Black Box LBH100A-PD-SC-24 Fast Ethernet Media Converter - Dual RJ-45 & SC Fiber Port - Multi-mode 2 km - DIN Rail Mount - 24V DC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This media converter features two 10/100 Mbps RJ-45 ports for copper connections and one SC multi-mode fiber port operating at 850 nm wavelength, supporting distances up to 2 km. It uses Fast Ethernet technology to maintain consistent 100 Mbps throughput across both media types, ensuring no bottleneck in data transmission.
The 24V DC power input provides flexible power options, compatible with standard industrial power supplies. Its small form factor—measuring 3.5" H x 3" W x 1" D and weighing only 4.8 oz—allows for dense installations without sacrificing performance.
This section brings together practical product details such as Total Number of Ports, Network (RJ-45), Number of Network (RJ-45) Ports, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This converter excels in environments where network reliability is critical, offering robust construction and compliance with industrial standards. Its ability to extend Ethernet over fiber up to 2 km eliminates distance limitations of copper cabling, while the dual RJ-45 ports provide switching functionality for local devices.
Industrial Durability
Built to withstand extreme temperatures and harsh conditions, ensuring continuous operation in manufacturing plants, outdoor installations, or utility settings.
- -40 to +75°C operating range
- Dust and dirt resistant design
Easy Integration
The DIN rail mount kit simplifies installation in standard industrial racks, saving space and reducing setup time compared to bulky alternatives.
- Includes mounting hardware
- Compact 3.5" x 3" x 1" footprint
Deployment / Use Cases
Ideal for extending network segments between buildings or across large facilities where fiber optic cabling is already deployed or required for distance. It converts fiber backbone connections to copper for end devices like IP cameras, access points, or PLCs.
Common applications include industrial automation networks, security systems with remote cameras, campus Wi-Fi deployments, and utility SCADA systems. The converter also serves in data center edge deployments where fiber links connect to copper-based equipment racks.
Industrial Automation
Connect PLCs, sensors, and HMIs across factory floors using fiber for noise immunity and long-distance runs, with local copper drops for devices.
Security & Surveillance
Extend network reach to remote IP cameras over fiber, then use RJ-45 ports for local switches or NVR connections in control rooms.
Physical Profile
The converter's compact dimensions and lightweight design make it easy to install in space-constrained environments. The DIN rail mountable form factor ensures secure attachment in industrial cabinets, while the small footprint allows for high-density deployments. The unit's construction supports reliable operation without requiring additional cooling or special mounting considerations.
- Width
- 3" (76.20 mm)
- Depth
- 1" (25.40 mm)
- Height
- 3.50" (88.90 mm)
- Weight
- 4.80 oz (136.08 g)
- Length
- 850 nm
What's in the Box
The package includes everything needed for immediate deployment, ensuring a complete solution right out of the box.
Highlights
- Converts between multi-mode fiber and copper Ethernet networks.
- Supports Fast Ethernet speeds up to 100 Mbps on all ports.
- Extends network distance up to 2 km over fiber.
- Dual RJ-45 ports provide local switching capability.
- 24V DC power input for flexible industrial power options.
- DIN rail mountable for secure installation in racks or panels.
- Operates in extreme temperatures from -40 to +75°C.
- Compliant with RoHS, WEEE, and TAA regulations.
- Includes all necessary mounting hardware.
- Backed by a 3-year limited warranty.
Specifications
| Specifications | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | LBH100A-PD-SC-24 |
| Brand Name | Black Box |
| Product Series | LBH100 |
| Product Name | LBH100 Transceiver/Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of SC Ports | 1 |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 850 nm |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 10/100Base-T |
| Power Description | |
| Power Source | DC |
| Physical Characteristics | |
| Form Factor | DIN Rail Mountable |
| Height | 3.50" (88.90 mm) |
| Width | 3" (76.20 mm) |
| Depth | 1" (25.40 mm) |
| Weight (Approximate) | 4.80 oz (136.08 g) |
| Miscellaneous | |
| Package Contents | LBH100 Transceiver/Media Converter DIN Rail Mount Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | United States |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What types of network connections does this media converter support?
This converter supports both optical fiber and twisted-pair copper connections. It has one SC multi-mode fiber port for fiber optic cabling and two RJ-45 ports for standard Ethernet copper cables, allowing seamless conversion between the two media types.
What is the maximum distance supported over fiber?
The converter supports fiber optic connections up to 2 kilometers (1.24 miles) when using multi-mode fiber at 850 nm wavelength. This extended range is ideal for connecting network segments across large facilities or between buildings.
How is this converter powered?
It uses a 24V DC power input, which is common in industrial and commercial settings. This power method provides compatibility with standard industrial power supplies and ensures reliable operation in environments where AC power may not be readily available.
Can this converter be mounted in a standard rack?
Yes, it includes a DIN rail mount kit for easy installation in industrial racks, control panels, or server enclosures. The compact design allows for high-density deployments, and the mounting hardware ensures secure attachment in vibration-prone environments.
What environmental conditions can this converter withstand?
It operates reliably in temperatures from -40 to +75°C (-40 to +167°F), making it suitable for harsh industrial, outdoor, or unconditioned spaces. This wide temperature range ensures performance in dusty, dirty, or variable climate conditions.
What certifications and compliance does this product have?
The converter is compliant with Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE), and Trade Agreements Act (TAA) regulations. It is also manufactured in the United States and comes with a 3-year limited warranty.
