Eaton 124100020-001 15 kVA External Wall-Mountable Maintenance Bypass Switch - 110V AC Input - 208V AC Output - Compatible with Powerware 9355 UPS
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This bypass switch delivers robust power management with a 15 kW load capacity, making it suitable for medium to large-scale UPS deployments. The input voltage of 110 V AC and output voltage of 208 V AC align with standard North American power configurations, ensuring compatibility with existing electrical systems.
The switch's design prioritizes safety and reliability, featuring a sturdy construction that withstands operational demands. It integrates seamlessly with Eaton Powerware 9355 UPS units, providing a straightforward solution for maintenance bypass needs in critical power applications.
This section brings together practical product details such as Load Capacity (VA), Input Voltage, Output Voltage, Form Factor, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Eaton 124100020-001 offers distinct advantages for IT power management, combining high capacity with practical installation features. Its external wall-mountable design eliminates the need for rack space, providing flexibility in deployment while maintaining robust performance.
High Load Capacity
Supports up to 15 kW, suitable for demanding UPS systems and critical loads in business environments.
- 15 kW capacity
- Handles medium to large-scale power needs
Flexible Installation
Wall-mountable form factor allows for space-efficient placement, ideal for data centers with limited rack availability.
- Saves rack space
- Easy wall mounting
Reliable Compatibility
Specifically designed for Eaton Powerware 9355 UPS, ensuring seamless integration and dependable operation.
- Optimized for Powerware 9355
- Reduces compatibility issues
Deployment / Use Cases
This maintenance bypass switch is ideal for environments where uninterrupted power is critical, such as data centers, server rooms, and network closets. It enables safe maintenance of UPS systems without downtime, supporting business continuity and IT infrastructure reliability.
Common use cases include scheduled UPS servicing, battery replacements, and system upgrades. The wall-mountable design makes it suitable for facilities with space constraints or those preferring external mounting for easier access and ventilation.
Data Center Maintenance
Allows technicians to service Powerware 9355 UPS units while keeping connected servers and networking equipment powered, minimizing disruption during maintenance windows.
Server Room Upgrades
Facilitates UPS upgrades or replacements in server rooms by providing a bypass path, ensuring continuous operation of critical IT loads during the transition.
Physical Profile
The switch measures 36 inches in height, 20 inches in width, and 5.70 inches in depth, with an approximate weight of 66 pounds. Its compact and shallow depth supports wall mounting in tight spaces, while the robust construction ensures durability in operational environments. The design includes mounting hardware for secure installation, and the finish is tailored for professional IT settings.
- Width
- 20" (508 mm)
- Depth
- 5.70" (144.78 mm)
- Height
- 36" (914.40 mm)
- Weight
- 66 lb (29937.10 g)
Highlights
- 15 kVA load capacity for medium to large-scale UPS systems
- Wall-mountable form factor saves valuable rack space
- Input voltage: 110 V AC, output voltage: 208 V AC
- Compatible with Eaton Powerware 9355 UPS units
- Dimensions: 36" H x 20" W x 5.70" D
- Weight: approximately 66 pounds
- Durable enclosure for reliable operation
- 2-year limited warranty for added peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | 124100020-001 |
| Brand Name | Eaton |
| Product Name | 15 kVA External Wall Mountable Maintenance Bypass Switch |
| Product Type | Bypass Switch |
| Power Description | |
| Load Capacity (VA) | 15 kW |
| Input Voltage | 110 V AC |
| Output Voltage | 208 V AC |
| Physical Characteristics | |
| Form Factor | Wall-mountable |
| Height | 36" (914.40 mm) |
| Width | 20" (508 mm) |
| Depth | 5.70" (144.78 mm) |
| Weight (Approximate) | 66 lb (29937.10 g) |
| Miscellaneous | |
| Compatibility | Powerware 9355 UPS |
| Country of Origin | United States |
| Warranty | |
| Limited Warranty | 2 Year |
FAQ
What is the load capacity of this Eaton bypass switch?
The Eaton 124100020-001 has a load capacity of 15 kW (15 kVA), making it suitable for medium to large-scale UPS deployments. This capacity supports critical IT loads during maintenance, ensuring uninterrupted power for servers, networking equipment, and other business infrastructure.
What input and output voltages does this switch support?
This switch accepts an input voltage of 110 V AC and delivers an output voltage of 208 V AC. These voltages align with standard North American power configurations, allowing seamless integration into existing electrical systems for reliable power distribution in data centers and server rooms.
Is this bypass switch compatible with my Eaton UPS?
Yes, the Eaton 124100020-001 is specifically designed for compatibility with Powerware 9355 UPS systems. It ensures safe and reliable bypass operation during maintenance, providing a dedicated solution for users of this UPS model without requiring additional adapters or modifications.
How is this switch installed?
The switch features a wall-mountable form factor, allowing installation on walls or other vertical surfaces. This design saves rack space and offers flexibility in placement, with dimensions of 36" H x 20" W x 5.70" D and a weight of 66 lb, making it manageable for standard IT installation procedures.
What are the dimensions and weight of this bypass switch?
The switch measures 36 inches in height, 20 inches in width, and 5.70 inches in depth, with an approximate weight of 66 pounds. Its compact profile supports wall mounting in space-constrained environments, while the sturdy build ensures durability in operational settings.
What warranty coverage does Eaton provide for this product?
Eaton offers a 2-year limited warranty for the 124100020-001 bypass switch. This warranty covers defects in materials and workmanship, providing confidence in the product's reliability and support for business-critical power management applications.
