Eaton 5P1000RC 5P 1000VA 2U Rackmount UPS - 770W - 120V AC - 10 NEMA 5-15R Outlets - Wall Mountable - Line-Interactive
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The Eaton 5P 1000VA UPS is a line-interactive power backup solution engineered for business IT environments requiring reliable protection against power disturbances and outages. This unit delivers 1 kVA (770W) of load capacity through 10 NEMA 5-15R outlets, providing clean 120V AC output to support critical equipment such as servers, network switches, and office electronics. Its compact 2U form factor is designed for rackmount installation in standard 19-inch enclosures, while wall-mount capability offers flexibility for space-constrained deployments like network closets or telecommunications rooms.
Built with Eaton's exclusive ABM (Advanced Battery Management) technology, this UPS extends internal battery life by 50% through a 3-stage charging process that reduces stress and maintenance intervals. The included multi-purpose rail kit simplifies rack installation, and the 5-button graphical LCD provides real-time monitoring of load status, battery condition, and operational parameters. With RoHS compliance and a 3-year limited warranty, this UPS combines robust power protection with installation versatility for diverse business applications.
Technical Overview
This line-interactive UPS maintains 120V AC output from 120V AC input, ensuring compatibility with standard North American power systems and delivering 20% more wattage than traditional UPS systems of similar VA rating. The advanced power conversion technology provides 770W of available power, enhancing protection headroom for connected devices and reducing overload risks during peak demand. The unit's electrical design includes efficient voltage regulation and battery backup capabilities, making it suitable for environments with moderate power quality issues.
The 5-button graphical LCD interface offers comprehensive monitoring of critical UPS data, including input/output voltage, load capacity percentage, battery runtime estimates, and system status alerts. For extended management capabilities, an optional NETWORK-M2 Gigabit network card enables full remote access, control, and monitoring over network connections. The UPS's line-interactive topology balances performance with cost-effectiveness, providing automatic voltage regulation (AVR) to correct minor fluctuations without switching to battery power, thereby preserving battery life and ensuring consistent power delivery.
Key Product Advantages
The Eaton 5P series combines robust power protection with installation flexibility, making it ideal for server rooms, network closets, and office environments where reliable backup power is essential.
Extended Battery Life
ABM technology with 3-stage charging increases internal battery life by 50%, reducing maintenance costs and improving long-term reliability.
- 3-stage charging algorithm
- Reduced battery stress
- Longer service intervals
Enhanced Power Capacity
Delivers 20% more wattage than traditional UPS systems, providing greater protection headroom for connected equipment.
- 770W output capacity
- Efficient power conversion
- Reduced overload risk
Dual Mounting Options
2U rackmount design with included rail kit plus wall-mount capability offers installation flexibility for various environments.
- Standard 19-inch rack compatible
- Wall mount brackets included
- Space-efficient 2U height
Deployment / Use Cases
The Eaton 5P 1000VA UPS is engineered for business-critical applications where uninterrupted power is non-negotiable. Its combination of power capacity, monitoring capabilities, and flexible installation makes it suitable for diverse IT infrastructure deployments.
In server room environments, this UPS protects rack-mounted equipment including network switches, storage arrays, and smaller servers. The 10-outlet configuration supports multiple devices while the 2U form factor conserves valuable rack space. For network closets and telecommunications rooms, the wall-mount option provides power protection without consuming floor or rack space.
Server Room Protection
Provides backup power for critical network infrastructure, allowing time for graceful shutdowns during extended outages.
- Rackmount installation
- 10-outlet capacity
- Remote management capable
Office Equipment Backup
Protects workstations, network equipment, and other office electronics from power disturbances and outages.
- Wall-mount flexibility
- Clean power output
- User-friendly interface
Physical Profile
The compact 2U design measures 3.40" (86.36 mm) in height, 17.30" (439.42 mm) in width, and 16" (406.40 mm) in depth, fitting standard 19-inch rack enclosures. At 33.07 lb (15000 g), the unit balances substantial construction with manageable weight for installation. The multi-purpose rail kit supports secure mounting in rack environments, while wall-mount capability provides alternative installation options where rack space is limited.
- Width
- 17.30" (439.42 mm)
- Depth
- 16" (406.40 mm)
- Height
- 3.40" (86.36 mm)
- Weight
- 33.07 lb (15000 g)
What's in the Box
The package includes everything needed for immediate deployment and operation of the UPS system.
Highlights
- 1 kVA / 770W load capacity for robust power protection
- 10 NEMA 5-15R outlets support multiple connected devices
- 2U rackmount design with wall-mount capability
- ABM technology extends battery life by 50%
- 5-button graphical LCD for real-time status monitoring
- Line-interactive topology ensures clean power output
- Includes multi-purpose rail kit for easy installation
- RoHS compliant and environmentally friendly
- 3-year limited warranty for peace of mind
- Optional NETWORK-M2 Gigabit network card enables remote management
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | 5P1000RC |
| Brand Name | Eaton |
| Product Name | 1000VA Rack/Wall Mountable UPS |
| Product Type | Line-interactive UPS |
| Technical Information | |
| Receptacle Type | NEMA 5-15R |
| Receptacle Detail | 10 x NEMA 5-15R |
| Power Description | |
| Load Capacity (VA) | 1 kVA |
| Load Capacity (Watt) | 770 W |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Physical Characteristics | |
| Height | 3.40" (86.36 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 16" (406.40 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable,Wall Mountable |
| Weight (Approximate) | 33.07 lb (15000 g) |
| Miscellaneous | |
| Package Contents | 1000VA Rack/Wall Mountable UPS Quick Start Guide USB Cable RS-232 Serial Cable Multi-purpose Rail Kit |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What processor does this product use?
Eaton 5P rackmount compact 1000VA UPS - 2U Rack-mountable, Wall Mountable - 120 V AC Input - 120 V AC Output - 10 x NEMA 5-15R (5P1000RC) is positioned around the processor configuration shown in the , giving buyers a clearer view of expected performance for business workloads and everyday deployment needs.
How much memory is installed?
The installed memory configuration for Eaton 5P rackmount compact 1000VA UPS - 2U Rack-mountable, Wall Mountable - 120 V AC Input - 120 V AC Output - 10 x NEMA 5-15R (5P1000RC) should be reviewed alongside your workload needs, especially if you are planning multitasking, heavier applications, or longer lifecycle deployment use.
What storage is included?
Storage details for Eaton 5P rackmount compact 1000VA UPS - 2U Rack-mountable, Wall Mountable - 120 V AC Input - 120 V AC Output - 10 x NEMA 5-15R (5P1000RC) are intended to support operating system files, applications, and day-to-day business data while keeping the platform aligned with practical deployment expectations.
What display size or resolution is listed?
Display-related specifications help position Eaton 5P rackmount compact 1000VA UPS - 2U Rack-mountable, Wall Mountable - 120 V AC Input - 120 V AC Output - 10 x NEMA 5-15R (5P1000RC) for the kind of viewing experience, readability, and workspace fit buyers may expect in business it/ups & power backup/general & industrial ups deployments.
What connectivity options are available?
Connectivity details help confirm how Eaton 5P rackmount compact 1000VA UPS - 2U Rack-mountable, Wall Mountable - 120 V AC Input - 120 V AC Output - 10 x NEMA 5-15R (5P1000RC) can integrate with your network, accessories, and surrounding peripherals before rollout or replacement planning.
What operating system or platform is included?
Eaton 5P rackmount compact 1000VA UPS - 2U Rack-mountable, Wall Mountable - 120 V AC Input - 120 V AC Output - 10 x NEMA 5-15R (5P1000RC) is described for practical deployment use, and the specification set helps buyers confirm fit, compatibility, and expected day-to-day operation.
