EnGenius EWS7928P-FIT 24-Port Gigabit PoE+ Managed Switch - Layer 2240W PoE Budget - 4 SFP Slots - Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Layer 2 managed switch delivers 56 Gbps switching capacity with support for 10/100/1000Base-T Ethernet over twisted pair and 1000Base-X via fiber optic connections through the four SFP expansion slots. The switch implements comprehensive networking standards including IEEE 802.3at/af for PoE+, IEEE 802.1Q for VLAN support, IEEE 802.3ad for link aggregation, and IEEE 802.1x for network access control.
The management capabilities extend beyond basic switching to include real-time system metrics, analytics, and remote configuration options. The modular design with four SFP slots provides uplink flexibility for connecting to core switches or extending network segments with fiber optic cabling where longer distances or electrical isolation are required.
Relevant factors for this section include Total Number of Network Ports, Network (RJ-45), Uplink Port, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The EWS7928P-FIT distinguishes itself through its balanced combination of power delivery, management flexibility, and deployment-ready design. The 240W PoE budget distributed across all 24 ports ensures adequate power for modern PoE devices without requiring external power injectors or additional power supplies.
Hybrid Management Flexibility
Supports multiple management approaches including cloud-based management with no recurring fees, local web interface for on-premise control, and mobile app configuration for quick setup and monitoring from any location.
- Cloud visibility without licensing costs
- Mobile app with QR code setup
- Web interface for detailed configuration
Comprehensive PoE Support
All 24 ports support IEEE 802.3at PoE+ and IEEE 802.3af PoE standards, delivering up to 30W per port for powering demanding devices like PTZ cameras, multi-radio access points, and digital signage displays.
- 240W total PoE budget
- 802.3at/af compliance
- Auto-sensing per port
Enterprise Switching Features
Includes VLAN support, link aggregation, QoS prioritization, and spanning tree protocol for creating resilient, segmented networks that prioritize business-critical traffic and applications.
- VLAN segmentation
- Link aggregation groups
- Traffic prioritization
Deployment / Use Cases
This switch is engineered for small to medium business environments where reliable power delivery and network segmentation are essential. The rack-mountable 1U form factor makes it suitable for installation in standard server racks, network closets, or wall-mounted enclosures in retail, office, education, and hospitality settings.
Common deployment scenarios include powering and connecting wireless access points throughout a facility while maintaining VLAN separation for guest and corporate networks. The switch also serves well in security installations where multiple IP cameras require both network connectivity and power from a centralized location, with fiber uplinks to a central monitoring station.
Unified Wireless Deployment
Power and connect multiple wireless access points while implementing separate VLANs for employee, guest, and IoT device networks, with fiber uplinks to core infrastructure.
Integrated Security Systems
Deploy as the central switch for IP surveillance systems, providing both network connectivity and power to cameras while using SFP uplinks for long-distance connections to recording servers.
Physical Profile
The switch features a standard 1U rack-mountable design measuring 1.73 inches in height, 17.32 inches in width, and 10.23 inches in depth, compatible with 19-inch server racks. The steel construction provides durability for commercial installations, while the included rack mount kit facilitates secure mounting in network cabinets or server rooms. The 7.82-pound weight and compact depth make it suitable for space-constrained environments while providing adequate ventilation for continuous operation.
- Width
- 17.32" (439.93 mm)
- Depth
- 10.23" (259.84 mm)
- Height
- 1.73" (43.94 mm)
- Weight
- 7.82 lb (3547.09 g)
What's in the Box
The package includes all necessary components for immediate deployment and management of the switch in your network environment.
Highlights
- 24 Gigabit Ethernet ports with PoE+ support on all ports
- 240W total PoE budget for powering multiple devices simultaneously
- Four SFP slots for fiber optic uplinks or network expansion
- Layer 2 managed switching with VLAN and QoS capabilities
- 56 Gbps switching capacity for high-performance networking
- Hybrid management: cloud, web, or mobile app configuration
- Rack-mountable 1U form factor for standard server installations
- No recurring licensing fees for cloud management features
- Real-time monitoring and remote configuration capabilities
- Includes rack mount kit and console cable for immediate deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | EnGenius Technologies, Inc |
| Manufacturer Part Number | EWS7928P-FIT |
| Brand Name | EnGenius |
| Product Line | Fit |
| Product Model | EWS7928P-FIT |
| Product Name | EWS7928P-FIT Ethernet Switch |
| Packaged Quantity | 1 |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet PoE+,4 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4.0 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1x,IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3af,IEEE 802.1Q,IEEE 802.1D,IEEE 802.3ad,IEEE 802.3at |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 240 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Height | 1.73" (43.94 mm) |
| Width | 17.32" (439.93 mm) |
| Depth | 10.23" (259.84 mm) |
| Weight (Approximate) | 7.82 lb (3547.09 g) |
| Miscellaneous | |
| Package Contents | EWS7928P-FIT Ethernet Switch 1 x Power Cord 1 x Rack Mount Kit 1 x RJ-45 Console Cable Quick Start Guide QR Code Mobile App QR Code |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
How many devices can this switch power simultaneously with PoE?
The EWS7928P-FIT features a 240W PoE budget distributed across all 24 ports, allowing it to power multiple PoE devices concurrently. The actual number of devices depends on their individual power requirements, with IEEE 802.3af devices drawing up to 15.4W and IEEE 802.3at PoE+ devices drawing up to 30W per port. The switch automatically negotiates power delivery with each connected device, ensuring efficient power allocation across your network.
What types of uplink connections does this switch support?
This switch provides four SFP (mini-GBIC) expansion slots that support 1000Base-X fiber optic connections for uplinks to core switches or network segments. These slots accept standard SFP transceivers for various fiber types including multi-mode and single-mode, enabling flexible uplink configurations based on distance requirements and existing infrastructure. The SFP slots complement the 24 copper RJ-45 ports, providing both copper and fiber connectivity options in a single switch.
What management options are available for this switch?
The EWS7928P-FIT offers hybrid management through three primary methods: cloud-based management via the EnGenius cloud platform with no recurring licensing fees, local web interface for traditional browser-based configuration, and mobile app management using the EnGenius mobile application. This multi-approach design allows network administrators to choose the management style that best fits their operational preferences, whether they prefer centralized cloud visibility, on-premise control, or mobile device management for quick adjustments.
Is this switch suitable for VLAN segmentation?
Yes, as a Layer 2 managed switch, the EWS7928P-FIT supports IEEE 802.1Q VLAN tagging for network segmentation. This allows you to create separate virtual LANs for different departments, device types, or security zones within your network. VLAN support enables traffic isolation between groups, improves network security by limiting broadcast domains, and allows for more efficient bandwidth utilization while maintaining all devices on the same physical switch infrastructure.
What is the switching capacity of this model?
The EWS7928P-FIT delivers 56 Gbps of switching capacity, providing ample bandwidth for simultaneous full-duplex traffic across all ports. This non-blocking architecture ensures that even with multiple high-bandwidth applications running concurrently, such as video streaming, large file transfers, and VoIP communications, the switch maintains optimal performance without packet loss or latency issues that could impact network operations.
What comes included for rack mounting installation?
The package includes a complete rack mount kit with all necessary hardware for installing the switch in a standard 19-inch server rack. The kit typically includes rack ears that attach to the switch chassis and appropriate mounting screws for securing the unit to rack posts. The switch itself measures 1.73 inches (1U) in height, making it compatible with standard rack units, while its 17.32-inch width ensures proper fit within 19-inch rack frames commonly used in server rooms and network closets.
