EIZO RadiForce MS236WT-BK 23" Class LCD Touchscreen Monitor - 16:9 - 11 ms - 23" Viewable - Projected Capacitive - Multi-touch Screen (MS236WT-BK)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- RadiForce MS236WT 2MP 58cm (23.0") Multitouch Color LCD Monitor
- AC Power cord
- DVI-D - DVI-D cable
- DisplayPort - DisplayPort cable
- USB cable
- Audio cable
- Touch pen
- Holder for touch pen
- Utility Disk (User's manual, Touch panel driver, TPOffset)
- Cleaning cloth
- Mask sheet
Screen Size Class: 23"
Viewable Screen Size: 23"
Screen Mode: Full HD
Response Time: 11 ms
Aspect Ratio: 16:9
Backlight Technology: LED
Horizontal Frequency: 31 kHz to 64 kHz - DVI,31 kHz to 68 kHz - DisplayPort,31 kHz to 81 kHz - Analog
Vertical Frequency: 59 Hz to 61 Hz - Analog,59 Hz to 61 Hz - DisplayPort,59 Hz to 61 Hz - DVI,69 Hz to 71 Hz - VGA
Maximum Resolution: 1920 x 1080
Color Supported: 16.7 Million Colors
Native Contrast Ratio: 1,000:1
Brightness: 260 cd/m²
Speakers: Yes
Touchscreen Type: Projected Capacitive
Multi-touch Screen: Yes
DVI: Yes
USB: Yes
VGA: Yes
DisplayPort: Yes
Number of DisplayPorts: 1
Built-in Devices: USB Hub
Operating Power Consumption: 42 W
Color Family: Black
Product Color: Black
Height: 13.35" (339.20 mm)
Width: 21.92" (556.70 mm)
Depth: 2.13" (54 mm)
Height with Stand: 14.45" (367 mm)
Width with Stand: 21.92" (556.70 mm)
Depth with Stand: 3.50" (88.90 mm)
Weight (Approximate): 13.23 lb (6000 g)
Weight with Stand (Approximate): 14.55 lb (6600 g)
Package Contents:
Country of Origin: Japan
Environmentally Friendly: Yes
Environmental Compliance: China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Limited Warranty: 3 Year
- The Full HD lcd touchscreen monitor is perfect for retail, hospitality, and point-of-sale applications
- The Full HD screen size with Full HD resolution (19201080) delivers sharp, detailed visuals without quality loss or downscaling
- Projective Capacitive touchscreen supports two-finger multi-touch for smooth zooming, scrolling, and gesture-based navigation
- LED backlight technology reduces power use and hazardous materials for eco-friendly performance
- Enjoy crisp visuals and vibrant hues with 260 cd/m² brightness for effortless touch navigation
- 16.7 million colors supported for lifelike visuals and smooth touch-based creative workflows
[custom-specifications]
| Specifications | |
| Manufacturer | EIZO |
| Manufacturer Part Number | MS236WT-BK |
| Manufacturer Website Address | http://www.eizo.com |
| Brand Name | EIZO |
| Product Line | RadiForce |
| Product Model | MS236WT-BK |
| Product Name | RadiForce MS236WT 2MP 58cm (23.0") Multitouch Color LCD Monitor |
| Product Type | LCD Touchscreen Monitor |
| Technical Information | |
| Screen Size Class | 23" |
| Viewable Screen Size | 23" |
| Screen Mode | Full HD |
| Response Time | 11 ms |
| Aspect Ratio | 16:9 |
| Backlight Technology | LED |
| Horizontal Frequency | 31 kHz to 64 kHz - DVI,31 kHz to 68 kHz - DisplayPort,31 kHz to 81 kHz - Analog |
| Vertical Frequency | 59 Hz to 61 Hz - Analog,59 Hz to 61 Hz - DisplayPort,59 Hz to 61 Hz - DVI,69 Hz to 71 Hz - VGA |
| Video | |
| Maximum Resolution | 1920 x 1080 |
| Color Supported | 16.7 Million Colors |
| Native Contrast Ratio | 1,000:1 |
| Brightness | 260 cd/m² |
| Audio | |
| Speakers | Yes |
| Touchscreen Information | |
| Touchscreen Type | Projected Capacitive |
| Multi-touch Screen | Yes |
| Interfaces/Ports | |
| DVI | Yes |
| USB | Yes |
| VGA | Yes |
| DisplayPort | Yes |
| Number of DisplayPorts | 1 |
| Built-in Devices | |
| Built-in Devices | USB Hub |
| Power Description | |
| Operating Power Consumption | 42 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Height | 13.35" (339.20 mm) |
| Width | 21.92" (556.70 mm) |
| Depth | 2.13" (54 mm) |
| Height with Stand | 14.45" (367 mm) |
| Width with Stand | 21.92" (556.70 mm) |
| Depth with Stand | 3.50" (88.90 mm) |
| Weight (Approximate) | 13.23 lb (6000 g) |
| Weight with Stand (Approximate) | 14.55 lb (6600 g) |
| Miscellaneous | |
| Package Contents |
|
| Country of Origin | Japan |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 3 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
[/custom-user-manual]
