- Vandal Resistant
- Dust Resistant
Flexible Storage Options
Supports local recording via memory card in addition to network storage solutions, providing redundancy and quick access to recent footage without relying solely on network infrastructure.
- Memory Card Support
- Network Storage
- Local Backup
Deployment / Use Cases
This camera is specifically designed for indoor surveillance applications where clear video identification and reliable operation are paramount. Its white dome form factor blends discreetly into commercial ceilings while providing 360° mounting flexibility.
The M4215-V excels in retail environments, office buildings, educational facilities, and healthcare settings where monitoring of entrances, corridors, and common areas is required. The varifocal lens allows installers to adjust the field of view during installation, making it suitable for both wide-area coverage and focused monitoring of specific points of interest.
Retail Security
Monitor point-of-sale areas, entrances, and inventory storage with clear 1080p video that supports identification of individuals and activities.
- POS Monitoring
- Entrance Surveillance
- Inventory Protection
Corporate Office Monitoring
Secure lobbies, hallways, and sensitive areas with a camera that delivers professional-grade video quality while maintaining a discreet appearance.
- Lobby Security
- Access Control
- Asset Protection
Physical Profile
The camera measures 2.80" (71 mm) in height with a 4.72" (120 mm) diameter dome housing, presenting a compact footprint suitable for ceiling mounting in various indoor environments. Its white finish coordinates with standard commercial interiors while the dome design provides tamper resistance and environmental protection.
- Height
- 2.80" (71 mm)
- Weight
- 12.28 oz (348 g)
- Length
- 3.5 mm (0.14")
Highlights
- 2-megapixel resolution delivers Full HD 1080p video at 60 fps
- Varifocal lens (3.5 mm to 6.6 mm) with 1.9x optical zoom
- Axis Zipstream technology reduces bandwidth and storage needs
- Power over Ethernet (PoE) simplifies installation
- Vandal-resistant dome housing with IK08 impact rating
- Wide Dynamic Range maintains image quality in high-contrast scenes
- Supports H.265, H.264, and Motion JPEG video formats
- Memory card support for local storage options
- Compatible with ONVIF and industry-standard protocols
- Indoor-rated with IP42 protection against dust ingress
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 02676-001 |
| Brand Name | AXIS |
| Product Series | M42 |
| Product Model | M4215-V |
| Product Name | M4215-V Dome Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | Full HD |
| Wide Dynamic Range (WDR) | Yes |
| Display & Graphics | |
| Image Sensor Type | RGB CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color |
| Field of View | Horizontal field of view: 93°-47° Vertical field of view: 50°-26° |
| Effective Camera Resolution | 2 Megapixel |
| Video | |
| Video Formats | Zipstream,H.264H,H.264M,H.265,Motion JPEG,H.264M (MPEG-4 Part 10/AVC),H.264H (MPEG-4 Part 10/AVC),H.265 (MPEG-H Part 2/HEVC) |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 60 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 3.5 mm (0.14") |
| Maximum Focal Length | 6.6 mm (0.26") |
| Lens Included | Yes |
| Minimum Aperture | f/2.6 |
| Maximum Aperture | f/1.7 |
| Optical Zoom | 1.9x |
| Exposure | |
| Shortest Shutter Speed | 1/25000 Second |
| Longest Shutter Speed | 1/5 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | IPv4,IPv6 USGv6,ICMPv4/ICMPv6,HTTP,HTTPS,TLS,QoS,DiffServ (QoS),FTP,SFTP,CIFS/SMB,SMTP,mDNS (Bonjour),UPnP,SNMPv1/v2c/v3 (MIB2),DNS/DNSv6,DDNS,NTP,NTS,RTSP,RTP,SRTP/RTSPS,TCP,UDP,IGMPv1/v2/v3,RTCP,ICMP,DHCP,ARP,SSH,LLDP,CDP,MQTT v3.1.1,ZeroConf,ONVIF |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| HDMI | Yes |
| Network (RJ-45) | Yes |
| Power Description | |
| Power Source Type | PoE |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Form Factor | Dome |
| Durability | Vandal Resistant,Impact Resistant,Dust Resistant |
| Height | 2.80" (71 mm) |
| Diameter | 4.72" (120 mm) |
| Weight (Approximate) | 12.28 oz (348 g) |
| Environmental Conditions | |
| Maximum Operating Temperature | 113°F (45°C) |
| Miscellaneous | |
| Features | Day/Night,Digital Wide Dynamic Range (D-WDR),Wide Dynamic Range,White Balance,Auto Gain Control,Back Light Compensation (BLC),Highlight Compensation (HLC),Noise Reduction,2D Digital Noise Reduction (2DNR),Automatic White Balance,Cross Line Detection |
| Indoor/Outdoor | Indoor |
| Impact Protection Rating | IK08 |
| Ingress Protection Rating | IP42 |
FAQ
What video resolution does the AXIS M4215-V camera support?
The AXIS M4215-V captures 2-megapixel video at Full HD 1080p resolution (1920 x 1080 pixels). This resolution provides clear, detailed imagery suitable for identifying individuals and activities in surveillance footage. The camera maintains this resolution at up to 60 frames per second for smooth motion representation.
Does this camera support Power over Ethernet (PoE)?
Yes, the M4215-V network camera supports Power over Ethernet, allowing both data transmission and power delivery through a single Ethernet cable. This simplifies installation by eliminating the need for separate power wiring near the camera location, reducing installation time and costs in surveillance deployments.
What type of lens does the M4215-V camera have?
This camera features a varifocal lens with a focal length range from 3.5 mm to 6.6 mm, providing 1.9x optical zoom capability. The varifocal design allows installers to adjust the field of view during installation without changing lenses, offering flexibility to cover wide areas (93° horizontal at 3.5 mm) or focus on specific points (47° horizontal at 6.6 mm).
Is the AXIS M4215-V suitable for outdoor use?
No, this camera is designed specifically for indoor applications. It carries an IP42 ingress protection rating, which provides limited protection against dust but is not rated for outdoor weather conditions. For outdoor surveillance, consider AXIS cameras with higher IP ratings specifically designed for exterior environments.
What video compression formats does this camera support?
The M4215-V supports multiple video compression formats including H.265 (HEVC), H.264H, H.264M, Motion JPEG, and Axis Zipstream technology. H.265 provides efficient compression for reduced bandwidth usage, while Zipstream intelligently optimizes video quality based on scene content to further decrease storage requirements without sacrificing important details.
What durability features does the dome housing provide?
The white dome housing offers IK08 impact protection, meaning it can withstand impacts of up to 5 joules, making it vandal-resistant for public or high-traffic areas. Additionally, the housing provides IP42 protection against dust ingress and is constructed to resist accidental impacts, ensuring reliable operation in commercial environments where physical contact may occur.
