Cisco AIR-ANT2524V4CR-RF Aironet Four-Element MIMO Dual-Band Ceiling Mount Omnidirectional Antenna - 4 dBi - SHF/UHF - RP-TNC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This antenna operates across two key frequency ranges: 2400 MHz to 2484 MHz and 5150 MHz to 5850 MHz, covering standard Wi-Fi bands for flexible network planning. The SHF and UHF band support enables compatibility with various wireless standards and access points.
The four-element MIMO configuration enhances signal reliability and throughput, while the 4 dBi isotropic gain provides balanced coverage without excessive directionality. The RP-TNC connector ensures secure and stable connections to compatible Cisco Aironet and other wireless devices.
Relevant factors for this section include Directivity, Frequency Band Type, Operating Frequency Range, Connector Type. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The Cisco AIR-ANT2524V4CR-RF antenna combines advanced radio design with practical installation features to deliver reliable wireless performance. Its omni-directional pattern simplifies deployment by providing uniform coverage, reducing the need for precise alignment.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Enhanced Connectivity, Streamlined Installation.
Enhanced Connectivity
The four-element MIMO design improves signal quality and network capacity, supporting higher data rates and reduced interference in dense wireless environments.
- Better throughput for data-intensive applications
- Improved reliability in multi-user scenarios
Streamlined Installation
Ceiling mounting offers optimal placement for coverage while maintaining a discreet appearance. The lightweight design and standard connector simplify setup and integration.
- Minimal visibility in office ceilings
- Easy integration with existing infrastructure
Deployment / Use Cases
This antenna is ideal for extending or enhancing wireless networks in environments where ceiling mounting is preferred. Its dual-band support makes it versatile for both 2.4 GHz and 5 GHz Wi-Fi deployments, accommodating a range of access points and client devices.
Common use cases include office buildings, retail spaces, educational institutions, and healthcare facilities where reliable wireless coverage is critical. The antenna's design supports seamless roaming and consistent signal strength across covered areas.
Enterprise Wi-Fi Expansion
Deploy as part of a Cisco Aironet or compatible wireless network to fill coverage gaps or enhance existing infrastructure. Suitable for high-density areas like conference rooms or open-plan offices.
Commercial Installations
Use in retail stores, hotels, or public venues to provide guest and operational Wi-Fi. The ceiling mount keeps equipment out of sight while maintaining performance.
Physical Profile
The antenna features a compact, low-profile design with dimensions of 7.25" in width and depth and just 1" in height. This slim form factor allows for discreet ceiling installation without protruding significantly into the room. The lightweight construction at 1.30 lb simplifies handling and mounting, while the durable build ensures long-term reliability in various environmental conditions.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1" (25.40 mm), 7.25" (184.15 mm), 7.25" (184.15 mm), 1.30 lb (589.67 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 7.25" (184.15 mm)
- Depth
- 7.25" (184.15 mm)
- Height
- 1" (25.40 mm)
- Weight
- 1.30 lb (589.67 g)
Highlights
- Four-element MIMO design for improved signal reliability and throughput
- Dual-band operation across 2400-2484 MHz and 5150-5850 MHz frequencies
- Omni-directional pattern provides uniform 360-degree coverage
- Ceiling mount form factor for discreet, optimal placement
- 4 dBi isotropic gain balances coverage and performance
- RP-TNC connector ensures secure compatibility with Cisco and other devices
- Compact dimensions: 7.25" x 7.25" x 1" (184.15 mm x 184.15 mm x 25.40 mm)
- Lightweight at 1.30 lb (589.67 g) for easy installation
- Supports SHF and UHF band types for flexible network design
- Ideal for wireless data networks in enterprise and commercial settings
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | AIR-ANT2524V4CR-RF |
| Brand Name | Cisco |
| Product Line | Aironet |
| Product Name | Aironet Four-Element, MIMO, Dual-Band Ceiling Mount Omnidirectional Antenna |
| Product Condition | Refurbished |
| Product Type | Antenna |
| Technical Information | |
| Directivity | Omni-directional |
| Frequency Band Type | SHF,UHF |
| Operating Frequency Range | 2400 MHz to 2484 MHz,5150 MHz to 5850 MHz |
| Antenna Gain (Isotropic) | 4 dBi |
| Interfaces/Ports | |
| Connector Type | RP-TNC |
| Physical Characteristics | |
| Height | 1" (25.40 mm) |
| Width | 7.25" (184.15 mm) |
| Depth | 7.25" (184.15 mm) |
| Form Factor | Ceiling Mount |
| Weight (Approximate) | 1.30 lb (589.67 g) |
| Miscellaneous | |
| Application/Usage | Wireless Data Network |
FAQ
What frequency bands does this Cisco antenna support?
The Cisco AIR-ANT2524V4CR-RF antenna supports dual-band operation across two frequency ranges: 2400 MHz to 2484 MHz (commonly used for 2.4 GHz Wi-Fi) and 5150 MHz to 5850 MHz (covering 5 GHz Wi-Fi bands). This dual-band capability allows it to work with a wide range of wireless access points and standards, providing flexibility for network deployments that require both bands for optimal performance and device compatibility.
What is the antenna gain and how does it affect coverage?
This antenna has an isotropic gain of 4 dBi. Gain measures how effectively the antenna focuses signal strength in its radiation pattern. A 4 dBi gain provides a balanced approach for omni-directional antennas, offering moderate signal enhancement without overly directional beams. This results in reliable coverage across a 360-degree area, suitable for general-purpose wireless deployments where uniform signal distribution is more important than long-range, focused transmission.
What type of connector does this antenna use?
The antenna uses an RP-TNC (Reverse Polarity Threaded Neill-Concelman) connector. This is a common connector type in Cisco and many other enterprise wireless systems. The RP-TNC design provides a secure, threaded connection that resists accidental disconnection and ensures stable signal transmission. It is compatible with access points and devices that feature RP-TNC antenna ports, making integration straightforward for network administrators.
Is this antenna designed for ceiling mounting?
Yes, this antenna has a ceiling mount form factor. It is specifically designed to be installed on ceilings, which is often the optimal location for wireless access points and antennas in indoor environments. Ceiling mounting helps provide broad, downward-facing coverage for rooms below while keeping the equipment discreet and out of the way. The compact and low-profile design minimizes visual impact, making it suitable for offices, schools, and commercial spaces.
What does 'four-element MIMO' mean for this antenna?
Four-element MIMO (Multiple Input, Multiple Output) refers to the antenna's internal design, which includes four separate radiating elements. In wireless technology, MIMO uses multiple antennas to improve communication performance by transmitting and receiving multiple data streams simultaneously. This design increases data throughput, enhances signal reliability, and reduces interference, especially in environments with many connected devices. It helps support higher Wi-Fi standards and better overall network capacity.
What are the dimensions and weight of this antenna?
The antenna measures 7.25 inches in width, 7.25 inches in depth, and 1 inch in height (184.15 mm x 184.15 mm x 25.40 mm). It weighs approximately 1.30 pounds (589.67 grams). These compact and lightweight dimensions make it easy to handle and install, particularly in ceiling applications where space and weight considerations are important. The slim profile allows it to fit neatly into ceiling tiles or mounts without being obtrusive.
