Cisco CBS220-8FP-E-2G-NA Business 8-Port Gigabit PoE+ Managed Switch with 2 SFP Uplinks - 130W PoE Budget - Layer 2 - Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Layer 2 managed switch operates at Gigabit Ethernet speeds across all ports, supporting both 10/100/1000Base-T copper and 1000Base-X fiber connections through its SFP slots. The switch implements a comprehensive set of networking standards including IEEE 802.3af and 802.3at for PoE/PoE+, 802.1Q for VLAN segmentation, 802.1x for network access control, and 802.3ad for link aggregation.
With a power consumption of just 9.10W under typical operation, the switch maintains energy efficiency while delivering full PoE capabilities. The rack-mountable 1U form factor fits standard 19-inch racks, and the compact dimensions make it suitable for space-constrained installations.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Uplink Port, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The CBS220-8FP-E-2G combines essential managed switching features with robust PoE capabilities in a compact form factor. The 130W PoE budget provides ample power for multiple connected devices, while the two SFP uplink slots offer future-proof connectivity options for network expansion.
Comprehensive PoE Support
All eight Gigabit Ethernet ports deliver PoE/PoE+ power, supporting both IEEE 802.3af (15.4W per port) and 802.3at (30W per port) standards for maximum device compatibility.
- 130W total PoE budget
- Supports PoE and PoE+ devices
- Auto-sensing power delivery
Managed Switching Capabilities
As a fully manageable Layer 2 switch, it provides advanced features including VLANs, QoS, port mirroring, IGMP snooping, and spanning tree protocols for network optimization and security.
- VLAN segmentation
- Quality of Service (QoS)
- Port security features
Flexible Uplink Options
The two SFP slots support both copper and fiber transceivers, allowing for long-distance connections or compatibility with existing fiber infrastructure.
- 1000Base-X compatibility
- Hot-swappable SFP modules
- Mixed media support
Deployment / Use Cases
This switch is particularly well-suited for small business environments where space, power, and budget constraints exist alongside growing network demands. Its combination of PoE capabilities, managed features, and compact design makes it versatile for various deployment scenarios.
Common applications include powering and connecting VoIP phone systems in office environments, supporting multiple wireless access points for comprehensive Wi-Fi coverage, and connecting IP surveillance cameras in security installations. The SFP uplinks enable connections to core switches or routers over longer distances where copper limitations would otherwise require additional equipment.
Small Office Networking
Ideal for offices with 8 or fewer wired devices needing both data and power, such as IP phones, computers, and access points, with room for expansion via uplinks.
Retail & Hospitality
Perfect for point-of-sale systems, digital signage, guest Wi-Fi access points, and security cameras in space-constrained retail or hospitality environments.
Physical Profile
The switch features a compact, rack-mountable design measuring 1.73 inches in height (1U), 10.98 inches in width, and 6.69 inches in depth. This form factor fits standard 19-inch equipment racks while occupying minimal vertical space. The included mounting kit facilitates easy installation in rack, wall, or desktop configurations depending on deployment needs.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.73" (44 mm), 10.98" (279 mm), 6.69" (170 mm), 2.60 lb (1180 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 10.98" (279 mm)
- Depth
- 6.69" (170 mm)
- Height
- 1.73" (44 mm)
- Weight
- 2.60 lb (1180 g)
What's in the Box
The package includes all necessary components for immediate deployment and operation.
Highlights
- 8 Gigabit Ethernet ports with PoE/PoE+ support on all ports
- 130W total PoE budget for powering multiple connected devices
- 2 SFP uplink slots for fiber or copper expansion
- Layer 2 managed switching with VLAN, QoS, and security features
- Rack-mountable 1U form factor for space-efficient deployment
- Supports comprehensive IEEE networking standards including 802.3af/at
- Energy-efficient operation with 9.10W typical power consumption
- Includes mounting kit for flexible installation options
- 3-year limited warranty for peace of mind
- Environmentally compliant with WEEE directives
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | CBS220-8FP-E-2G-NA |
| Brand Name | Cisco |
| Product Line | Business |
| Product Series | 220 |
| Product Model | CBS220-8FP-E-2G |
| Product Name | Business CBS220-8FP-E-2G Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE,2 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Optical Fiber,Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 2.0 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3z,IEEE 802.3x,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1w,IEEE 802.1s,IEEE 802.1x,IEEE 802.3af,IEEE 802.3at |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 130 W |
| Power Source | Power Supply |
| Power Consumption | 9.10 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.73" (44 mm) |
| Width | 10.98" (279 mm) |
| Depth | 6.69" (170 mm) |
| Weight (Approximate) | 2.60 lb (1180 g) |
| Miscellaneous | |
| Package Contents | Business CBS220-8FP-E-2G Ethernet Switch Power Cord Mounting Kit Quick Start Guide |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What is the total PoE budget of this switch?
The Cisco CBS220-8FP-E-2G provides a total PoE budget of 130 watts. This budget is shared across all eight Gigabit Ethernet ports, allowing you to power multiple PoE and PoE+ devices simultaneously, such as IP phones, wireless access points, and security cameras, without requiring separate power supplies for each device.
How many SFP uplink ports does this switch have?
This switch includes two SFP (Small Form-factor Pluggable) uplink slots. These slots support both copper and fiber SFP transceivers, providing flexible connectivity options for extending your network with 1000Base-X connections over longer distances or for connecting to fiber infrastructure.
Is this switch manageable, and what features does it offer?
Yes, this is a fully manageable Layer 2 switch. It offers comprehensive management features including VLAN support for network segmentation, Quality of Service (QoS) for traffic prioritization, port mirroring for monitoring, IGMP snooping for multicast optimization, and spanning tree protocols for network redundancy and loop prevention.
What are the physical dimensions and mounting options?
The switch measures 1.73 inches high (44 mm), 10.98 inches wide (279 mm), and 6.69 inches deep (170 mm), weighing approximately 2.60 pounds (1180 g). It is designed for rack-mountable installation in standard 19-inch racks (1U height) and includes a mounting kit for flexible deployment in rack, wall, or desktop configurations.
What networking standards does this switch support?
The switch supports a comprehensive set of IEEE networking standards including 802.3af and 802.3at for PoE/PoE+, 802.1Q for VLAN tagging, 802.1x for network access control, 802.3ad for link aggregation, along with 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1D, 802.1w, and 802.1s for various Ethernet and switching functionalities.
What is included in the package with this switch?
The package includes the Cisco Business CBS220-8FP-E-2G Ethernet Switch itself, a power cord for operation, a mounting kit for installation in various configurations, and a quick start guide to help with initial setup and configuration. All necessary components for immediate deployment are provided.
