Dynatron High Airflow Cooling Fan Radiator Assembly With Five Fans Optimized For Sustained Ventilation Fan/Radiator Diameter Gal/min Maximum L25-1
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Number of Fans: 5
Fan Bearing Type: Dual Ball Bearing
Fan Speed (Max): 12000 rpm
Maximum Airflow: 21.53 CFM (36.57m³/h)
Noise Levels (A-Weighted): 54 dB(A)
Fan Life: 8.0 Year
Maximum Air Pressure: 22.912mmH2O
Cooler Type: Liquid Cooler
Compatible Intel Socket: Socket LGA-1851
Compatible AMD Socket: AM2 PGA-940,AM3 PGA-941,AM4,AM5,FM1,FM2
Connectors: Pin1- (-),Pin2- (+),Pin3- (Tachometer/Signal output),Pin4- (PWM)
Maximum Fan Diameter: 1.57" (40 mm)
Radiator Height: 10.94" (277.90 mm)
Radiator Width: 2.93" (74.40 mm)
Radiator Depth: 1.57" (40 mm)
Fan Height: 1.57" (40 mm)
Fan Width: 1.57" (40 mm)
Fan Depth: 1.10" (28 mm)
Application/Usage: Server,CPU,Processor
- Heavy-duty fan shroud ensures safe operation
- Features dual ball bearing for higher heat endurance and reduced noise emissions
- The competent cooling system is specially designed for standard processors
[custom-specifications]
| Specifications | |
| Manufacturer | Dynatron Corporation |
| Manufacturer Part Number | L25-1 |
| Manufacturer Website Address | http://www.dynatron-corp.com |
| Brand Name | Dynatron |
| Product Model | L25-1 |
| Product Name | L25-1 Cooling Fan/Radiator |
| Product Type | Cooling Fan/Radiator |
| Fan Information | |
| Number of Fans | 5 |
| Fan Bearing Type | Dual Ball Bearing |
| Fan Speed (Max) | 12000 rpm |
| Maximum Airflow | 21.53 CFM (36.57m³/h) |
| Noise Levels (A-Weighted) | 54 dB(A) |
| Fan Life | 8.0 Year |
| Maximum Air Pressure | 22.912mmH2O |
| Heatsink Information | |
| Cooler Type | Liquid Cooler |
| Compatible Intel Socket | Socket LGA-1851 |
| Compatible AMD Socket | AM2 PGA-940,AM3 PGA-941,AM4,AM5,FM1,FM2 |
| Interfaces/Ports | |
| Connectors | Pin1- (-),Pin2- (+),Pin3- (Tachometer/Signal output),Pin4- (PWM) |
| Physical Characteristics | |
| Maximum Fan Diameter | 1.57" (40 mm) |
| Radiator Height | 10.94" (277.90 mm) |
| Radiator Width | 2.93" (74.40 mm) |
| Radiator Depth | 1.57" (40 mm) |
| Fan Height | 1.57" (40 mm) |
| Fan Width | 1.57" (40 mm) |
| Fan Depth | 1.10" (28 mm) |
| Miscellaneous | |
| Application/Usage | Server,CPU,Processor |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
[/custom-user-manual]
