CradlePoint MBA1-2105-5GB-GA R2105 Wi-Fi 6 Dual-Band Ruggedized Router - 5G/LTE Advanced Pro Cellular - 2.5GbE PoE Port - Dual SIM - Vehicle/Cabinet
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The R2105 operates on the IEEE 802.11ax (Wi-Fi 6) standard across dual bands, supporting both 2.4 GHz ISM and 5 GHz UNII frequencies for optimal throughput and reduced interference. Cellular connectivity includes 5G, LTE Advanced Pro, UMTS, and HSPA+ technologies, ensuring backward compatibility and wide carrier support.
A single 2.5 Gigabit Ethernet port with Power over Ethernet capability simplifies deployment by delivering both data and power over one cable. VPN support enhances security for remote access, while dual nano-SIM slots enable carrier redundancy and failover for uninterrupted service.
Relevant factors for this section include Wi-Fi Generation, Network Band, Broadband Transmission Technology, Wireless LAN Standard. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
This router eliminates the need to separate hardware from service providers, streamlining deployments and reducing costs. The integrated PoE port transmits electrical power and data through a single cable to connected devices like access points, IP cameras, or VoIP phones, minimizing cabling complexity.
Ruggedized Construction
Built for vehicle and cabinet mounting, the R2105 withstands vibrations, temperature extremes, and harsh environments typical in mobile and industrial applications.
Dual SIM Redundancy
Two nano-SIM slots support multi-carrier configurations, providing automatic failover to maintain connectivity if one network experiences issues.
High-Speed Backhaul
2.5 Gigabit Ethernet and 5G cellular connectivity ensure sufficient bandwidth for HD video streaming, large file transfers, and real-time data applications.
Deployment / Use Cases
The R2105 excels in mobile and remote scenarios where traditional wired internet is unavailable or unreliable. Its rugged design and versatile mounting options make it ideal for vehicles, temporary sites, and industrial cabinets.
Emergency services such as police, fire, and ambulance fleets use these routers for real-time communication and data transmission. Transportation companies deploy them in buses, trains, and trucks for passenger Wi-Fi and fleet tracking. Industrial applications include remote monitoring, equipment telemetry, and temporary worksite networking.
Relevant factors for this section include Wi-Fi Generation, Network Band, Broadband Transmission Technology, Wireless LAN Standard. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring 15.20 inches wide, 4.53 inches deep, and 3.23 inches high, the R2105 has a compact footprint suitable for confined spaces. Weighing 3.22 pounds, it balances durability with manageable size for vehicle installations. The design supports both vehicle and cabinet mounting, with secure attachment points for stable operation in motion or fixed locations.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 3.23" (82 mm), 15.20" (386 mm), 4.53" (115 mm), 3.22 lb (1460 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 15.20" (386 mm)
- Depth
- 4.53" (115 mm)
- Height
- 3.23" (82 mm)
- Weight
- 3.22 lb (1460 g)
Highlights
- Wi-Fi 6 dual-band wireless with IEEE 802.11ax standard
- 5G and LTE Advanced Pro cellular connectivity with UMTS/HSPA+ fallback
- 2.5 Gigabit Ethernet port with Power over Ethernet support
- Dual nano-SIM slots for carrier redundancy and failover
- Four internal antennas for reliable signal reception
- VPN supported for secure remote access
- Ruggedized design for vehicle and cabinet mounting
- Compact dimensions: 15.20" W × 4.53" D × 3.23" H
- Ideal for emergency services, transportation, and industrial deployments
- Simplifies deployment with single-cable PoE connectivity
Specifications
| Specifications | |
|---|---|
| Manufacturer | ERICSSON |
| Manufacturer Part Number | MBA1-2105-5GB-GA |
| Brand Name | CradlePoint |
| Product Series | R2100 |
| Product Model | R2105 |
| Product Name | R2100 Series 5G Ruggedized Router |
| Product Type | Modem/Wireless Router |
| Technical Information | |
| Wi-Fi Generation | Wi-Fi 6 |
| Network Band | Dual Band |
| Wireless Specifications | |
| Broadband Transmission Technology | Cellular,Ethernet |
| Wireless LAN Standard | IEEE 802.11ax |
| ISM Band | Yes |
| UNII Band | Yes |
| ISM Maximum Frequency | 2.40 GHz |
| UNII Maximum Frequency | 5 GHz |
| Cellular Generation | 5G |
| Cellular Data Connectivity Technology | LTE Advanced Pro,UMTS,HSPA+ |
| Total Number of Antennas | 4 |
| Number of Internal Antennas | 4 |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 1 |
| PoE (RJ-45) Port | Yes |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| VPN Supported | Yes |
| Multi-SIM Supported | Yes |
| Number of SIM Card Supported | 2 |
| SIM Size Supported | Nano |
| Physical Characteristics | |
| Form Factor | Vehicle Mount,Cabinet Mount |
| Height | 3.23" (82 mm) |
| Width | 15.20" (386 mm) |
| Depth | 4.53" (115 mm) |
| Weight (Approximate) | 3.22 lb (1460 g) |
User Manual
FAQ
What Wi-Fi standard does the CradlePoint R2105 support?
The R2105 supports Wi-Fi 6 (IEEE 802.11ax) across dual bands, operating on both 2.4 GHz ISM and 5 GHz UNII frequencies. This provides faster throughput, better performance in congested environments, and improved efficiency for multiple connected devices compared to previous Wi-Fi generations.
Does this router support 5G cellular connectivity?
Yes, the R2105 includes 5G cellular capability along with LTE Advanced Pro, UMTS, and HSPA+ technologies. This ensures high-speed mobile broadband access with backward compatibility for areas where 5G coverage is still expanding, making it suitable for diverse geographic deployments.
How many SIM cards can the R2105 accommodate?
The router supports two nano-SIM cards simultaneously. This dual-SIM design enables multi-carrier configurations for load balancing or automatic failover, ensuring continuous connectivity if one cellular network experiences downtime or poor coverage.
What type of Ethernet port does the router have?
The R2105 features a single 2.5 Gigabit Ethernet port that also provides Power over Ethernet. This allows you to deliver both data and electrical power over one cable to compatible devices like access points or IP cameras, simplifying installation and reducing cable clutter.
Is the R2105 suitable for vehicle mounting?
Yes, the router is specifically designed for vehicle and cabinet mounting. Its ruggedized construction withstands vibrations, temperature variations, and harsh conditions common in mobile environments, making it ideal for emergency vehicles, public transit, and industrial fleets.
What are the dimensions and weight of the R2105?
The router measures 15.20 inches wide, 4.53 inches deep, and 3.23 inches high, with an approximate weight of 3.22 pounds. This compact and relatively lightweight design facilitates installation in confined spaces while maintaining durability for demanding applications.
