Fortinet FGR-60F-3G4G FortiGate Rugged Network Security Firewall Appliance - 6 Port Gigabit Ethernet with 2 SFP Slots - Desktop/DIN Rail/Wall
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This FortiGate Rugged appliance operates on Gigabit Ethernet technology, supporting network standards of 10/100/1000Base-T and 1000Base-X for high-speed data transmission. The hardware includes six RJ-45 ports for copper connectivity and two SFP (mini-GBIC) slots for fiber optic expansion, offering flexibility in network media selection.
Security capabilities are comprehensive, featuring threat protection, SSL encrypted traffic inspection, application control, and malware protection. The device supports up to 100 concurrent VPN connections, enabling secure remote access and site-to-site tunneling. Management is fully supported through Fortinet's security fabric ecosystem.
Relevant factors for this section include Firewall Protection Supported, Encryption Standard, Number of VPN Supported, Total Number of Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The FGR-60F-3G4G combines rugged durability with advanced security features, making it ideal for industrial, retail, or remote office locations where environmental factors or space constraints are considerations.
Multi-Mount Flexibility
Install the appliance on a desktop, DIN rail, or wall with included mounting options, adapting to various infrastructure layouts without requiring additional brackets or kits.
Integrated Threat Protection
Leverage built-in threat protection, application control, and malware defense to inspect both clear-text and SSL-encrypted traffic, reducing the attack surface without external security services.
High-Density Connectivity
Six Gigabit Ethernet ports and two SFP slots provide ample interfaces for WAN, LAN, and uplink connections, supporting network segmentation and high-bandwidth applications.
Deployment / Use Cases
The FortiGate Rugged FGR-60F-3G4G is designed for edge-security scenarios where reliability and compactness are critical. Its ruggedized construction and versatile mounting make it suitable for environments with vibration, dust, or limited space.
Common deployments include retail branch offices, manufacturing floors, transportation hubs, and utility substations. The appliance can serve as a primary firewall for small networks or as a secure gateway for IoT devices, point-of-sale systems, and industrial control networks.
Relevant factors for this section include Firewall Protection Supported, Encryption Standard, Number of VPN Supported, Total Number of Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Industrial IoT Security
Protect operational technology networks by segmenting IoT devices, enforcing application policies, and inspecting traffic between sensors, controllers, and enterprise systems.
Remote Office Connectivity
Establish secure VPN tunnels between branch locations and headquarters, ensuring encrypted data exchange and centralized management of security policies across distributed sites.
Physical Profile
The appliance measures 8.50" wide, 6.50" deep, and 1.68" high, with a weight of approximately 3.85 pounds. Its compact dimensions allow for discreet installation in control panels, network cabinets, or wall-mounted enclosures. The ruggedized chassis withstands typical industrial environmental conditions, and multiple mounting options provide installation flexibility without custom hardware.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1.68" (42.67 mm), 8.50" (215.90 mm), 6.50" (165.10 mm), 3.85 lb (1746.33 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 8.50" (215.90 mm)
- Depth
- 6.50" (165.10 mm)
- Height
- 1.68" (42.67 mm)
- Weight
- 3.85 lb (1746.33 g)
Highlights
- 6 Gigabit Ethernet ports for high-speed network connectivity
- 2 SFP (mini-GBIC) slots for fiber optic expansion
- Supports 100 concurrent VPN tunnels for secure remote access
- AES-256 and SHA-256 encryption for data protection
- Threat protection, application control, and malware defense
- Desktop, DIN rail, or wall mounting options
- Fully manageable through Fortinet security fabric
- Ruggedized design for demanding environments
- Compact footprint: 8.50" W x 6.50" D x 1.68" H
- 1-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Fortinet, Inc |
| Manufacturer Part Number | FGR-60F-3G4G |
| Brand Name | Fortinet |
| Product Line | FortiGate Rugged |
| Product Model | FGR-60F-3G4G |
| Product Name | FortiGate Rugged FGR-60F-3G4G Network Security/Firewall Appliance |
| Product Type | Network Security/Firewall Appliance |
| Technical Information | |
| Firewall Protection Supported | Threat Protection,SSL Encrypted Traffic Protection,Application Control,Malware Protection |
| Encryption Standard | AES (256-bit),SHA-256 |
| Number of VPN Supported | 100 |
| Interfaces/Ports | |
| Total Number of Ports | 6 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 6 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Standard | 10/100/1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 2 |
| Management & Protocols | |
| Manageable | Yes |
| Physical Characteristics | |
| Form Factor | Desktop,DIN Rail Mountable,Wall Mountable |
| Height | 1.68" (42.67 mm) |
| Width | 8.50" (215.90 mm) |
| Depth | 6.50" (165.10 mm) |
| Weight (Approximate) | 3.85 lb (1746.33 g) |
| Miscellaneous | |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 1 Year |
FAQ
How many Ethernet ports does the FortiGate Rugged FGR-60F-3G4G have?
The appliance includes six Gigabit Ethernet RJ-45 ports, providing ample connectivity for WAN, LAN, and device connections. These ports support 10/100/1000Base-T standards, ensuring compatibility with existing network infrastructure and high-speed data transfer capabilities.
What expansion slots are available on this firewall appliance?
Two SFP (mini-GBIC) slots are available for fiber optic expansion. These slots allow the use of SFP transceivers to connect to fiber optic networks, extending connectivity options beyond copper Ethernet and supporting longer distance or higher bandwidth requirements.
How many VPN connections can the FGR-60F-3G4G support simultaneously?
This FortiGate Rugged model supports up to 100 concurrent VPN connections. This capacity enables secure site-to-site or remote access VPN tunnels, making it suitable for connecting multiple branch offices or providing secure access for remote employees.
What security features are included in this firewall appliance?
Security features include threat protection, SSL encrypted traffic inspection, application control, and malware protection. The appliance uses AES-256 and SHA-256 encryption standards to secure data in transit, providing comprehensive defense against network-based threats and unauthorized access.
What mounting options are available for this device?
The FGR-60F-3G4G supports desktop, DIN rail, and wall mounting. This flexibility allows installation in various environments, from standard office settings to industrial control panels, without requiring additional mounting kits or custom hardware.
Is this firewall appliance manageable?
Yes, the appliance is fully manageable through Fortinet's security management platform. This allows centralized configuration, policy enforcement, and monitoring, enabling consistent security controls across the network and integration with other Fortinet security products.
