Gigabyte R163-Z32-AAC2 Barebone System - 1U Rackmount - AMD EPYC Socket SP5256GB DDR5 - 12Gb/s SAS
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This barebone system features a comprehensive I/O profile with four USB 3.2 Gen 1 ports for peripheral connectivity and Gigabit Ethernet for network integration. The ASPEED AST2600 graphics controller provides reliable out-of-band management capabilities, essential for remote server administration.
Power delivery is handled by dual 1.30kW power supplies with automatic voltage sensing for 120V or 230V AC input, ensuring redundancy and stable operation in data center environments. The 1U rackmount design maximizes density while maintaining serviceability with standard rack dimensions.
Relevant factors for this section include Number of Processors Supported, Processor Socket, Processor Supported, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The 1U form factor optimizes rack space utilization without compromising expansion capabilities, featuring two PCIe x16 slots for additional connectivity or acceleration cards. Dual redundant power supplies with 1.30kW capacity ensure continuous operation, while broad operating system compatibility simplifies deployment across Windows Server and multiple Linux distributions.
Enterprise Storage Ready
Integrated 12Gb/s SAS controllers deliver the speed and reliability needed for high-performance storage arrays, while twelve expansion bays provide ample room for drive installation.
- 12Gb/s SAS interface
- Serial ATA/600 support
- 12 total expansion bays
Modern Memory Architecture
DDR5-4800 memory support across twelve slots enables higher bandwidth and efficiency compared to previous generations, crucial for memory-intensive server applications.
- DDR5-4800/PC5-38400
- 256GB maximum capacity
- 12 memory slots
Deployment / Use Cases
This barebone system is designed for IT professionals building custom server solutions where specific processor, memory, and storage configurations are required. The platform supports Windows Server 2019/2022 along with multiple enterprise Linux distributions including Red Hat Enterprise Linux, SUSE Linux Enterprise Server, and Ubuntu LTS versions.
Typical deployment scenarios include departmental file servers, application hosting platforms, development/test environments, and edge computing nodes where rack density and remote management capabilities are prioritized.
Virtualization Host
With AMD EPYC processor support and substantial memory capacity, this system serves as an efficient platform for hypervisor deployment, supporting multiple virtual machines for consolidated server environments.
Storage Server
The combination of 12Gb/s SAS controllers, twelve expansion bays, and dual PCIe slots makes this barebone ideal for NAS, SAN, or backup storage solutions in small to medium business settings.
Physical Profile
The 1U rackmount chassis measures 1.71 inches in height (43.50 mm), 17.24 inches in width (438 mm), and 27.95 inches in depth (710 mm), conforming to standard 19-inch rack requirements. This compact footprint maximizes data center density while maintaining adequate airflow for component cooling. The rack-mountable design includes standard mounting hardware compatibility for straightforward installation in server cabinets.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1U, 17.24" (438 mm), 27.95" (710 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.24" (438 mm)
- Depth
- 27.95" (710 mm)
- Height
- 1U
Highlights
- 1U rackmount barebone system with AMD EPYC processor support
- Supports up to 256GB DDR5-4800 memory across 12 DIMM slots
- Integrated 12Gb/s SAS and SATA/600 storage controllers
- Dual PCI Express x16 expansion slots for additional cards
- Four USB 3.2 Gen 1 ports for peripheral connectivity
- Gigabit Ethernet networking with ASPEED AST2600 management
- Dual 1.30kW power supplies with 120/230V AC auto-sensing
- Compatible with Windows Server and multiple Linux distributions
- Twelve total expansion bays for storage drive installation
- Compact 1U form factor optimizes rack space utilization
Specifications
| Specifications | |
|---|---|
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | R163-Z32-AAC2 |
| Brand Name | GIGABYTE |
| Product Model | R163-Z32 |
| Product Name | R163-Z32 (rev. AAC2) Barebone System |
| Packaged Quantity | 1 |
| Product Type | Barebone System |
| Processor | |
| Number of Processors Supported | 1 |
| Processor Socket | Socket SP5 LGA-6096 |
| Processor Supported | EPYC |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Maximum Memory Supported | 256 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Total Number of Memory Slots | 12 |
| Controllers | |
| Controller Type | 12Gb/s SAS,Serial ATA/600 |
| RAID Supported | No |
| Display & Graphics | |
| Graphics Controller Manufacturer | ASPEED |
| Graphics Controller Model | AST2600 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 12 |
| Total Number of Expansion Slots | 2 |
| Number of PCI Express x16 Slots | 2 |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.2 Gen 1 Ports | 4 |
| Operating System | |
| Operating System Supported | Windows Server 2019,Windows Server 2022,Red Hat Enterprise Linux 8.6 x64,Red Hat Enterprise Linux 9.0 x64,SUSE Linux Enterprise Server 15 SP4 x64,Ubuntu 20.04.5 LTS x64,Ubuntu 22.04 LTS x64 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 1.30 kW |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.71" (43.50 mm) |
| Width | 17.24" (438 mm) |
| Depth | 27.95" (710 mm) |
FAQ
What processors are compatible with this barebone system?
This system supports single AMD EPYC processors using the Socket SP5 LGA-6096 interface. The platform is designed for EPYC server processors, providing 64-bit processing capabilities for enterprise workloads. You'll need to purchase a compatible EPYC CPU separately to complete the system.
How much memory can this system support?
The R163-Z32-AAC2 supports up to 256GB of DDR5 SDRAM using the DDR5-4800/PC5-38400 memory standard. This capacity is distributed across twelve memory slots, allowing for flexible DIMM configurations. The DDR5 technology provides improved bandwidth and power efficiency compared to previous DDR4 implementations.
What storage interfaces are included?
This barebone system includes integrated 12Gb/s SAS (Serial Attached SCSI) and Serial ATA/600 controllers. The 12Gb/s SAS interface offers high-speed connectivity suitable for enterprise storage arrays, while the SATA/600 support accommodates standard hard drives and SSDs. RAID functionality is not supported by the integrated controllers.
What expansion capabilities does this system offer?
The chassis provides two PCI Express x16 slots for additional expansion cards, such as network adapters, storage controllers, or GPU accelerators. Additionally, there are twelve total expansion bays for storage drive installation. The system includes four USB 3.2 Gen 1 ports for peripheral connectivity and Gigabit Ethernet for network integration.
What operating systems are supported?
This barebone system supports multiple server operating systems including Windows Server 2019, Windows Server 2022, Red Hat Enterprise Linux 8.6/9.0 x64, SUSE Linux Enterprise Server 15 SP4 x64, Ubuntu 20.04.5 LTS x64, and Ubuntu 22.04 LTS x64. This broad compatibility allows deployment in diverse enterprise environments with different OS requirements.
What are the power supply specifications?
The system includes two installed power supplies with a maximum wattage of 1.30kW each. These power supplies feature automatic voltage sensing for both 120V AC and 230V AC input, making them suitable for deployment in different geographical regions. The dual power supply configuration provides redundancy for continuous operation in critical server applications.
