AXIS 02914-001 P5654-E Mk II PTZ Network Camera - Full HD 1080p - 21x Optical Zoom - IP66/IK10 - PoE+ - White
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This PTZ camera captures video at up to 1920 x 1080 resolution and 60 frames per second, ensuring smooth, real-time surveillance footage. The varifocal lens offers a focal length range from 4 mm to 84.6 mm, with a horizontal field of view adjustable between 77.0° and 3.6°. This flexibility allows operators to zoom in on distant details or monitor broad areas without sacrificing image clarity.
Network connectivity is handled via Fast Ethernet, with support for a comprehensive suite of protocols including IPv4, IPv6, HTTP/HTTPS, RTSP, and SNMP for seamless integration into existing security systems. The camera includes a removable IR cut-off filter for effective day/night operation, and features like electronic image stabilization and defog enhance video quality in challenging conditions.
Relevant factors for this section include HD Recording, Recording Formats, Camera Iris, Image Sensor Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The AXIS P5654-E Mk II stands out with its combination of high-performance imaging, rugged construction, and intelligent detection capabilities. Its 21x optical zoom provides exceptional detail capture at long distances, while the IP66/IK10 ratings guarantee durability in harsh environments. Advanced video analytics, including human, vehicle, and fence detection, reduce false alarms and enhance security monitoring efficiency.
Advanced Detection Features
Incorporates motion detection, shock detection, human detection, vehicle detection, cross line detection, and fence detector algorithms to identify and alert on specific events, improving situational awareness.
- Human Detection
- Vehicle Detection
- Cross Line Detection
- Fence Detector
Environmental Resilience
Rated IP66 for complete protection against dust and powerful water jets, and IK10 for impact resistance, ensuring reliable operation in outdoor and industrial settings.
- Weather Resistant
- Impact Resistant
- Wide Temperature Range
Efficient Video Management
Supports H.264, H.265, and Motion JPEG formats with Zipstream technology to reduce bandwidth and storage requirements while maintaining high video quality.
- H.265/HEVC Support
- Zipstream
- Multiple Format Compatibility
Deployment / Use Cases
This camera is ideal for perimeter security, parking lots, transportation hubs, and industrial facilities where detailed, long-range monitoring is essential. Its PTZ capabilities and wide tilt range (0° to 350°) allow for comprehensive coverage of large areas, while the ceiling mount design facilitates discreet installation in both indoor and outdoor environments.
The PoE+ support enables deployment over single-cable Ethernet runs, reducing installation complexity and cost in networked surveillance systems. Integration with VMS platforms is straightforward thanks to broad protocol support, making it suitable for upgrading existing security infrastructure or deploying in new, scalable installations.
Perimeter and Area Surveillance
Use for monitoring fences, gates, and open spaces where the 21x zoom and advanced detection features provide detailed oversight and reduce blind spots.
Critical Infrastructure Protection
Deploy in utilities, warehouses, and transportation terminals where IP66/IK10 durability ensures continuous operation in demanding conditions.
Physical Profile
The camera features a white, smoked dome design that blends discreetly into various environments. It includes a hard ceiling mount, spring pipe adaptor, and U-profile pipe adaptor for flexible installation options. With an approximate weight of 5.51 lb (2500 g), it is robust yet manageable for standard mounting procedures.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 5.51 lb (2500 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Weight
- 5.51 lb (2500 g)
- Length
- 4 mm (0.16")
What's in the Box
The package includes all necessary components for installation and operation, ensuring a complete out-of-the-box experience.
Highlights
- Full HD 1080p resolution at 60 fps for crisp, real-time video
- 21x optical zoom with varifocal lens for detailed long-range monitoring
- IP66 and IK10 ratings for weather and impact resistance
- PoE+ and AC power options for flexible installation
- Advanced detection features including human, vehicle, and fence detection
- H.265, H.264, and Motion JPEG video compression with Zipstream
- Wide operating temperature range from -22°F to 122°F (-30°C to 50°C)
- TAA compliant for use in U.S. federal government projects
- 5-year limited warranty for long-term reliability
- Includes ceiling mount and adaptors for easy installation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Axis Communications |
| Manufacturer Part Number | 02914-001 |
| Brand Name | AXIS |
| Product Model | P5654-E Mk II |
| Product Name | P5654-E Mk II PTZ Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | Full HD |
| Camera Iris | Auto |
| Display & Graphics | |
| Image Sensor Type | RGB CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color |
| Tilt | 0° to 350° |
| Field of View | Horizontal field of view: 77.0° - 3.6° / Vertical field of view: 43.1° - 2.0° |
| Video | |
| Video Formats | H.264 (MPEG-4 Part 10/AVC),H.265 (MPEG-H Part 2/HEVC),Motion JPEG,H.264,H.265,Zipstream,H.264B,H.264H,H.264M |
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 60 fps |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 4 mm (0.16") |
| Maximum Focal Length | 84.6 mm (3.33") |
| Lens Included | Yes |
| Optical Zoom | 21x |
| Exposure | |
| Shortest Shutter Speed | 1/66500 Second |
| Longest Shutter Speed | 2 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | IPv4,IPv6 USGv6,ICMPv4/ICMPv6,HTTP,HTTPS,TLS,DiffServ (QoS),FTP,SFTP,CIFS/SMB,SMTP,mDNS (Bonjour),UPnP,SNMP (v1/v2c/v3),SNMP (MIB-2),DNS/DNSv6,DDNS,NTP,NTS,RTSP,RTP,SRTP/RTSPS,TCP,UDP,IGMPv1/v2/v3,RTCP,ICMP,DHCPv4/v6,ARP,SSH,NTCIP,LLDP,CDP,MQTT v3.1.1,RFC 3164/5424,UDP/TCP/TLS,ZeroConf,IEEE 802.1X,IEEE 802.1AR |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Maximum Power Consumption | 37 W |
| Input Voltage | 100 V AC,240 V AC |
| Power Source Type | PoE+,AC |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Mount Type | Ceiling Mount |
| Durability | Weather Resistant,Impact Resistant |
| Weight (Approximate) | 5.51 lb (2500 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 100% |
| Miscellaneous | |
| Features | Day/Night,Removable IR Cut-off Filter,Motion Detection,Electronic Image Stabilization,Defog,Shock Detection,Human Detection,Vehicle Detection,Cross Line Detection,Fence Detector,Password Protection |
| Package Contents | P5654-E Mk II PTZ Network Camera RJ45 Push-Pull Connector (IP66) Hard Ceiling Mount Spring Pipe Adaptor U-Profile Pipe Adaptor Installation Guide Windows® Decoder 1-User License Smoked Dome |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the maximum video resolution of the AXIS P5654-E Mk II camera?
The camera supports a maximum video resolution of 1920 x 1080 pixels, which is Full HD (1080p). This resolution provides clear, detailed imagery suitable for identifying faces, license plates, and other critical details in surveillance footage, ensuring effective monitoring in both commercial and industrial settings.
Does this camera support Power over Ethernet (PoE)?
Yes, the AXIS P5654-E Mk II supports PoE+ (IEEE 802.3at), which delivers both power and data over a single Ethernet cable. This simplifies installation by reducing wiring needs and allows for flexible placement in locations where AC power outlets may not be readily available, supporting deployments up to 100 meters from the switch.
What are the durability ratings of this network camera?
This camera is rated IP66 for ingress protection, meaning it is dust-tight and protected against powerful water jets, making it suitable for outdoor use. It also has an IK10 impact protection rating, which ensures resistance to physical impacts up to 20 joules, providing reliability in high-traffic or vandal-prone areas.
What type of lens and zoom capabilities does it have?
The camera features a varifocal lens with a 21x optical zoom, offering a focal length range from 4 mm to 84.6 mm. This allows for adjustable field of view from wide-angle (77.0° horizontal) to telephoto (3.6° horizontal), enabling detailed zooming on distant objects without loss of image quality, ideal for monitoring large perimeters or specific points of interest.
What advanced detection features are included?
The AXIS P5654-E Mk II includes multiple intelligent detection features such as human detection, vehicle detection, cross line detection, and fence detector. These analytics help reduce false alarms by focusing on relevant events, enhance security monitoring by providing targeted alerts, and improve overall system efficiency in identifying potential threats or incidents.
Is this camera compliant with TAA requirements?
Yes, this camera is TAA (Trade Agreements Act) compliant, meaning it meets the sourcing and manufacturing standards required for use in U.S. federal government projects. This compliance ensures it can be deployed in government facilities and other regulated environments where such certifications are mandatory for procurement and installation.
